Data transfer to storage medium

Data transfer to storage medium
On your VISIONCONTROL control panel you can export your inspection data, load updates from remote directories, or save video and image
data on different drives. All of these processes are executed in the data transfer dialog window. The file can be selected in the upper area of the
dialog selection. The data is structured in a tree menu that opens subdirectories to the right in new subdirectory when file folders are selected.
- In the "Directory" field you can change your filename.
- Use the Update view button to update the file view, if for example you have added a storage medium.
ATTENTION!
When importing, saving, or loading files please wait until the procedure is completely concluded. Premature cancellation of the
procedure can result in loss of data.
NOTE!
FAT32 and NTFS formatted USB sticks are supported.
User interface
71
