Status displays

Status displays
remaining video
recording time
meter counter /
overall meter counter /
AutoStop
active remote
control
Fig. Status displays
Battery 100 % charged
Battery 66 % charged
Battery 33 % charged
Battery < 33 % charged
(imminent automatic shutdown)
Locator on
Locator off
Pressure normal
Pressure low (blinking display)
Pressure high (permanent)
Inclination measurement forward
Inclination measurement backward
Video recording running
Camera position indicator
40h 10min 0,00m / 743,33m
Remote control is active !
Press FULL-STOP
to return to pendant mode.
Cable reel automatic mode
Cable reel manual mode
Clutch engaged
Clutch disengaged
Front camera on
Rear camera on
Cruise control
!
Crawler roll alert left
!
Crawler roll alert right
Crawler in level position
Functional description
13:50 Uhr
!
current time
33
