6-22 Minitower Repair

Illustrated Parts Breakdown

This subsection contains the illustrated parts breakdown (IPB) and NEC part numbers for
the PowerMate P60 minitower computer. Table Section 6-3 lists the field-replaceable parts
for the computer. Figure Section 6-11 is the illustrated parts breakdown.
Table Section 6-3 PowerMate P60 Minitower Field-Replaceable Parts List*
Item Description
1 NEC Mouse (PS/2-compatible)
2 Power Cord
3 Heatsink for the 60 MHz Pentium
4 60 MHz Pentium
5 System Board (without CPU)
6 ISA/PCI-Bus Backboard
7 Bottom Cover
8 Chassis Support Bracket
9 3 1/2-inch Drive Cage
10 Cover Lock and Key
11 3 1/2-inch x 1-inch, 420-MB Hard Disk
12 Hard Disk Drive IDE Signal Cable
13 Minitower Chassis
14 Top Cover
15 Power Supply
16 5 1/4-inch Metal Blank Panel Cover (3)
17 Power Lamp, Hard Disk Drive Busy Lamp, and
Reset Button Assembly
18 5 1/4-inch Plastic Blank Panel (3)
19 Diskette Drive Signal Cable
20 3 1/2-inch x 1-inch, 1.44-MB Diskette Drive
____________
*This data was prepared June 1994. For an up-to-date listing of spare parts, please call FastFacts (800) 366-0476 and
order document number 42180994.
NOTE: In the U.S., call 1(800) 632-4525 to
order NEC spare parts. To order options in the
U.S., call your local sales office.
Part Number
158-050484-002
158-050697-000
158-060279-000
802-148518-012A
158-050723-000A
158-050724-000A
158-050705-108
158-050705-008
158-050705-010
158-050705-003
158-050395-320
158-050324-001
158-050705-109
158-050705-001
158-050684-000
158-050705-012
158-050705-102
158-050705-011
158-050561-000
808-870954-101A
