6-12 Minitower Repair

5 1/4-Inch Device Removal

Remove a 5 1/4-inch device from the 5 1/4-inch device cage as follows.
1. Remove the top cover, front panel, and 5 1/4-inch device cage as previously de-
scribed.
Remove the four 5 1/4-inch hard disk drive screws; two on each side (see
2.
Figure Section 6-12).
Remove the device out of the 5 1/4-inch device cage.
3.
2 of 4 Device
Screws
Figure Section 6-12 5 1/4-Inch Device Screws
Device
Cage
