Take Screenshot

Take Screenshot
The action button Take Screenshot creates an inspection screenshot of the current view. This function is also active during a running video
recording. The recording will then be stopped for the time involved in taking the screenshot, and then it will automatically continue. If you have
opened a general project, you can take a screenshot only when you have created at least one event in the current section.
• Select Take Screenshot.
If you are working on a general project, a new dialog will open which shows the two picture slots of the last event of the current section. You can
select which slot the new screenshot will be assigned to. You can also overwrite existing screenshots here.
• Photos will be saved after approximately 3 seconds.
NOTE!
Shown measurements are mapped in the recorded photo and saved. The measured values can therefore be called up again via the
inspection photo.
NOTE!
All recorded screenshots can be called again in the Image View dialog.
In order to view, manage, or delete images you must go to the image view dialog. A detailed description of this process is provided starting
on Seite 78.
When you open a dialog, video recording pauses. The recording will continue automatically when you exit the dialog.
