MSI/Plessey

Disable MSI & Plessey bar codes
Enable MSI, 1 Mod 10 check digit
Enable MSI, 2 Mod 10 check digits
Enable MSI, 1 Mod 11/ Mod 10 check digit
Transmit no check digits
Transmit 1 check digit
Transmit 2 check digits
Enable Plessey bar code (mutually exclusive with MSI)
Enable LabelCode5 (mutually exclusive with MSI & Plessey)
Enable LabelCode4 (mutually exclusive with all above codes)
• LabelCode 5 and LabelCode 4 are proprietary bar code types used by
Follet.
• For more information regarding MSI or Plessey Code, see Appendix
M; MSI Plessey Code.

Code 128

Disable Code 128
Enable Code 128
Disable UCC/EAN-128
Enable UCC/EAN-128
Enable Storage Tek Tape Label Code (TriOptic Code 39)
Disable Storage Tek Tape Label Code (TriOptic Code 39)
Bar Code ID's transmitted
Bar Code ID's not transmitted
• UCC/EAN-128 is a subset of Code 128 that follows certain
specifications regarding character content, length and check digits.
Enabling UCC/EAN-128 (2) causes the TriCoder to look for a Code
128 bar code that begins with the Code 128 F1 (Function 1) character.
See Appendix I; Code 128 for more details.
• The StorageTek Tape Label code (also called TriOptic Code 39) is a
proprietary variation of Code 39 code used for the storage of computer
data tapes. Enabling the tape label code (C) does not disable reading of
Code 128 bar codes.
• Bar Code ID's are characters assigned to each bar code type to identify
that particular type of code. These Bar Code ID's can be used to identify
what type of bar code you are using when you are not sure or you want
your application to differentiate between the different types. This applies
only when the TriCoder is used in NON PORTABLE mode.
6-12
0
1
2
3
4
5
6
7
8
9
0
1
2
3
C
D
E
F
