Measuring Functions
Real view of the virtual settings lines in the video view
Setting line 1
Virtual Pipe
Setting line 2
Virtual Pipe
Set measuring lines scheme
If the real pipe has been referenced, the measuring lines for the measuring functions can now be positioned. The relevant measuring lines are
supplemented and positioned for the setting lines of the real pipe for this. The following schemes show the individual measuring lines of the
measuring functions.
118
PIPE BRANCH:
Diameter:
100.00mm
Angle:
45.00°
Rotation:
7.00°
Distance:
20.00mm
Measuring line: Pipe Bend
Measuring line: Pipe Branch
Measuring lines: Water Level
Overview of the Measuring Functions
REAL PIPE:
Diameter:
150.00mm
Length:
105.50mm
Rotation:
2.80°
PIPE BEND:
Radius:
51.00mm
Angle:
45.00°
Rotation:
90.00°
PIPE BRANCH:
Diameter:
100.00mm
Angle:
45.00°
Rotation:
7.00°
Distance:
20.00mm
Video Real view
REAL PIPE:
Diameter:
150.00mm
Length:
105.50mm
Rotation:
2.80°
REAL PIPE:
Diameter:
150.00mm
Length:
105.50mm
Rotation:
2.80°
