ISA/PCI-Bus Backboard Removal

Remove the ISA/PCI-Bus backboard as follows.
1. Remove the top cover and all expansion slot boards as previously described.
Remove the two chassis support bracket screws (see Figure Section 6-5).
2.
Pull the backboard and bracket out of the system unit.
3.
Bracket Screw
(not shown)
Chassis Support Bracket
Figure Section 6-5 Chassis Support Bracket Screws
Minitower Repair
Bracket Screw
6-19
