Tools

The Tools menu allows you to select various helpful additional functions of the VISIONREPORT operating software while you are compiling an
inspection event. You have the option of editing the meter counter, performing various measurements or adapting the text visualization. You can
therefore record helpful additional information for later analyses regarding every event. A detailed description of the measuring functions can be
found from Seite 115 onwards.
Set meter counter
You can assign a new value to the meter counter at this position.
Measure cracks
You can measure cracks here using the camera's integral laser (if available).
Measure water level
You can measure the level of the water in the pipe here.
Measure bend
You can measure the radius and offset value of a bend here.
Measure branch
You can measure the diameter and angle of a branch here.
Measure PIPE WALL OBJECT
You can measure an object that is located on the curved pipe wall here.
Measure cross-section object
You can measure an object that is located on the cross section level / cylinder level of the pipe here.
Adapt text
You can adapt the layout and appearance of the inspection text here.
NOTE!
The measuring functions are only available if a catalogue is selected in the current project and all required data has already been
entered in the event.
NOTE!
The crack width measurement is only possible if a camera with integral laser system is connected to the system.
