Measured value description

Measured value description
The following table contains a complete overview of the individual measured values and a description of the measurements on which these values
are based.
Diameter
Length
Rotation
Water Level
Start
End
Rotation
Radius
Angle
Rotation
Diameter
Angle
Rotation
Distance
Real Pipe
Diameter of the pipe to be inspected
Distance setting line 1 / setting line 2
Rotation of the setting lines around the pipe axis
Measure water level
Distance invert / water surface
Water level for setting line 1
Water level for setting line 2
Rotation of the measuring lines around the pipe axis
Measure bend
Radius of the neutral axis of the bend
Angle between setting line 2 / measuring line 1
Rotation of the bend around the pipe axis
Measure branch
Diameter of the branched pipe
Branch angle
Rotation of the branch around the pipe axis
Distance setting line 1 / intersection of center axis branch and pipe wall of real pipe
Measuring Functions
125
