Laser and CCD
The laser and CCD TTL pin-outs are:
Remember:
If you make your own cables, you are on your own. We accept NO
RESPONSIBILITY for damages resulting from incorrect wiring.
Pin
1
2
3
4
5
6
7
8
Table I-11. Laser and CCD Pin-outs
Function
5 volts
Data
Phase
LED
Trigger
Enable
Shield(drain)
Ground
D-4
