User interface

Switching the control panel off

It can take up to 20 seconds to switch the control panel off. At the end of the process the connected inspection system will switch off by itself.
The camera i.e. the crawler are already switched off upon initiating shutdown.
• Briefly press the ON/OFF button.
Directly after pressing the ON/OFF button a selection dialog will be shown on the display.
Confirm this dialog with Yes, if you want to switch off the control panel. If you do not want to switch off the control panel press NO.
ATTENTION!
When using the VISIONCONTROL with the ROVION
shut down properly before pushing the On/Off switch of the cable reel, otherwise loss of data can occur.

Forced switch off

If the control panel should no longer react to inputs, you can force the switch off.
• Press the ON/OFF button for at least 3 seconds.
• Wait for approximately 10 seconds and switch the control panel on again.
ATTENTION!
Only switch the control panel off in this manner in an emergency. Otherwise you can count on data loss and damaged video files.
After restart wait until the control panel is completely started.
38
, it is highly recommended that you first let the VISIONCONTROL
®
Switching the control panel on or off
