Functional description

Notes for the Status displays

Camera Position Indicator:
The Camera Position Indicator visualizes the current pan and tilt position of the camera head, whereas the inner circle of the graphic indicates a
tilt position of 90 degrees, the outer circle a tilt position of 180 degrees. The red gradient horizon shows the current pan position of the camera.
According to the pan movement, it moves in a circular path around the center of the graphic. Finally, the green dot combines both the pan and tilt
position and shows the current position of the camera head.
Meter Counter:
The meter counter für the current section is displayed on the left, the overall meter counter on the right. The overall meter counter shows you the
current position - across several sections. This is especially helpful when you have created several satellite sections. This way it is easier for you to
determine the distance between you and the crawler.
AutoStop:
An additional meter counter is displayed if the AutoStop is active. The Offset value for the AutoStop is in brackets after the other meter counter
values.
Crawler Roll Alert:
A warning is displayed when the crawler is about to tilt over sidewards. With the help of this warning you can easily recognize in which direction
you have to steer the crawler in order to get it into an uncritical i.e. upright position again. When such a position is reached, the warning will
disappear by itself.
34
Status displays
