Functional description

Error messages of the system

Communication error (error code 0x00000016)

This error occurs when there is a communication problem between the control panel and the rest of the system. In that case, the system will stop
automatically for safety reasons. After acknowledging the error message you can continue with your work. Please inform your service partner
about the occurrence of this error.

Isolation error (error code 0x00000017)

An isolation error occurs when there is a hardware problem with the crawler's isolation. As a consequence the case of the crawler will be current-car-
rying. Therefore it is no longer safe to operate the system. Do not touch the case of the crawler until you have switched it off. Please contact your
service partner afterwards about how to proceed.

Cable reel inclination error (error code 0x00000018)

This error happens due to a safety measure of the cable reel when winding up the cable and when the cable reel is in a too much tilted position.
In this case, the system will be stopped completely, and the cable reel's torque will be disabled. After acknowledging the error message the cable
reel is operational again. If the cable reel is still in a too much tilted position at the time of the acknowledgement of the error message, this safety
measure will remain disabled until the cable reel will return to an uncritical position.

System configuration error (error code 0x00000019)

This error occurs when a device has been connected to the system which is either too old to work with VISIONCONTROL or it is generally not
supported by the software. Older SUPERVISION
i.e. ROVION . Among the devices that are not supported are e.g. SUPERVISION
®
designed to be EX-compatible. In such a case, all system controls will be disabled for security reasons, joysticks etc. will not work. In case you
have any questions about that, please contact your service partner.
36
devices require a hardware or software update to work together with VISIONCONTROL
®
devices because VISIONCONTROL has not been
®
