User interface
All functions of the Tools menu are shown below.
• Select Photo + OK, to complete the event and simultaneously take an inspection photo at this point.
NOTE!
If you select the option Photo + OK in the image view a new photo of the current section will be created and saved. The screen-
shot does not include the current text of the event.
NOTE!
If you select the option Photo + OK and if you have done a crack measurement using the laser just before, you can select if this
measurement should be included into the photo.
NOTE!
Mandatory input fields are shown in bold. You have to enter data in all of them, otherwise you cannot create a new event.
• Confirm your input with OK, to directly complete the event.

Quick Input

Inspection abbreviations can be entered directly to save time. Selecting the QUICK INPUT option takes you to the screen keyboard. You can
enter the known abbreviation directly here. The software automatically completes known inspection abbreviations.
• Select QUICK INPUT to enter an inspection abbreviation.
Inspection abbreviations can be obtained in an updated list from your service partner. Inspection abbreviations depend on the set locale. Make
sure that the locale you require and the required catalogue are always preset.
• Check the automatically compiled inspection text in the Text preview and edit it if required.
68
Events
