Overview of the Measuring Functions
All measuring and setting lines can be set both using the joysticks and via the L1-L5 and R1-R5 buttons.
Measuring line: Pipe Branch
Measuring lines: Water Level
Measuring lines: Pipe Wall Object
Measuring lines: Cross Section Object
Measuring Functions
REAL PIPE:
Diameter:
Length:
Rotation:
WATER LEVEL:
Start:
12.75mm
End:
12.10mm
Rotation:
0.00°
REAL PIPE:
Diameter:
150.00mm
Length:
105.50mm
Rotation:
2.80°
PIPE WALL OBJECT:
Grid Unit:
5.00mm
Distance:
3.46mm
Rotation:
188.00°
Length:
15.00mm
Arc length:
15.00mm
REAL PIPE:
CROSS SECTION OBJECT:
Diameter:
Grid Unit: 5.00mm
Length:
Distance: 7.00mm
Rotation:
Rotation:
15.00°
Video Real view
150.00mm
105.50mm
2.80°
150.00mm
105.50mm
2.80°
119
