Basic setting functions

Settings

The settings area provided in every measuring option lets you show and set a virtual 3D grid for visualization
of the pipe course. You can also load an inspection image which you can also use to perform a subsequent measurement.
The Settings function is called up by pressing the button and hidden again of you press the button again.
Increase 3D grid lines
A virtual 3D grid is created between the relevant start and end lines. The division of the grid lines is increased
by pressing this button.
Decrease 3D grid lines
A virtual 3D grid is created between the relevant start and end lines. The division of the grid lines is decreased
by pressing this button.
Measure image file
You can also measure an inspection image from a previous inspection as an alternative to measuring the current inspection.
By pressing the button, you can load an image from the image directory, which is then positioned over the current
video image.
NOTE!
A correct measurement of an image file is only possible if the loaded inspection has the same position properties as the current
settings.
