Defining SNMP views
NOTE
All MIB objects are automatically excluded from any view unless they are explicitly included;
therefore, when creating views using the snmp-server view command, indicate which portion of the
MIB you want users to access.
For example, you may want to assign the view called "admin" a community string or user group. The
"admin" view will allow access to the Brocade MIBs objects that begin with the 1.3.6.1.4.1.1991
object identifier. Enter the following command.
BigIron RX
You can exclude portions of the MIB within an inclusion scope. For example, if you want to exclude
the snAgentSys objects, which begin with 1.3.6.1.4.1.1991.1.1.2 object identifier from the admin
view, enter a second command such as the following.
BigIron RX
Note that the exclusion is within the scope of the inclusion.
To delete a view, use the no parameter before the command.

SNMP v3 configuration examples

The examples below shows how to configure SNMP v3.
Simple SNMP v3 configuration
BigIron RX(config)#snmp-server group admingrp v3 priv read all write all notify
all
BigIron RX(config)#snmp-server user adminuser admingrp v3 auth md5 admin priv
admin1
BigIron RX(config)#snmp-server host 10.3.1.44
More detailed SNMP v3 configuration
BigIron RX(config)#snmp-server view internet internet included
BigIron RX(config)#snmp-server view system system included
BigIron RX(config)#snmp-server community ..... ro
BigIron RX(config)#snmp-server community ..... rw
BigIron RX(config)#snmp-server contact isc-operations
BigIron RX(config)#snmp-server location sdh-pillbox
BigIron RX(config)#snmp-server host 128.91.255.32 .....
BigIron RX(config)#snmp-server group ops v3 priv read internet write system
BigIron RX(config)#snmp-server group admin v3 priv read internet write internet
BigIron RX(config)#snmp-server group restricted v3 priv read internet
BigIron RX(config)#snmp-server user ops ops v3 encrypted auth md5
ab8e9cd6d46e7a270b8c9549d92a069 priv encrypted des
0e1b153303b6188089411447dbc32de
BigIron RX(config)#snmp-server user admin admin v3 encrypted auth md5
0d8a2123f91bfbd8695fef16a6f4207b priv encrypted des
18e0cf359fce4fcd60df19c2b6515448
BigIron RX(config)#snmp-server user restricted restricted v3 encrypted auth md5
261fd8f56a3ad51c8bcec1e4609f54dc priv encrypted des
d32e66152f89de9b2e0cb17a65595f43k
1010
(config)# snmp-server view admin 1.3.6.1.4.1.1991 included
(config)# snmp-server view admin 1.3.6.1.4.1.1991.1.1.2 excluded
