PROGRAMMING MODE
PASSWORD?_
PROGRAM FUNCTION KEY
Create Programs---->1-3
Voice Operations---->4
Change Setup-------->5
PROGRAM NOT SET
HIT ANY KEY_
PROGRAM NO.?
KEY [0-3]?_
PROGRAM RECEIVE
KEY [Y/N]?_
PROGRAM TRANSMIT
KEY [Y/N]?_
RECEIVE PROGRAM KEY
Programs[1-3]? 1-3
Clone TriCoder?->0
RECEIVING PROG.
PLEASE WAIT>
RECEIVING INTERRUPTED
Key Pressed In Error
Restart Transmission
Hit any Key_
RTC ERROR
Call 831-458-9938
SEARCH PATTERN
_
SENDING PROGRAM
PLEASE WAIT_
SRAM WRITE ERROR
CYCLE POWER_
Start Host Program
Then Hit Any Key
Start Host USB
Firmware Download
Program First and
Then Hit Any Key.
TABLE DOWNLOAD?
KEY [YES/NO]?_
TABLE FORMAT ERR
PRESS ANY KEY_
TABLE NOT AVAILABLE
HIT ANY KEY_
You are trying to enter
Programming Mode and need to
enter the password. The password
prevents programming accidents.
You have correctly entered the
password and are in Programming
Mode. Select the function you
want by pressing the correct key.
You have requested to collect data
in a program that has not been
defined, or you are trying to
transmit a program that has not
been defined.
You are in Data Collection mode
and need to select a program to
use.
Do you want to receive a program
from another TriCoder or host
computer?
Do you want to transmit a program
to another TriCoder or a host
computer?
You have answered YES to
program receive mode. Choose
the program to receive into or
choose to clone.
A program is being received by the
TriCoder.
A key was pressed on the TriCoder
after program transfer had started,
aborting the transmission. TriCoder
contains invalid program
information.
This error should not occur and
indicates a firmware problem. Try
to record what led to this error.
The SEARCH key was pressed.
You are transmitting a program
from the TriCoder. Wait for
completion.
A serious error was detected. If
persistent, call for RMA.
TriCoder is ready to receive from
the host via USB, (i.e. Table,
Program, or Firmware Download)
Firmware download has been
requested. USB enumeration has
been completed. Now TriCoder is
requesting the user to start PC
TriCoder Firmware Downloader.
A table has been defined in the
memory partitions - you can now
download a table into the TriCoder.
The table header is in an invalid
format or EOF Ctrl Z (ASCII 26) is
missing.
The host program has told the
TriCoder it has no table to
download.
14-4
Key in the password -
WDTRI
Key the number that
corresponds to what you
want to do.
HIT ANY KEY. Enter the
correct program number or
go to Programming Mode to
create a new program.
Key 0, 1,2 or 3.
Press YES to go to
Receiving Menu. Press NO
to go to the Mode Menu.
Press YES to go to Transmit
Menu.
Press NO to go to Mode
Menu.
Press the Program # or 0 to
Clone.
Wait for next message.
Hit any Key. Restart
transmission. Do not press
any keys on TriCoder once
transmission has begun.
Cycle Power to clear, Call
for support.
Enter data to search for or
press ENTER key to exit.
Wait for next message.
Turn TriCoder OFF/ON. Call
for support if error continues
to occur.
Start the host computer
program, i.e. TriCoder
Utilities, then Hit Any key.
Start the Windows program,
TriCoder Firmware
Downloader. Available on
TriCoder Utilities CD ROM,
or on www.barcodehq.com.
Press YES to continue with
table download.
Press NO to return to Mode
Menu.
Check table file for format
errors. Try again.
Try again later.
