Summary of Contents for Worth Data LZ360-RF
- Page 2 PROPOSITION 65 WARNING: This product, its packaging, and/or components may contain chemicals known to the state of California to cause cancer or birth defects or other reproductive harm Worth Data, Inc. 623 Swift Street Santa Cruz, CA 95060 Toll free USA &...
-
Page 3: Table Of Contents
Troubleshooting ................................23 Windows XP: ................................24 Win98/ME: ................................... 24 Win2000: ..................................24 Worth Data 520-RF Bar Code Scanner Setup Guide ..................... 25 1D Codes: ................................... 25 2D codes: ..................................26 Other Options: ................................26 Set to factory default: ..............................27 UPC ..................................... - Page 4 Prefix / Suffix Commands Continued: ........................63 Prefix / Suffix ASCII Value Table: ..........................64 Prefix / Suffix ASCII Value Table Continued: ......................65 Code Identification / Length Settings: ........................65 Worth Data Code ID Prefix / Suffix Values: ......................66...
- Page 5 Collective Reading Settings: ............................ 67 Collective Reading Settings Continued: ......................... 68 Read Mode Settings: ..............................69 Read Mode Settings Continued: ..........................70 Read Mode Settings Continued: ..........................71 Read Mode Settings Continued: ..........................72 Imager Settings: ................................. 73...
-
Page 6: Introduction
Introduction Worth Data RF Lasers have the following features: A range of up to 500 feet (line-of-sight) with collision detection and retry logic built in. Indoor range will vary depending on wall construction type, number of walls and other obstructions between the RF Laser and USB Base Station receiver. -
Page 7: Installation
RF Laser Battery Charging Before using the RF Laser it is a good idea to fully charge the battery. Simply plug the Worth Data charger into the base of the RF Laser handle. The red LED should turn on to indicate that the battery is being charged. -
Page 8: Pairing
Pairing The default state of the RF Laser is un-paired. You must pair the RF Laser to the USB Base Station receiver that you wish it to communicate with. You can pair the RF Laser with any USB Base Station receiver but it can only be paired with one at a time. -
Page 9: Operational Modes
Operational Modes Normal Operation When you scan, you will get one high pitched beep when you get a successful decode. The data is then transmitted to the USB Base Station receiver (as it is being transmitted, the LED turns blue). When the Laser receives the acknowledgement from the Base Station that the data has been received, the RF Laser emits a lower pitched beep and turns on a green LED. -
Page 10: 1D Setup Mode
1D Setup Mode Note: If you are using the 2D 520-RF then refer to the 2D setup chart starting on page 21. On the included CD-ROM you will find the RF Laser Setup Menu sheet. This simple menu lets you easily configure the RF Laser Reader to work with almost any computer system, and to tailor its bar code reading and data format characteristics. -
Page 11: Laser Scanning Instructions
Laser Scanning Instructions Using a laser scanner is basically as simple and intuitive as "point and shoot" at a distance of 0-24", depending on the density of the bar code. Basically, the laser scanner's beams must cross every bar and space on the bar code, without touching any other bar codes, as shown in the first example below. -
Page 12: Using The 1D Rf Laser Setup Menu
Using The 1D RF Laser Setup Menu Note: If you are using the 2D 520-RF then refer to the 2D setup chart starting on page 24. 1. To configure your reader using the RF Laser Setup Menu, you must first scan the Start Setup code at the top left corner. -
Page 13: Code 3 Of 9 (Code 39)
Note: If you are using the 2D 520-RF then refer to the 2D setup chart starting on page 24. Code 3 of 9 (Code 39) Enable Code 39 Disable Code 39 Enable Full ASCII Code 39 Disable Full ASCII Code 39 Enable Code 39 Accumulate Mode Disable Code 39 Accumulate Mode Enable Start/stop character transmission... -
Page 14: Upc/Ean
Note: If you are using the 2D 520-RF then refer to the 2D setup chart starting on page 24. UPC/EAN Enable UPC/EAN Disable UPC/EAN Enable UPC/EAN Supplements Disable UPC/EAN Supplements Enable transmission of UPC-A NSC and EAN-13 1 Disable transmission of UPC-A NSC and EAN-13 1 1 digits Enable transmission of UPC-A and EAN–13 Check Digit Disable transmission of UPC-A and EAN-13 Check Digit... -
Page 15: Code 128
Note: If you are using the 2D 520-RF then refer to the 2D setup chart starting on page 24. Code 128 Disable Code 128 Enable Code 128 Disable UCC/EAN-128 Enable UCC/EAN-128 Enable Storage Tek Tape Label Code Disable Storage Tek Tape Label Code Bar Code IDs transmitted Bar Code IDs not transmitted To enable a Bar Code ID character to be transmitted at the beginning of each bar code read, scan E. -
Page 16: Of 5 Code
Note: If you are using the 2D 520-RF then refer to the 2D setup chart starting on page 24. 2 of 5 Code Enable Interleaved 2 of 5 Disable Interleaved 2 of 5 Enable Interleaved 2 of 5 Check Digit Disable Interleaved 2 of 5 Check Digit Enable Check Digit Transmission Disable Check Digit Transmission... -
Page 17: Terminator Characters
Note: If you are using the 2D 520-RF then refer to the 2D setup chart starting on page 24. Terminator characters Enter (carriage return) None CR/LF Depending on your application, you may wish your Wireless Reader to transmit bar code data to your computer with an Enter (carriage return), a Tab at the end, or with no extra terminating character at all. -
Page 18: Postamble
Note: If you are using the 2D 520-RF then refer to the 2D setup chart starting on page 24. Postamble "Postamble" refers to a user-specified data string transmitted at the end of each bar code. For instance, if you specify the postamble @@ and read data of 123456, "123456@@" would be transmitted to your computer. The default is no postamble. -
Page 19: Difficult Code Setup Options (Does Not Apply To 2D Rf Laser)
DIFFICULT CODE SETUP OPTIONS (does not apply to 2D RF Laser) Aiming Laser Dot: (LZ404-RF only) Sometimes it is difficult to see the laser beam and know you are on the bar code, especially if you are attempting to read outdoors in direct sunlight. The laser can be output as a bright dot for a few seconds, allowing the user to place the dot in the middle of the bar code;... -
Page 20: Accumulate Mode (1D Only)
Accumulate Mode (1D only) Accumulate Mode is an option (which can be enabled or disabled using the Reader Setup Menu's Code 39 section) allowing the reader to accumulate multiple bar codes in its buffer, then transmit them to the computer as if they had been a single bar code. -
Page 21: Function/Control Key Support
Function/Control Key Support The RF Laser can also transmit key sequences for function, control, alt (command and option keys on Macs), cursor and shift keys, for ease of use with the many software packages using these keys for menus or commands. - Page 22 Windows Key The Windows key on a Windows keyboard is transmitted by scanning 4 bar codes - NULL and C for Windows On (pressing down) and NULL and D for Windows Off (releasing the key). Command and Option Keys on Mac USB Keyboards When you have a WDP Reader attached to a Macintosh Computer's USB port, to emulate the Command key, use the Windows key ON/OFF bar codes NULL, C (Command ON) and NULL, D (Command OFF) For the Option Key ON/OFF use RS (Option On) and US (Option Off).
-
Page 23: Troubleshooting
Troubleshooting All Models Troubleshooting The beam won’t stay on, or I just get a narrow beam when I pull the trigger, or the scanner won’t turn on when I pull the trigger or the red LED flashes when I pull the trigger. All of the above problems are an indication that your BATTERY IS TOO LOW. -
Page 24: Windows Xp
USB Trouble Shooting The Base Station's light flashes in Red cycles when the USB cable is connected. The Base Station cannot enumerate. The driver is probably not installed correctly. Occasionally the user will be unaware that he aborted his driver installation. Once the process has started, it should finish successfully. -
Page 25: Worth Data 520-Rf Bar Code Scanner Setup Guide
Worth Data 520-RF Bar Code Scanner Setup Guide 1D Codes: Code Type Enabled by Default Additional Setup Info page 25 page 26 EAN-13 page 26 EAN-8 page 26 Code 39 page 28 Codabar page 29 Code 128 page 31 Code 93... -
Page 26: Codes
2D codes: Code Type Enabled by Default Additional Setup Info PDF417 page 45 Micro PDF417 page 46 Maxi Code page 47 QR Code page 48 Micro QR page 49 Aztec Code page 50 Aztec Runes page 51 Data Matrix (ECC 200) page 52 Data Matrix (ECC 000-140) page 52... -
Page 27: Set To Factory Default
Set to factory default: To set the scanner to factory defaults, scan the code below. Reset All 2D Settings to Default... -
Page 28: Upc
Start Setup End Setup ,ZZ, ,ZZ, UPC-A Settings: ,E3, UPC-A, no leading zero, transmit check digit default ,E5, UPC-A UPC-A, no leading zero, not transmit check digit leading zero ,E2, UPC-A, leading zero, transmit check digit check digit transmission ,E4, UPC-A, leading zero, not transmit check digit UPC-E Settings: ,E7,... -
Page 29: Ean Settings
Start Setup End Setup ,ZZ, ,ZZ, EAN Settings: ,6J, not transmit EAN-13 check digit ,6K, EAN-13 and EAN-8 transmit EAN-13 check digit default Check Digit ,6H, not transmit EAN-8 check digit Transmission ,6I, transmit EAN-8 check digit default ,IB, disable ISBN conversion default EAN-13 and EAN-8 ,IA,... -
Page 30: Ean Supplement Settings
EAN Supplement Settings: EAN Symbologies Exclusive Enable Disable ,J4, ,R4, ,X4E, EAN no supplement (default enable) ,J5, ,R5, ,X4F, EAN with 2-digit supplement ,J6, ,R6, ,X4G, EAN with 5-digit supplement note: setting any symbology to exclusive will disable all other symbologies EAN-13 Supplement Settings: EAN Symbologies Exclusive... -
Page 31: Code 39 Settings
Code 39 Start Setup End Setup ,ZZ, ,ZZ, Code 39 Settings: Code 39 Exclusive Enable Disable ,A2, ,B2, ,VB, Code 39 Enable/Disable (default enable) note: setting any symbology to exclusive will disable all other symbologies ,D5, normal code 39 default ,D4, Full ASCII Conversion full ASCII code 39... -
Page 32: Codabar Settings
Codabar Start Setup End Setup ,ZZ, ,ZZ, Codabar Settings: Codabar Exclusive Enable Disable ,A3, ,B3, ,VC, Codabar Enable/Disable (default enable) note: setting any symbology to exclusive will disable all other symbologies ,HA, enable only Codabar normal mode default ,H4, enable only ABC code Codabar ABC, CX Conversion ,H5,... -
Page 33: Codabar Settings Continued
Codabar Settings Continued: ,HC, minimum data = one character Codabar ,HB, minimum data = three characters Minimum Digit ,HF, minimum data = five characters default ,HE, disable space insertion default Codabar Space Insertion ,HD, enable space insertion ,HI, Codabar disable inter-character gap check Inter-Character ,HH, enable inter-character gap check... -
Page 34: Code 128 Settings
Code 128 Start Setup End Setup ,ZZ, ,ZZ, Code 128 Settings: Codabar Exclusive Enable Disable ,A6, ,B6, ,VE, Code 128 Enable/Disable (default enable) note: setting any symbology to exclusive will disable all other symbologies ,OF, disable GS1-128 default Code 128 and ,JF, GS1-128 (EAN-128) enable GS1-128 only... -
Page 35: Code 93 Settings
Code 93 Start Setup End Setup ,ZZ, ,ZZ, Code 93 Settings: Symbology Exclusive Enable Disable ,A5, ,B5, ,VD, Code 93 (default enable) note: setting any symbology to exclusive will disable all other symbologies ,DZ, not transmit CD default Code 93 Check Digit (CD) ,DY, transmit CD... -
Page 36: Code 11 Settings
Code 11 Start Setup End Setup ,ZZ, ,ZZ, Code 11 Settings: Symbology Exclusive Enable Disable ,BLB, ,BLC, ,BLA, Code 11 (default disable) note: setting any symbology to exclusive will disable all other symbologies ,BLF, not check CD ,BLG, check 1 CD ,BLH, check 2 CD Code 11... -
Page 37: Of 5 And S-Code Settings
2 of 5 and S-Code Start Setup End Setup ,ZZ, ,ZZ, 2 of 5 and S-Code Settings: Symbology Exclusive Enable Disable ,J7, ,R7, ,X4K, Industrial 2 of 5 (default enable) ,J8, ,R8, ,X4L, Interleaved 2 of 5 (default enable) ,RA, ,R9, S-Code (default enable) ,AB,... -
Page 38: Msi / Plessey Settings
MSI / Plessey Start Setup End Setup ,ZZ, ,ZZ, MSI / Plessey Settings: Symbology Exclusive Enable Disable ,A7, ,B7, ,VF, MSI / Plessey (default enable) note: setting any symbology to exclusive will disable all other symbologies ,4A, not check CD ,4B, check 1 CD = mod 10 default... -
Page 39: Uk / Plessey Settings
UK / Plessey Start Setup End Setup ,ZZ, ,ZZ, UK / Plessey Settings: Symbology Exclusive Enable Disable ,A1, ,B1, ,VA, UK / Plessey (default enable) note: setting any symbology to exclusive will disable all other symbologies ,4O, not transmit CD UK / Plessey Check Digit (CD) ,4N,... -
Page 40: Postnet Settings
POSTNET Start Setup End Setup ,ZZ, ,ZZ, POSTNET Settings: Symbology Exclusive Enable Disable ,D6C, ,D6A, ,D6B, POSTNET (default disable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 41: Intelligent Mail Bar Code Settings
Intelligent Mail Bar Code Start Setup End Setup ,ZZ, ,ZZ, Intelligent Mail Bar Code Settings: Symbology Exclusive Enable Disable ,D5H, ,D5F, ,D5G, IMBC (default disable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 42: Gs1 Databar Settings
GS1 DataBar Start Setup End Setup ,ZZ, ,ZZ, GS1 DataBar Settings: Symbology Exclusive Enable Disable GS1 DataBar Omnidirectional Truncated ,J9, ,JX, ,SJ, Stacked Stacked Omnidirectional (default enable) GS1 DataBar Limited ,JJ, ,JY, ,SK, (default enable) GS1 DataBar Expanded ,JK, ,DR, ,SL, Expanded Stacked (default enable) -
Page 43: Korean Postal Authority Code Settings
Korean Postal Authority Start Setup End Setup ,ZZ, ,ZZ, Korean Postal Authority Code Settings: Symbology Exclusive Enable Disable Korean Postal Authority ,JL, ,WH, ,WI, (default disable) note: setting any symbology to exclusive will disable all other symbologies ,*-, not transmit CD default Korean Postal Authority Check Digit (CD) -
Page 44: Iata Settings
IATA Start Setup End Setup ,ZZ, ,ZZ, IATA Settings: Symbology Exclusive Enable Disable ,A4, ,B4, ,VH, IATA (default enable) note: setting any symbology to exclusive will disable all other symbologies ,4H, not check CD default ,4I, check FC / SN only IATA Check Digit (CD) ,4J,... -
Page 45: Tri-Optic Settings
Tri-Optic Start Setup End Setup ,ZZ, ,ZZ, Tri-Optic Settings: Symbology Exclusive Enable Disable ,JD, ,JZ, Tri-Optic (default enable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 46: Telepen Settings
Telepen Start Setup End Setup ,ZZ, ,ZZ, Telepen Settings: Symbology Exclusive Enable Disable ,A9, ,B9, ,VG, Telepen (default enable) note: setting any symbology to exclusive will disable all other symbologies ,D2, numeric mode default Telepen Conversion Output Mode ,D3, ASCII mode... -
Page 47: Jpn Settings
JPN (Customer Bar Code) Start Setup End Setup ,ZZ, ,ZZ, JPN Settings: Symbology Exclusive Enable Disable ,D5R, ,D5P, ,D5Q, JPN (default disable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 48: Pdf417 Settings
PDF417 Start Setup End Setup ,ZZ, ,ZZ, PDF417 Settings: Symbology Exclusive Enable Disable ,BC3, ,BCF, ,BCR, PDF417 (default enable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 49: Micro Pdf417 Settings
Micro PDF417 Start Setup End Setup ,ZZ, ,ZZ, Micro PDF417 Settings: Symbology Exclusive Enable Disable ,BC4, ,BCG, ,BCS, Micro PDF417 (default enable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 50: Maxi Code Settings
Maxi Code Start Setup End Setup ,ZZ, ,ZZ, Maxi Code Settings: Symbology Exclusive Enable Disable ,BC2, ,BCE, ,BCQ, Maxi Code (default enable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 51: Qr Code Settings
QR Code Start Setup End Setup ,ZZ, ,ZZ, QR Code Settings: Symbology Exclusive Enable Disable ,BC1, ,BCD, ,BCP, QR Code (default enable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 52: Micro Qr Settings
Micro QR Start Setup End Setup ,ZZ, ,ZZ, Micro QR Settings: Symbology Exclusive Enable Disable ,D38, ,D2U, ,D2V, Micro QR (default enable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 53: Aztec Code Settings
Aztec Code Start Setup End Setup ,ZZ, ,ZZ, Aztec Code Settings: Symbology Exclusive Enable Disable ,BC5, ,BCH, ,BCT, Aztec Code (default enable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 54: Aztec Runes Settings
Aztec Runes Start Setup End Setup ,ZZ, ,ZZ, Aztec Runes Settings: Symbology Exclusive Enable Disable ,BF4, ,BF2, ,BF3, Aztec Runes (default disable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 55: Data Matrix Settings
Data Matrix Start Setup End Setup ,ZZ, ,ZZ, Data Matrix Settings: Symbology Exclusive Enable Disable Data Matrix (ECC 200) ,BC0, ,BCC, ,BCO, (default enable) Data Matrix (ECC 000-140) ,BG2, ,BG0, ,BG1, (default disable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 56: Codablock F Settings
Codablock F Start Setup End Setup ,ZZ, ,ZZ, Codablock F Settings: Symbology Exclusive Enable Disable ,D4R, ,D4P, ,D4Q, Codablock F (default disable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 57: Chinese Sensible Code Settings
Chinese Sensible Code Start Setup End Setup ,ZZ, ,ZZ, Chinese Sensible Code Settings: Symbology Exclusive Enable Disable Chinese Sensible Code ,D4K, ,D4L, ,D4M, (default disable) note: setting any symbology to exclusive will disable all other symbologies... -
Page 58: All Codes Settings
All Codes Start Setup End Setup ,ZZ, ,ZZ, All Codes Settings: Symbology Exclusive Enable Disable ,BCA, ,BCM, ,BCY, All 1D Codes (default disable) ,BCB, ,BCN, ,BCZ, All 2D Codes (default disable) All 1D and 2D Codes ,A0, ,B0, (default disable) note: setting any symbology to exclusive will disable all other symbologies Use this setting if you're having trouble reading a bar code with the default settings and you don't know what type of code you are trying to read. -
Page 59: Number Of Characters Settings
Number of Characters Start Setup End Setup ,ZZ, ,ZZ, Number of Characters Settings: If you are going to read bar codes of a known length, it is recommended to set the scanner for a fixed number of characters. The scanner uses this to verify that labels read are of the correct length and reject labels that do not have the specified length. -
Page 60: Composite Codes Settings
Composite Codes Start Setup End Setup ,ZZ, ,ZZ, Composite Codes Settings: ,RQ, not ignore link flag for RSS/EAN-128 and EAN/UPC default Link Flag ,RP, ignore link flag for RSS/EAN-128 and EAN/UPC ,BHF, disable RSS/EAN-128 composite default RSS / EAN-128 Composite ,BHE, enable RSS/EAN-128 composite ,D1W,... -
Page 61: Case Conversion Settings
String Options Start Setup End Setup ,ZZ, ,ZZ, Case Conversion Settings: ,YZ, no case conversion (AbCd -> AbCd) default ,YW, convert to upper case (AbCd -> ABCD) Case Conversion ,YX, convert to lower case (AbCd -> abcd) ,YY, exchange case (AbCd -> aBcD) Output Format Settings: The following additional characters can be included in each code that is scanned: Preamble / Postamble (up to 8 digits) -
Page 62: Prefix / Suffix Commands
Prefix / Suffix Commands: Symbology Prefix Command Suffix Command ,RY, ,RZ, All Codes ,N1, ,N6, UPC-A ,M0, ,O0, UPC-A add-on ,N2, ,N7, UPC-E ,M1, ,O1, UPC-E add-on ,N3, ,N8, EAN-13 ,M2, ,O2, EAN-13 add-on ,N4, ,N9, EAN-8 ,M3, ,O3, EAN-8 add-on ,M4, ,O4, Code 39... -
Page 63: Prefix / Suffix Commands Continued
Prefix / Suffix Commands Continued: Symbology Prefix Command Suffix Command ,D6D, ,D6E, POSTNET ,OE, ,PQ, GS1 DataBar ,RR, ,RS, Composite code ,D4S, ,D4T, Codablock-F ,MD, ,PO, Data Matrix ,BF0, ,BF1, Aztec ,D4N, ,D4O, Chinese Sensible Code ,MK, ,PW, QR Code ,ML, ,PX, Maxicode... -
Page 64: Prefix / Suffix Ascii Value Table
Prefix / Suffix ASCII Value Table: ASCII Command ASCII Command ASCII Command ASCII Command ,5A, ,0A, ,$A, ,9G, <SP> (NULL) ,5B, ,0B, ,$B, ,1A, (SOH) ,5C, ,0C, ,$C, ,1B, “ (STX) ,5D, ,0D, ,$D, ,1C, (ETX) ,5E, ,0E, ,$E, ,1D, (EOT) ,5F, ,0F,... -
Page 65: Prefix / Suffix Ascii Value Table Continued
,9W, ,Q6, ,9F, ,Q7, ,Q8, ,Q9, Code Identification / Length Settings: ,$2, code identification using Worth Data Code ID Code Identification ,$1, code identification using AIM/ISO/IEC 15424 ID ,$3, code length (1D/2D : 2/6 digit) Code Length ,$6, code length (1D/2D : 6/6 digit) Code Identification and Code Length can be included in a prefix and/or suffix. -
Page 66: Worth Data Code Id Prefix / Suffix Values
Worth Data Code ID Prefix / Suffix Values: Code Code ID Code Code ID UPC-A MSI/Plessey UPC-A +2 Telepen UPC-A +5 UK/Plessey UPC-E Code 128 UPC-E +2 GS1-128 UPC-E +5 Code 93 EAN-13 Code 11 EAN-13 +2 Korean Postal Authority... -
Page 67: Collective Reading Settings
Collective Reading Start Setup End Setup ,ZZ, ,ZZ, Collective Reading Settings: It is possible to not output data unless the specified number of codes is read. That means that the scanner does not read codes other than the specified number. Use this setting to read a group of labels all at once. ,D01, multiple label = 1 default... -
Page 68: Collective Reading Settings Continued
Collective Reading Settings Continued: ,D0T, disable same label read during multiple read default Same Label Read ,D0U, enable same label read during multiple read ,D0V, enable sorting decoded labels default Sorting Labels ,D0W, disable sorting decoded labels ,D0X, buffered mode (one image) default ,D0L, Buffered Mode... -
Page 69: Read Mode Settings
Read Mode Start Setup End Setup ,ZZ, ,ZZ, Read Mode Settings: ,S0, single read default ,S1, Read Mode multiple read (see below) ,S2, continuous read (used mainly for demonstration) In multiple read mode, when a bar code has been decoded, the decoded data will be output and the scan engine will keep on reading. -
Page 70: Read Mode Settings Continued
Read Mode Settings Continued: ,+I, enable auto trigger Auto Trigger (Stand Mode) ,+F, disable auto trigger default ,%Q, disable auto trigger synchronization Auto Trigger Synchronization ,%R, enable auto trigger synchronization default note: when the auto trigger is synchronized with the trigger switch, the read time configured for normal reading will be used for auto trigger read time. -
Page 71: Read Mode Settings Continued
Read Mode Settings Continued: ,Y0, read time 0 second ,Y1, read time 1 second ,Y2, read time 2 seconds default ,Y3, read time 3 seconds ,Y4, read time 4 seconds ,Y5, read time 5 seconds Normal Read Time ,Y6, read time 6 seconds ,Y7, read time 7 seconds ,Y8,... -
Page 72: Read Mode Settings Continued
Read Mode Settings Continued: ,XA, disable add-on wait more default ,XB, add-on wait mode = 0.25 seconds Add-on Delay Timer ,XC, add-on wait mode = 0.50 seconds ,XD, add-on wait mode = 0.75 seconds Since WPC-type codes (UPC, EAN) with add-on (supplements) have a high probability of unsuccessful decoding, the scanner repeats decoding the add-on code during the specified period of time. -
Page 73: Imager Settings
Imager Settings: ,D3A, disable LED illumination ,D39, Illumination Mode enable LED illumination default ,D3B, LED illumination alternating ,D3C, disable laser aiming and LED illumination ,D3D, Aiming On/Off enable laser aiming default ,D3E, disable laser aiming enable central reading ,D00, (read only a code that the laser aims at) Central Reading disable central reading ,D0Z,...
