Compaq Deskpro 2000 Series Reference Manual page 122

-16
6 Upgrading the Minitower Computer
To install a memory module, complete the following steps:
1. Remove the computer cover as described in the section
"Removing the Computer Cover."
2. Insert a memory module at a 45-degree angle into a
memory socket on the system board.
Installing a Memory Module
A memory module can be installed in only one way. Match the
notch on the module with the tab on the memory socket. Push
the module down into the socket, ensuring that the module is
fully inserted and properly seated.
3. Rotate the module gently to an upright position, allowing
the latches to snap into place.
4. Repeat steps 2 and 3 for each module that you want to
install.
5. Replace the computer cover.
6. Your computer will recognize system memory upgrades
and will automatically reconfigure the computer. If, for
some reason, the memory upgrades do not configure
correctly, you will need to run Computer Setup to
reconfigure the computer. Refer to Chapter 3, "Using
Compaq Utilities," for information on running Computer
Setup.
7. Test the system (optional) using the Computer Checkup
(TEST) utility. Refer to Chapter 3, "Using Compaq
Utilities."
