Device Control

Reel invert mode

The reel invert mode can be activated to drive backwards into a pipeline with the crawler.
By activating the button Reel standard mode the cable reel's status is changed from standard to invert mode. A new window is displayed,
where you need to reconfirm your selection to activate the reel invert mode by pressing the button yes.
Reel standard mode is activated:
The crawler moves forward, the cable is being unwound.
The crawler moves backwards, the cable is being rewound.
Reel invert mode is activated:
The crawler moves backwards, the cable is being unwound.
The crawler moves forward, the cable is being rewound.
CAUTION!
Make sure not to drive over the camera cable to avoid damaging the cable.
With the invert mode being activated the winding direction of the cable reel also changes when operated manually!
Camera Movement & Locator
Camera & Laser
Miscellaneous
Crawler
Secure
Clutch
Slow
Mode
ON
OFF
Aux. Light
0%
+
-
Video Source
Internal External
Others
Reel Camera
Standard Auto
Mode Center
Do you want to set reel to reverse mode?
Device Control
System-Status Help
Ja
Nein
Executing the inspection
Exit
93
