Functional description
Inspection interface
6
1 Video image
2 Status bar with monitoring displays
3 Status bar with function displays
4 Touch screen buttons (referenced with R1 – R5 buttons on the VISIONCONTROL control panel)
5 Touch screen function menu buttons
6 Touch screen buttons (referenced with L1 – L5 buttons on the VISIONCONTROL control panel)
