Worth Data TriCoder t53 User Manual page 196

8. Click the "Next" button in the Device Driver Wizard
9. Select "Search for a suitable driver for my device (recommended)."
and click "Next"
10. Select "Specify a location" and click "Next"
11. Browse to the Worth Data Utilities CD ROM of the folder where
you unpacked files downloaded from www.barcodehq.com and
click "OK"
12. Choose "Install one of the other drivers" at the bottom of the
dialog and click "Next"
13. In the next dialog, choose "TriCoderUSB", (NOT
"TRICODERUSB" which is the old driver), (future will be
TriCoderHCUSB) and click "Next"
14. When it asks you to insert disk, click "OK"
15. Browse to the directory where you unpacked the files and click "OK"
16. Click "Finish"
Manually Updating Tricoder USB Driver on Windows 98/Me
1. Plug the Tricoder into the computer's USB port and turn it on.
Make sure it is in High Speed mode, (go to the Data Collection?
Y/N prompt).
2. In Windows, go to: Start | Settings | Control Panel | System.
3. Now select the View Devices By Connection option.
4. For USB devices, navigate to Standard PC | PCI bus | PCI To USB
Universal Host Controller | USB Root Hub | TricoderUSB, (future
will be TriCoderHCUSB).
5. Select Properties.
6. Click the Update Driver button in the Driver tab.
7. Click the Next button.
8. Check the Only Specify A Location check-box.
9. Click the Next button.
10. In the input box that is displayed, enter the path to the Worth Data
Utilities CD or the folder where the downloaded driver files have
been extracted.
11. Click the OK button.
12. Click the Next button.
13. Click the Finish button.
14. Reboot.
G-3
