Multiple paths, DEK cluster, no HA cluster

Multiple paths, DEK cluster, no HA cluster

Figure 95
There is one encryption switch in each fabric.
FIGURE 95
The configuration details are as follows:
•
•
•
•
•
•
•
206
shows a configuration with a DEK cluster with multiple paths to the same target device.
Management Link
CTC2
Encryption
Switch 1
4 CTC1
C T C
IO Sync Link
Multi-path, DEK cluster, no HA cluster
There are two fabrics.
There are four paths to the target device, two paths in each fabric.
There are two host ports, one in each fabric.
Host port1 is zoned to target port1 and target port2 in fabric 1.
Host port2 is zoned with target port 3 and target port 4 in fabric 2.
There are two encryption switches, one in each fabric (no HA cluster).
There is one DEK Cluster and one encryption group.
Management
Network
LAN
Management Link
Host
Host Port 2
Host Port 1
Fabric1 Fabric2
Target
Target
Port 2
Port 3
Target Target
Port 1 Port 4
Target
Dedicated Cluster
Network
LAN
Fabric OS Encryption Administrator's Guide (SKM/ESKM)
Ecryption Group
Encryption
Switch 2
IO Sync Link
53-1002721-01
CTC3
CTC4
CTC4
