Page 1 All Rights Reserved Printed in Canada Information is subject to change without notice. Nortel Networks reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant. This equipment has been tested and found to comply with the limits of a Class A digital device pursuant to Part 15 of the FCC rules and the radio interference regulations of Industry Canada.
Page 3 Page 3 of 302 Revision history August 2000 Preliminary 0.10. July 2000 Preliminary 0.09. For controlled release only. June 2000 Preliminary 0.08. Released for beta. May 2000 Preliminary 0.07. Reflects project team’s written comments. May 2000 Preliminary 0.06. Reflects project team’s written comments. April 2000 Preliminary 0.05.
Page 4 Page 4 of 302 553-3001-204 Preliminary 0.10 August 2000...
Page 5: Table Of Contents
Page 5 of 302 Contents About this document ..... . . Description ....... . Contents .
Page 6 Page 6 of 302 Contents X11 system software requirements ......i2004 Internet Telephone firmware requirements ....System Resources .
Page 7 Contents Page 7 of 302 Configuration of the DHCP server ... . . Contents ..........Overview .
Page 8 Page 8 of 302 Contents Manual first-time i2004 Internet Telephone installation ... Automatic first-time installation of an i2004 Internet Telephone ..i2004 Internet Telephone power cycle description ....Reinstall an i2004 Internet Telephone .
Page 9 Contents Page 9 of 302 Verify ITG card software and firmware ......Access the command line from MAT ......Adding a “dummy”...
Page 10 Page 10 of 302 Contents Reliability ..........Environmental specifications .
Page 11: About This Document
Page 11 of 302 About this document This document describes the physical and functional characteristics of the Meridian Internet Telephony Gateway Line 2.0 (NTZC80) card and the i2004 Internet Telephone (NTEX00). The document also explains how to engineer, install, configure, administer and maintain a network node that contains the Meridian Internet Telephony Gateway Line 2.0 card and the i2004 Internet Telephone in Meridian 1 large and small systems.
Page 12 Page 12 of 302 About this document 553-3001-204 Preliminary 0.10 August 2000...
Page 13: Description
Page 13 of 302 Description Contents This section contains information on the following topics: Reference list ..........Overview .
Page 14: Reference List
2.0 card and the optional DHCP server. Figure 1 on page 15 shows a system block diagram. Applicable systems The ITG Line 2.0 card is supported on Meridian 1 large and small systems. Meridian ITG line 2.0 is not supported on the following products: • Carrier Remote •...
Page 15: System Requirements
Description Page 15 of 302 Figure 1 System block diagram System Overview Remote MAT/OTM DHCP • Fiber Remote • Fiber Remote Multi-IPE System requirements The ITG Line 2.0 card requires the following software: • X11 Release 25.30 or later software •...
Page 16: Required Packages
Page 16 of 302 Description ITG Line-side software and related documentation such as General Release Bulletins can also be downloaded from the Meridian 1 Electronic Software Distribution (ESD) web site at: http://www.nortelnetworks.com/servsup/esd/meridian/ For additional information on registering for access to the M1ESD site, please refer to the Generic X11 Release 25 Software Product Bulletin.
Page 17: Itg Line 2.0 And I2004 Internet Telephone Package Components List
Component Code Meridian ITG - Line 2.0 Systems Package. Includes NTZC81AA Meridian ITG Line 2.0 card (contains G.711, G729A and G.729AB codecs), ITG Lineside 2.0 software CD-ROM, cables, M1 Backplane to 50-pin I/O Panel Mounting Connector, NTP CD-ROM Meridian ITG Line 2.0 card assembly and required...
Page 18 Page 18 of 302 Description Table 2 Meridian ITG Line 2.0 package components Component Code ISM Parameter - For a single i2004 Internet Telephone NTZC84AA (Small System) A0808998 M1 Backplane to 50 Pin I/O Panel Mounting connector NTCW84JA with ITG specific filtering...
Page 19: Ordering Rules For Itg Line 2.0
Description Page 19 of 302 Ordering rules for ITG Line 2.0 An ITG Line 2.0 node requires: • one NTZC81AA Meridian ITG - Line 2.0 systems package. • one NTEX00BA i2004 Internet Telephone boxed package. Marketing packages contain 24-port ITG Line 2.0 card with G.711, G.729AB, G.729B codecs, IP Lineside software and NTP CD-ROM.
Page 20: I2004 Internet Telephone Physical And Functional Description
Page 20 of 302 Description i2004 Internet Telephone physical and functional description The i2004 Internet Telephone translates voice into data packets for transport using Internet Protocol. A Dynamic Host Configuration Protocol (DHCP) server can be used to provide information that enables the i2004 Internet Telephone network connection, and connection to the Internet Telephony Gateway Line 2.0 card.
Page 21: Itg Line 2.0 Card Physical Description
Description Page 21 of 302 ITG Line 2.0 card physical description The ITG Line 2.0 card (NTZC80AA) plugs into an Intelligent Peripheral Equipment (IPE) shelf. Each ITG Line 2.0 card occupies two slots. ITG Line 2.0 cards have an E-LAN management Ethernet port (10BaseT) and a T-LAN VoIP Ethernet port (10/100BaseT) on the I/O panel.
Page 22 Page 22 of 302 Description Figure 3 ITG Line 2.0 card Ethernet Voice Port LED (card status) ITG-P Reset Switch Reset Status NWK LEDs (Ethernet) Type III PCMCIA slot (ATA Drive A:) Four-character LED-based Matrix Maintenance Display NTVQ55AA RS-232 Maint Inboard: Port Maintenance Port...
Page 23 Description Page 23 of 302 • Yellow - flashes when there is T-LAN data activity. During heavy traffic, yellow can stay continuously lit. Note: There are no Ethernet status LEDs for the E-LAN management interface. PC Card slots The ITG Line 2.0 card has one faceplate PC card slot (designated drive A:). It is used for optional maintenance (backup and restore).
Page 24: Itg Line 2.0 Card Functional Description
Page 24 of 302 Description Assembly description The ITG Line 2.0 card assembly consists of a two-slot motherboard/ daughterboard combination. A PCI interconnect board connects the ITG motherboard and the DSP daughterboard. ITG Line 2.0 card functional description The ITG Line 2.0 card performs two separate functions: It acts as a gateway between the Time Division Multiplexing (TDM) voice switching network and the IP network.
Page 25 Description Page 25 of 302 The concentration of i2004s Telephones is made possible by dynamically allocating a port (also referred to as a Physical TN) of the ITG card for a TDM – i2004 call. All Meridian 1 speech path management is done with Physical TNs instead of the Virtual TNs.
Page 26: Codecs
Page 26 of 302 Description Interactions with i2004 Internet Telephone When you add an i2004 Internet Telephone to the network, the telephone sends a request to the DHCP server identifying itself as an i2004 Internet Telephone and requests IP parameters and a Connect Server address. The i2004 Internet Telephone then contacts the Connect Server which instructs the i2004 Internet Telephone to display a message on its display screen requesting the customer’s node number and TN.
Page 27: Unistim Description
Meridian 1 CPU and the ITG Line 2.0 cards, and for T-LAN communications between the ITG Line 2.0 cards and the i2004 Internet Telephones. RUDP is another layer on top of UDP. RUDP is proprietary to Nortel Networks. RUDP features: •...
Page 28: Administration
Page 28 of 302 Description Zones To optimize ITG traffic bandwidth use between different locations, the ITG network is divided into “zones" representing different topographical areas of the network. All i2004 Internet Telephone and ITG ports are assigned a zone number indicating which zone they belong to.
Page 29: Supported Features
Description Page 29 of 302 With a CLI session established, you can enter the Leader card IP address. MAT/OTM uses the card IP address to carry out configuration and software download functions. Supported features The i2004 Internet Telephone supports the full Meridian digital set feature compliment available on the M2000 series telephones.
Page 30 Page 30 of 302 Description However, some of the new features available on the M3900 series are not currently supported on the i2004 Internet Telephone. Specific features not available include: • Personal Directory • Call Log and redial List • Expansion Modules •...
Page 31: I2004 Internet Telephone Restricted Keys
Description Page 31 of 302 i2004 Internet Telephone restricted keys Table 4 describes the specific telephone assignment functions you can program for Keys 16-26 on the i2004 Internet Telephone using Overlay 11. Note: If you attempt to configure anything other than the permitted response, Meridian 1 generates an error code.
Page 32 Page 32 of 302 Description i2004 Internet Telephone Response(s) Allowed number Key 24 PRS, NUL PRS - Privacy Release key. Key 25 CHG, NUL CHG - Charge Account key. Key 26 CPN, NUL CPN - Calling Party Number key. 553-3001-204 Preliminary 0.10 August 2000...
Page 33: Meridian 1 Capacity Engineering Guidelines
Page 33 of 302 Meridian 1 capacity engineering guidelines Contents This section contains information on the following topics: Overview ..........X11 system software requirements .
Page 34: Overview
Page 34 of 302 Meridian 1 capacity engineering guidelines IP address requirements for the Line 2.0 card ..... 44 Node IP requirements ........44 ITG Line card IP address requirements .
Page 35: X11 System Software Requirements
Meridian 1 capacity engineering guidelines Page 35 of 302 X11 system software requirements The ITG Line 2.0 and i2004 Internet Telephone requires X11 Release 25.30 software (or later). Table 5 lists the X11 software package requirements. Table 5 X11 software package requirements Package Package Package description...
Page 36: I2004 Internet Telephone Firmware Requirements
Page 36 of 302 Meridian 1 capacity engineering guidelines i2004 Internet Telephone firmware requirements The i2004 Internet Telephone has field upgradable firmware. A copy of this firmware is stored on each ITG Line 2.0 card in the system to automatically upgrade i2004 sets if an upgrade is required.
Page 37: System Resources
Meridian 1 capacity engineering guidelines Page 37 of 302 The next step is to select each ITG Line 2.0 card in turn, and upgrade the firmware with the latest firmware file downloaded form the web. IMPORTANT Refer to Procedure 23 at this point, for the actual steps required to complete this firmware installation.
Page 38: Capacity Engineering Considerations
Page 38 of 302 Meridian 1 capacity engineering guidelines Capacity engineering considerations • Number of sets per system: — Option 11C or 11C Mini - 640 — Large Systems - limit is determined by engineering of real time usage, traffic capacity and IPE slot usage. •...
Page 39 Meridian 1 capacity engineering guidelines Page 39 of 302 If an i2004 Internet Telephone is unplugged, it will automatically become un-registered after a pre-determined time-out. This limitation on simultaneous calls depends not on the number of ports, but on the number and type of calls.
Page 40: I2004 Set Engineering
Page 40 of 302 Meridian 1 capacity engineering guidelines i2004 Set Engineering Traffic and Service Circuits i2004 sets are engineered similar to existing digital sets (based upon 3500 CCS per Virtual Loop). TDS/Conference circuits are provisioned like existing digital sets (one TDS/CONF card per half group of i2004 sets). The recommendation is to use 5 ITG cards per shelf.
Page 41: Real Time Factors
Meridian 1 capacity engineering guidelines Page 41 of 302 Table 1 ITG card recommendations based on CCS capacity i2004 Internet Telephone blocking probability is 0.005 Number of ITG cards Capacity CCS 11818 12657 13496 14335 15177 16020 Note 1: CCS is the number of hundred call seconds per hour Note 2: If the number of ITG Line 2.0 card exceeds 20, add 801 CCS to the total capacity for each additional card.
Page 42: Specifications
Page 42 of 302 Meridian 1 capacity engineering guidelines The total real time capacity of the Meridian 1 depends on many factors such • calling patterns • feature operations • set and trunk signalling • system CPU capacity These factors are used to provision the maximum number of i2004 Internet Telephones supported on specific Meridian 1 system types.
Page 43: Environmental Specifications
Meridian 1 capacity engineering guidelines Page 43 of 302 Environmental specifications Table 7 shows the environmental specifications of the ITG Line 2.0 card. The ITG line card provides external interface protection to -52 V dc, but does not provide lightning or hazardous voltage protection. Table 8 shows the environmental specifications of the i2004 Internet Telephone.
Page 44: Ip Address Requirements For The Line 2.0 Card
Separate subnet Node IP address requirements Figure 4 on page 45 shows an example of the ITG Node General tab with IP addresses configured for separate subnets. Nortel Networks recommends that you accept the default configuration of separate subnets. The terms in the bullet list below are the terms used to define the fields in the MAT/OTM application.
Page 45 Node IP address requirements example (separate subnets) Single subnet Node IP address requirements Note: Nortel Networks strongly recommends using separate subnets with the ITG Line 2.0/i2004. Figure 5 on page 46 shows an example of the ITG Node General tab with IP addresses configured for separate subnets.
Page 46 Page 46 of 302 Meridian 1 capacity engineering guidelines • Management subnet mask addressE-LAN Figure 5 Node IP address requirements example (single subnet) 553-3001-204 Preliminary 0.10 August 2000...
Page 47: Itg Line Card Ip Address Requirements
Meridian 1 capacity engineering guidelines Page 47 of 302 ITG Line card IP address requirements The IP address information for each card is set in the Configuration tab of the ITG IP Phones application. The IP address requirements for each card depend on the Node subnet option.
Page 48: I2004 Internet Telephone Ip Address Requirements
Page 48 of 302 Meridian 1 capacity engineering guidelines Figure 6 Separate subnet node configuration example i2004 Internet Telephone IP address requirements Each i2004 Internet Telephone requires an IP address. The i2004 Internet Telephone also requires information about subnet masks, IP default gateway (router) for the i2004 Internet Telephone LAN segment and other network configuration parameters.
Page 49 Meridian 1 capacity engineering guidelines Page 49 of 302 Figure 7 Single subnet node configuration ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 50: Equipment Considerations
Optional equipment • A server configured with Dynamic Host Configuration Protocol (DHCP). For example, you can use a Nortel NetID server. • External modem router (recommended Bay Networks Netgear RM356) to allow remote dial-up connection to E-LAN for technical support.
Page 51: Identify The Ipe Card Slots
Meridian 1 capacity engineering guidelines Page 51 of 302 For Option 11C or 11C MiniC systems, the standard I/O filter connector already supports 100BaseTX. Refer to “Install NTCW84JA Large System ITG-specific I/O Panel Filter Connector” on page 115 for installation instructions.
Page 52: Product Compatibility With Other Itg Products
Meridian 1 capacity engineering guidelines Product compatibility with other ITG products Nortel Networks manufactures three Voice Over IP (VoIP) products in addition to ITG Line 2.0. This section explains how the ITG Line 2.0 card relates to the ITG products listed below: •...
Page 53: Itg Card Cpu Resources
Meridian 1 capacity engineering guidelines Page 53 of 302 Each ITG Line 2.0 card requires 24 physical TNs. You configure the physical units in Overlay 14. ITG card CPU resources The i2004 Internet Telephones share the CPU resources of the ITG cards. Each i2004 Internet Telephone is controlled by one of the ITG Line 2.0 cards.
Page 54 Page 54 of 302 Meridian 1 capacity engineering guidelines When you configure the ITG Line 2.0 card, you select two codecs - a high-quality Codec and a bandwidth-efficient Codec. Figure 8 on page 54 shows the list of supported codecs. The ITG Line 2.0 product supports A-law and Mu-law.
Page 55: Ip Network Engineering Guidelines
Page 55 of 302 IP Network engineering guidelines Contents This section contains information on the following topics: IP network assessment procedure ......Calculate ITG traffic requirements .
Page 56: Overview
Page 56 of 302 IP Network engineering guidelines Overview This chapter provides guidelines and recommendations to help plan, engineer, and test the ITG Line 2.0 card/i2004 Internet Telephone network. See “Configuration of the DHCP server” on page 97, for engineering guidelines to set and configure the Dynamic Host Configuration Protocol (DHCP) server to support the ITG Line 2.0 card and i2004 Internet Telephone.
Page 57: Calculate Itg Traffic Requirements
IP Network engineering guidelines Page 57 of 302 Provide the necessary IP network infrastructure: — 10baseT or 100baseT Ethernet connection. — IP address. Each ITG Line 2.0 card requires 10baseT E-LAN or 10/100baseT T-LAN unicast IP address. — One additional IP address per node. The node IP address will be on the T-LAN if using separate subnets or on the E-LAN if using a single subnet.
Page 58 Page 58 of 302 IP Network engineering guidelines Figure 9 T-LAN and E-LAN Topology T-LAN / E-LAN Topology DS30X E-LAN T-LAN Meridian 1 ITGL Card (in IPE Shelf) DHCP MAT/OTM For a more thorough assessment, the technician must consider the impact of incremental ITG Line 2.0 traffic on routers and LAN resources in the intranet.
Page 59 IP Network engineering guidelines Page 59 of 302 Figure 10 Bandwidth management example Zone 1 Zone 2 Kbps Kbps Kbps Remote Zone Table Zone Intrazone Interzone 1 BQ: 100,000 BB: 500 2 BQ: 10,000 BB: 128 3 BQ: 10,000 BB: 500 Two Codecs Can Be Configured Zone 3 One for Best Quality - e.g.
Page 60: T-Lan Traffic Calculations
Page 60 of 302 IP Network engineering guidelines T-LAN traffic calculations To calculate the total T-LAN requirement, add together all sources of traffic destined for the IP telephony network using the same LAN. The data rate for a T-LAN is the total bit rate. Procedure 2 T-LAN traffic calculation procedure Total subnet traffic = Number of i2004 Internet Telephones ×...
Page 61: T-Lan Engineering Example
IP Network engineering guidelines Page 61 of 302 Table 10 T-LAN and WAN IP bandwidth usage per ITG Line 2.0 card port (silence suppression enabled) T-LAN Frame Voice Ethernet bandwidth bandwidth Codec duration payload packet frame usage usage type payload (bytes) (bytes) (bytes)
Page 62: Assess Wan Link Resources
Page 62 of 302 IP Network engineering guidelines Subnet B: 72 i2004 Internet Telephones, average 5 CCS/i2004 Internet Telephone. Subnet B total erlangs = 72 × 5 / 36 = 10 Subnet B bandwidth = 10 × 25.6 = 256 Subnet C: 12 i2004 Internet Telephones, average 6 CCS/i2004 Internet Telephone.
Page 63 IP Network engineering guidelines Page 63 of 302 Find WAN bandwidth usage (kbit/s) from Table 10. Note: Table 10 on page 61 lists the Ethernet and WAN bandwidth usage of IP Line ports with the 729AB codec only. Bandwidth per subnet = total erlangs × WAN bandwidth usage. Multiply bandwidth per subnet ×...
Page 64: Ip Voice Zones
Page 64 of 302 IP Network engineering guidelines — Subnet B WAN bandwidth with 30% peaking = 93 × 1.3 = 120.9 kbit/s. — Subnet C: 12 i2004 Internet Telephones, average 6 CCS/i2004 Internet Telephone. — Total erlangs = 12 × 6/36 = 2 —...
Page 65: Relationship Between Zones And Domains
IP Network engineering guidelines Page 65 of 302 • p2 - The preferred strategy for the choice of codec for intrazone calls (that is, preserve voice quality or preserve bandwidth) • p3 - The total bandwidth available for interzone calls •...
Page 66 Page 66 of 302 IP Network engineering guidelines Assess how much spare capacity is available. Enterprise intranets are subject to capacity planning policies that ensure that capacity usage remains below some determined utilization level. For example, a planning policy might state that the utilization of a 56 kbps link during the peak hour must not exceed 50%;...
Page 67: Estimating Network Loading Due To Itg Traffic
IP Network engineering guidelines Page 67 of 302 Figure 11 An ITG intranet with subnetworks Meridian 1 ITG Line 2.0 Card Node 1 i2004 Subnet i2004 Enterprise Intranet/WAN (Corporate IP network) Subnet Subnet i2004 Zone 2 Zone 1 i2004 553-5560 Estimating network loading due to ITG traffic At this point, the technician has enough information to “load”...
Page 68: Decision: Sufficient Capacity
Page 68 of 302 IP Network engineering guidelines To complete this example, the traffic flow from the ITG node to all routes needs to be summed to determine the load to the link (T-LAN). Decision: Sufficient capacity? A link is defined as the route between the ITG Line 2.0 card node and a subnet.
Page 69: Set Service Parameters
IP Network engineering guidelines Page 69 of 302 Set service parameters Quality of Service (QOS) mechanism QOS is controlled by setting the DiffServ field in the IP header for both the ITG Line Card and the i2004 Internet Telephone. This can be set to a value between 0 and 255 using MAT 6.6/OTM 1.0.
Page 70 Page 70 of 302 IP Network engineering guidelines End-to-end delay and error characteristics of the intranet must be measured so that the technician can set realistic QOS expectations for intranet voice services. The use of measuring tools requires a starting node and a destination node. The starting node can be a “PING”...
Page 71 IP Network engineering guidelines Page 71 of 302 Both PING and traceroute are basic measuring tools that can be used to assess the ITG network. They are standard utilities that come with most commercial operating systems. PING is used to measure the round trip delay of a packet and the percentage of packet loss;...
Page 72 Page 72 of 302 IP Network engineering guidelines Sample PING output: ITG_Node1% PING -s subnetA 60 PING subnetA (10.3.2.7): 60 data bytes 68 bytes from (10.3.2.7): icmp_seq=0 ttl=225 time=97ms 68 bytes from (10.3.2.7): icmp_seq=0 ttl=225 time=100ms 68 bytes from (10.3.2.7): icmp_seq=0 ttl=225 time=102ms 68 bytes from (10.3.2.7): icmp_seq=0 ttl=225 time=97ms...
Page 73 IP Network engineering guidelines Page 73 of 302 Assessment of sample PING output Note: The round trip time (rtt) is indicated by the time field. Notice the variation of rtt from the PING output. It is from repeated sampling of rtt that a delay characteristic of the intranet can be obtained. In order to obtain a delay distribution, the PING tool can be embedded in a script which controls the frequency of the PING probes, timestamps and stores the samples in a raw data file.
Page 74 Page 74 of 302 IP Network engineering guidelines r6 (10.8.0.1) 1 ms 1 ms 1 ms r5 (10.18.0.2) 42 ms 44 ms 38 ms r4 (10.28.0.3) 78 ms 70 ms 81 ms r1 (10.3.0.1) 92 ms 90 ms 101 ms subnetA (10.3.2.7) 94 ms 97 ms 95 ms...
Page 75 IP Network engineering guidelines Page 75 of 302 Late packets Packets that arrived outside of the window allowed by the jitter buffer are discarded by the ITG. To determine which PING samples to ignore, first calculate the average one-way delay based on all the samples. To calculate late packets, double the value of the nominal jitter buffer setting.
Page 76 Page 76 of 302 IP Network engineering guidelines At the end of this measurement and analysis, the technician has a good indication of whether or not the corporate intranet can deliver adequate voice service. Looking at the “Expected QOS level” column in Table 12 on page 75, the technician can gauge the QOS level for each site pair.
Page 77 To limit the size of this table, the packet loss and one-way delay values are tabulated in increments of 1% and 10ms respectively. The techniques used to determine and apply the information in this table are proprietary to Nortel Networks. Table 13 ITG QOS levels (Part 1 of 4)
Page 78 Page 78 of 302 IP Network engineering guidelines Table 13 ITG QOS levels (Part 2 of 4) Packet One-way QOS level loss (%) delay (ms) G.729A G.711A/G.711u G.723.1 350-360 fair good fair 370-630 fair fair fair 640-690 fair fair poor 700-780 poor fair...
Page 79 IP Network engineering guidelines Page 79 of 302 Table 13 ITG QOS levels (Part 3 of 4) Packet One-way QOS level loss (%) delay (ms) G.729A G.711A/G.711u G.723.1 400-440 fair fair poor 50-180 good good good 190-210 good good fair 220-360 fair fair...
Page 80 Page 80 of 302 IP Network engineering guidelines Table 13 ITG QOS levels (Part 4 of 4) Packet One-way QOS level loss (%) delay (ms) G.729A G.711A/G.711u G.723.1 270-280 fair fair poor 50-250 fair fair fair 260-270 fair fair poor 50-230 fair fair...
Page 81 IP Network engineering guidelines Page 81 of 302 DiffServ/TOS The Type of Service (TOS) byte or Differentiated Service (DiffServ) code point determines the priorities of the management and voice packets in the ITG network. The range for both management and voice packet DiffServ/TOS is 0-255.
Page 82 Page 82 of 302 IP Network engineering guidelines To determine which links should be considered for upgrading, first list all the intranet links used to support the ITG traffic, which can be derived from the traceroute output for each site pair. Then, using the intranet link utilization report, note the highest utilized and/or the slowest links.
Page 83 IP Network engineering guidelines Page 83 of 302 The ITG Line 2.0 card node and the T-LAN router should be placed as close to the WAN backbone as possible in order to: • minimize the number of router hops. • segregate constant bit-rate Vo IP traffic from bursty LAN traffic.
Page 84 Page 84 of 302 IP Network engineering guidelines • LAN saturation. Packets may be dropped on under-engineered or faulty LAN segments. • Jitter buffer too small. Packets that arrive at the destination ITG, but too late to be placed in the jitter buffer are essentially loss packets. Adjusting jitter buffer size The jitter buffer parameters directly affect the end-to-end delay.
Page 85 IP Network engineering guidelines Page 85 of 302 Post-installation network measurements The design process is continual, even after implementation of the ITG network and commissioning of voice services over the network. Network changes – in actual ITG traffic, general intranet traffic patterns, network policies, network topology, user expectations and networking technology –...
Page 86: Select Subnet Configuration
Page 86 of 302 IP Network engineering guidelines OM Report description The OM log file is a comma-separated (.csv) file stored on the MAT 6.6/OTM 1.0 PC. Using MAT/OTM you can run an adhoc report or schedule a regular report. A new file is created for each month of the year in which OM data is collected.
Page 87: Single Subnet Configuration
E-LAN, which can be isolated from the customer's enterprise network (C-LAN), or have access to and from the C-LAN only through a fire-wall router. Note 1: Nortel Networks strongly recommends that customers place the voice and management LANs on separate dedicated subnets, separated by a router.
Page 88 Page 88 of 302 IP Network engineering guidelines 553-3001-204 Preliminary 0.10 August 2000...
Page 89: Installation And Configuration Summary
Page 89 of 302 Installation and configuration summary Contents This section contains information on the following topics: Overview ..........Before you begin .
Page 90: Before You Begin
Page 90 of 302 Installation and configuration summary Before you begin Upgrade Meridian 1 X11 software to Release 25.30 or later. Upgrade the M1 keycodes to expand the ISM system limit to support the number of i2004 Internet Telephones you plan to install. Refer to Overlay 22 in the M1 System Maintenance Guide (553-3001-511).
Page 91: Installation Procedure Summary
Installation and configuration summary Page 91 of 302 Installation procedure summary Summary of steps The following summary of steps can be used as a reference guide to install and configure an ITG Line 2.0 card node. This summary is intended to serve as a pointer to the more detailed procedures contained in other chapters and to provide a sequential flow to the steps involved in the overall installation procedure.
Page 92 Page 92 of 302 Installation and configuration summary Configure ITG line card properties. Refer to Procedure 10 on page 131. Configure DSP Profile data. Refer to Procedure 11 on page 134. Configure E-LAN IP address and T-LAN Voice port. Refer to Procedure 12 on page 135.
Page 93: Itg Line 2.0 Card Installation Summary Sheet
Page 93 of 302 ITG Line 2.0 card installation summary sheet Nortel Networks recommends that you complete an ITG Line 2.0 card installation summary sheet (Table 14) as you unpack, inventory and provision the cards. IP information will normally be supplied by the customer’s IP Network Administrator.
Page 94 Page 94 of 302 Installation and configuration summary Table 14 ITG Line 2.0 card installation summary sheet Site________________________M1 system_____________________M1 customer______ Node ID______ T-LAN Node IP address________________________M1 active ELNK IP address____________ SNMP Manager List IP addresses________________________ T-LAN subnet mask___________________________T-LAN gateway__________________ E-LAN subnet mask__________________________E-LAN gateway________________________ E-LAN Management T-LAN MAC address...
Page 95: I2004 Internet Telephone Configuration Data Summary Sheet
Installation and configuration summary Page 95 of 302 i2004 Internet Telephone configuration data summary sheet Table 15 i2004 Internet Telephone configuration data summary sheet IP configuration Connect User User Node# server IP Name Location subnet Gateway IP IP address address mask address ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 96 Page 96 of 302 Installation and configuration summary 553-3001-204 Preliminary 0.10 August 2000...
Page 97 Requested Network Configuration Parameters ....102 Format for Nortel Networks i2004 Internet Telephone DHCP Class Identifier Option ......... . . 104 Format for Nortel Networks i2004 Internet Telephone DHCP Encapsulated Vendor Specific Option .
Page 98 Meridian 1. It encodes voice as binary data and packetizes the data to transmit it over an IP Network to the ITG Line 2.0 card or to another i2004 Internet Telephone. The Nortel Networks i2004 Internet Telephone can act as a DHCP client in one of two modes: •...
Page 99 Configuration of the DHCP server Page 99 of 302 Full DHCP mode In full DHCP mode, the DHCP server requires special configuration. The i2004 Internet Telephone obtains network configuration parameters and also connect server configuration parameters from specially configured DHCP server.
Page 100: Itg Line 2.0 Card
Page 100 of 302 Configuration of the DHCP server Figure 12 DHCP block diagram The ITG Line 2.0 card contains: 1. The connect server 2. TPS resource master 3. The Terminal Proxy Server (TPS) 4. Firmware upgrade server 5. The media gateway The IP Network must have DHCP/bootp Relay Agents.
Page 101: Configuring Dhcp Server To Support Full Dhcp Mode
The i2004 Internet Telephone is designed with a unique class identifier that the DHCP server can use to identify the i2004 Internet Telephone. All i2004 Internet Telephones use the same text string, "Nortel-i2004-A", to identify itself. The ASCII string is sent inside the Class Identifier option of the i2004 Internet Telephone's DHCP messages.
Page 102: Requested Network Configuration Parameters
Page 102 of 302 Configuration of the DHCP server Requested Network Configuration Parameters Nortel's i2004 Internet Telephone has the ability to be configured automatically by an i2004 Internet Telephone-aware DHCP server by requesting a list of network configuration parameters. The i2004 Internet Telephone uses DHCP, an industry standard protocol, to request and receive the information.
Page 103 Configuration of the DHCP server Page 103 of 302 The first five parameters in Table 16 are standard DHCP options and have predefined option codes. The last parameter is for ITG Line 2.0 card information, which does not have a standard DHCP option. The server administrator must define a vendor encapsulated and/or site specific option to transport this information to the i2004 Internet Telephone.
Page 104: Format For Nortel Networks I2004 Internet Telephone Dhcp Class
All i2004 Internet Telephones fill in the Class ID option of the DHCP Discovery and Request messages with the null-terminated, ASCII-encoded string Nortel-i2004-A, where A identifies the version number of the i2004 Internet Telephone. The Class Identifier Nortel-i2004-A must be unique in the DHCP server domain.
Page 105 "Nortel-i2004-A,iii.jjj.kkk.lll:ppppp,aaa,rrr;iii.jjj.kkk.lll:pppp,aaa,rrr." where, "Nortel-i2004-A" - uniquely identifies that this is the Nortel option and is a response from a server that can provide the correct configuration information to the i2004 Internet Telephone. ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 106 (0x00..0xFF). Note that these fields must be no more than 3 digits long. First server is always considered "Primary", second server always considered "Secondary". If only one server is required, terminate primary TPS sequence immediately with "." instead of ";" for example, "Nortel-i2004-A,iii.jjj.kkk.lll:ppppp,aaa,rrr." 553-3001-204 Preliminary 0.10 August 2000...
Page 107 Configuration of the DHCP server Page 107 of 302 Valid options are one or two servers (0 or 3 is not allowed). However, it is recommended that the two server option be used. For i2004 Internet Telephone firmware version 3002B00, the valid option is two servers. Note: If there is only one connect server (i.e.
Page 108: Specific Option
Format for Nortel Networks i2004 Internet Telephone DHCP Site Specific Option The following definition describes the Nortel i2004 specific, Site Specific option. This option uses the "reserved for site specific use" DHCP options (128 to 254 - Refer to RFC 1541 and RFC 1533) and must be returned by the DHCP server as part of each DHCP OFFER and ACK message for the i2004 to accept these messages as valid.
Page 109 Configuration of the DHCP server Page 109 of 302 where, "Nortel-i2004-A" - uniquely identifies this as the Nortel option Additionally, the "-A" signifies the version. Future enhancements could use "-B" for example. ASCII "," is used to separate fields ASCII ";" is used to separate Primary from Secondary server info ASCII "."...
Page 110 Page 110 of 302 Configuration of the DHCP server Action code values: - reserved - UNIStim Hello (currently only this type is a valid choice) 2-254 - reserved - reserved iii,jjj,kkk,lll are ASCII encoded, decimal numbers representing the IP address of the server. They do not need to be 3 digits long as the. and : delimiters will guarantee parsing.
Page 111 Page 111 of 302 Installation and configuration of ITG Line 2.0 node Contents This section contains information on the following topics: Overview ..........112 Install the hardware components .
Page 112: Overview
Page 112 of 302 Installation and configuration of ITG Line 2.0 node Overview This chapter explains how to install and configure new ITG Line 2.0 nodes, cards and associated cables; configure and transmit ITG Line 2.0 data on Meridian 1 and MAT; upgrade ITG Line 2.0 card software; upgrade i2004 Internet telephone firmware.
Page 113: Install The Hardware Components
Installation and configuration of ITG Line 2.0 node Page 113 of 302 • Procedure 21, “Upgrade ITG Line card software from the web” on page 153 • Procedure 22, “Upgrade ITG card software by PC card” on page 155 • Procedure 23, “Upgrade i2004 Internet Telephone firmware”...
Page 114 Page 114 of 302 Installation and configuration of ITG Line 2.0 node Remove any existing I/O panel cabling associated with any card previously installed in the selected card slot. Pull the top and bottom locking devices away from the ITG Line 2.0 Leader 0 card faceplate.
Page 115: Install Ntcw84Ja Large System Itg-Specific I/O Panel Filter
Installation and configuration of ITG Line 2.0 node Page 115 of 302 Install NTCW84JA Large System ITG-specific I/O Panel Filter Connector Note: This NTCW84JA ITG-specific Filter Connector is not required on Option 11C and 11C Mini systems. CAUTION For large systems manufactured during the period of 1998-1999 and shipped in North America, the IPE modules have the NT8D81BA Backplane to I/O Panel ribbon cable assembly with a non-removable Filter Connector.
Page 116: Install The Ntmf94Ea E-Lan, T-Lan, Serial Interface Cable
Page 116 of 302 Installation and configuration of ITG Line 2.0 node Re-position the new NTCW84JA Filter Connector in the now vacant I/O panel opening. (See Figure 13 on page 116.) Attach the new NTCW84JA ITG-specific Filter Connector to the I/O panel by securely fastening the top back screw and the bottom front screw.
Page 117 Installation and configuration of ITG Line 2.0 node Page 117 of 302 Procedure 7 Installing the NTMF94EA E-LAN, T-LAN, serial interface cable IMPORTANT You must plug all IP Line card T-LAN interfaces belonging to the same ITG node into the same T-LAN hub. Plug all IP Line card E-LAN interfaces belonging to the same ITG node into the same E-LAN hub.
Page 118: Configure Itg Line 2.0 Data On The Meridian 1
553-3001-511). • Expand the ISM System Limit, if required, by ordering additional ISM Parameters (NTZC82AA). Refer to Table 2, “Meridian ITG Line 2.0 package components,” on page 17 and “Ordering rules for ITG Line 2.0” on page 19. Configure IP address for the M1 Ethernet Interface (LD 117)
Page 119: Configure Bandwidth Management Zones (Ld 117)
Installation and configuration of ITG Line 2.0 node Page 119 of 302 Verify your IP address for the Ethernet by entering the following command: PRT ELNK. Update DBS. Go to Overlay 137. Check the status of the Ethernet interface by entering the command: STAT ENLK.
Page 120 Page 120 of 302 Installation and configuration of ITG Line 2.0 node • p3 - The total bandwidth available for Interzone calls • p4 - The preferred strategy for the choice of the codec for Interzone calls Overlay 117 also includes DIS and ENL commands to disable or enable a zone.
Page 121: Configure Itg Physical Tns (Ld 14)
Installation and configuration of ITG Line 2.0 node Page 121 of 302 Table 18 LD 117 bandwidth management zones configuration => Command Description ENL ZONE xxx Allows user to enable a zone. PRT ZONE xxx Prints zone and bandwidth information. Configure ITG physical TNs (LD 14) Use LD 14 to define ITG card physical TNs.
Page 122: Configure Virtual Superloops For I2004 Internet Telephones (Ld 97)
Page 122 of 302 Installation and configuration of ITG Line 2.0 node Configure virtual superloops for i2004 Internet Telephones (LD 97) You must configure one or more virtual superloops to support i2004 Internet Telephones Virtual TNs (VTNs). Virtual superloops are distinct from phantom superloops and standard superloops and compete for network groups in physically and non-physically equipped network groups.
Page 123 Installation and configuration of ITG Line 2.0 node Page 123 of 302 Small system mapping of virtual superloops Up to 128 VTNs can be configured on a single virtual superloop for a small system, for a maximum number of 640 VTNs in each system. Mapping virtual superloops on a small system is the same as mapping phantom loops.
Page 124: Configure I2004 Meridian 1 Features (Ld11)
Page 124 of 302 Installation and configuration of ITG Line 2.0 node Configure i2004 Meridian 1 features (LD11) The existing ISM header that is printed at the start of Overlay 11 includes the new ISM limit for the i2004 Internet Telephone. Refer to Table 22 to configure the i2004 Internet Telephone in Overlay 11.
Page 125 Installation and configuration of ITG Line 2.0 node Page 125 of 302 Table 22 LD 11 Configure i2004 Internet Telephone (Part 2 of 2) Prompt Response Description aaaa ADD - Automatic Digit Display, default for i2004 Internet Telephone (HFD), HFA - Handsfree Denied, Allowed All default classes of service are: CLS CTD FBD WTA LPR MTD FND HTD ADD HFD GRLD MWD RMMD SMWD AAD IMD XHD IRD NID OLD...
Page 126: I2004 Internet Telephone Dedicated Soft Keys
Page 126 of 302 Installation and configuration of ITG Line 2.0 node i2004 Internet Telephone dedicated soft keys Table 23 describes the Meridian 1 features that can be assigned to dedicated soft Keys 16-26 on the i2004 Internet Telephone. Features that are not used can be removed from the dedicated soft keys.
Page 127 Installation and configuration of ITG Line 2.0 node Page 127 of 302 Table 23 LD 11 i2004 Internet Telephone dedicated soft key assignment (Part 2 of 2) i2004 Internet Telephone key Response(s) Allowed number Key 24 PRS, NUL PRS - Privacy Release key. Key 25 CHG, NUL CHG - Charge Account key.
Page 128: Configure Itg Line 2.0 Data On Mat/Otm
Page 128 of 302 Installation and configuration of ITG Line 2.0 node Configure ITG Line 2.0 data on MAT/OTM This section uses the MAT 6.67.07(with update disk)/OTM 1.0 (or later) ITG IP Phones Application to manually add and configure an ITG card node. Multiple ITG line 2.0 card nodes for i2004 Internet Telephones are configured and managed from the same MAT PC.
Page 129 Installation and configuration of ITG Line 2.0 node Page 129 of 302 Figure 14 IP Telephony Gateway - IP Phones main window Enter Network Connections data. For ITG line 2.0, you must check the option, "Use separate subnets for voice and management". CAUTION Using the single subnet option will cause unacceptable performance for ITG Line 2.0.
Page 130 Page 130 of 302 Installation and configuration of ITG Line 2.0 node Enter Management LAN subnet mask address (in dotted decimal format). Enter Voice LAN subnet mask address (in dotted decimal format). Click the Configuration tab. CAUTION Do not click OK at this point. If you click OK you will exit the General Tab Node properties configuration without saving any of the changes.
Page 131 Installation and configuration of ITG Line 2.0 node Page 131 of 302 Figure 15 New ITG Node General tab Configure ITG line card properties Procedure 10 Configure ITG Line 2.0 card properties If the IS Manager provides IP addresses and subnet masks in CIDR format, you must convert the data to dotted decimal format.
Page 132 Page 132 of 302 Installation and configuration of ITG Line 2.0 node Note 1: On the Configuration tab, you can Add, Change or Delete the ITG Line 2.0 cards in the node one at a time. Note 2: You cannot delete the Leader 0 card in the Configuration tab. You must delete the node in order to delete Leader 0.
Page 133 Installation and configuration of ITG Line 2.0 node Page 133 of 302 Figure 16 New ITG Node - Configuration tab Configure DSP profile data The following procedure uses the DSP Profile tab and its two sub-tabs to configure DSP profile data.The DSP Profile tab has two sub-tabs - General and Codec Options that are described briefly below.
Page 134 Page 134 of 302 Installation and configuration of ITG Line 2.0 node Loss and Level Plan - Determines parameters, such as transmission gain, that vary from country to country. The Loss and Level Plan values are stored in a file on the MAT/OTM PC. MAT/OTM reads the file to acquire the loss and level values for the selected country and places the values in a config.ini file on the ITG cards.
Page 135 Installation and configuration of ITG Line 2.0 node Page 135 of 302 Figure 17 New ITG Node DSP Profile tab (General tab) Configure E-LAN and T-LAN voice port Procedure 12 Configure E-LAN M1 IP address and T-LAN voice port Click on the Ports tab. Enter the E-LAN M1 IP address and T-LAN voice port (see Figure 18).
Page 136 Page 136 of 302 Installation and configuration of ITG Line 2.0 node Change the T-LAN voice port only as instructed by the IP network administrator to improve quality of service for Internet telephony. Note 1: The T-LAN voice port range is 1024-65535. The default voice ports are 5200 - 5295.
Page 137 Installation and configuration of ITG Line 2.0 node Page 137 of 302 Configure security for SNMP access This procedure explains how to change the SNMP community names to provide better security for the ITG node. MAT/OTM uses the community name password to refresh the ITG line card status, and to control the transmitting and retrieving of configuration data files for database synchronization.
Page 138 Page 138 of 302 Installation and configuration of ITG Line 2.0 node Figure 19 New ITG Node (Security tab) Configure SNMP traps Procedure 14 Configuring SNMP traps Click the SNMP traps tab in the Node Properties window. Check the "Enable SNMP traps" checkbox, if you are configuring one or more SNMP management IP addresses to receive SNMP traps from cards in the ITG line node.
Page 139 Installation and configuration of ITG Line 2.0 node Page 139 of 302 Note: A net route or host route through the management gateway is added to the ITG line cards IP Routing Table for each SNMP management address that is added to the SNMP traps list. To add a net route or host route through the management gateway for a management host which does not receive SNMP traps, type the IP address and subnet mask in the entry field of the card routing table,...
Page 140 Page 140 of 302 Installation and configuration of ITG Line 2.0 node Figure 20 SNMP traps/Routing and IPs tab Configure alarm notification features in MAT Procedure 15 Configuring MAT/OTM alarm notification feature In the MAT/OTM Navigator window menu, select Utilities | Alarm | Notification.
Page 141 Installation and configuration of ITG Line 2.0 node Page 141 of 302 Figure 21 Alarm Notification Run Options (General tab) ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 142 Page 142 of 302 Installation and configuration of ITG Line 2.0 node Click the Control Files tab. Figure 22 Alarm Notification Run Options (Control Files tab) 553-3001-204 Preliminary 0.10 August 2000...
Page 143 Installation and configuration of ITG Line 2.0 node Page 143 of 302 Click Devices | Browse. The "Open" dialog box appears. Figure 23 Open dialog box (Devices) ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 144 Page 144 of 302 Installation and configuration of ITG Line 2.0 node Select the "Devices.txt" file from the "Control Files" folder and click Open. The "Devices.txt" file opens. Figure 24 Devices.txt Notepad For each ITG Line 2.0 card in each monitored ITG Line 2.0 card node, add a line consisting of three fields separated by spaces, as shown in Table 24.
Page 145: Cards
Installation and configuration of ITG Line 2.0 node Page 145 of 302 Click File|Save As and save as ITGDevices.txt. In the "Alarm Notification Run Options" window, verify that the devices field name is correct ("ITGDevices.txt") Click Apply then OK. Note: MAT/OTM Alarm Notification must be restarted whenever Control Files are changed.
Page 146 Page 146 of 302 Installation and configuration of ITG Line 2.0 node • Transmitting the node and card properties to Leader 0 • Transmitting card properties to all cards in the node Procedure 16 Set the Leader 0 IP address Access the ITGL shell by connecting a MAT PC to the RS232 serial maintenance port on the faceplate of the ITG Leader 0 card with an NTAG81CA PC Maintenance cable.
Page 147 Installation and configuration of ITG Line 2.0 node Page 147 of 302 Enter the default "user ID" and "password" of itgadmin to access the ITGL shell command line prompt: ...+++ user ID: itgadmin password: itgadmin When the maintenance window displays "T:21", at the ITGL shell prompt, enter: ITGL>...
Page 148 Page 148 of 302 Installation and configuration of ITG Line 2.0 node Procedure 17 Transmit node and card properties to Leader 0 Log in to Overlay 32 in Meridian 1. Disable the card in order to transmit the card properties. Open MAT/OTM.
Page 149 Installation and configuration of ITG Line 2.0 node Page 149 of 302 Figure 25 ITG Transmit Options dialog box ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 150 Page 150 of 302 Installation and configuration of ITG Line 2.0 node Procedure 18 Transmit card properties to all cards in the node To verify installation and configuration: Check card faceplate displays. — After successfully rebooting, the Leader 0 card is now fully configured with the Node Properties of the node and enters a state of “active leader”.
Page 151 Installation and configuration of ITG Line 2.0 node Page 151 of 302 Transmit card properties again to Leader 1 and follower cards. If any of the cards are not status "disabled", go into Overlay 32 and disable the card. When all card TNs show a status of disabled, go into Configure | Synchronize | Transmit.
Page 152 Page 152 of 302 Installation and configuration of ITG Line 2.0 node Note the software and i2004 Internet telephone firmware release of each ITG Line 2.0 card and compare it against the latest recommended software release for the card available on the M1 ESD website.
Page 153 Installation and configuration of ITG Line 2.0 node Page 153 of 302 Click on the pdf file in the Documentation column to download the text file associated with the latest card software. Open the readme.txt file that contains the version number of the latest card software and associated i2004 firmware.
Page 154 Page 154 of 302 Installation and configuration of ITG Line 2.0 node In the “Transmit Options” group box, select the radio button “Transmit to selected cards.” In the “Software Download” group box check “Card software.” Click on the Browse button to locate the ITG Line 2.0 card software that was downloaded earlier from the website.
Page 155 Upgrade ITG card software by PC card This procedure provides an alternate to the web method of upgrading card software described in Procedure 21 on page 153. In this case, Nortel Networks supplies a PC card containing the latest ITG card software version.
Page 156 Page 156 of 302 Installation and configuration of ITG Line 2.0 node Procedure 23 Upgrade i2004 Internet Telephone firmware Open a browser on the MAT/OTM PC and connect to the following URL address: http://www.nortelnetworks.com/servsup/esd/meridian1/ When you are connected to the site, enter the username and password.
Page 157 Installation and configuration of ITG Line 2.0 node Page 157 of 302 The i2004 Internet Telephones continue to run the old firmware until the umsUpgradeAll command is executed or the i2004 Internet Telephone re-registers with the ITG line card. Verify the time and the date on each ITG card before proceeding to the next step.
Page 158 Page 158 of 302 Installation and configuration of ITG Line 2.0 node 553-3001-204 Preliminary 0.10 August 2000...
Page 159: Overview
Page 159 of 302 ITG MAT 6.67.07 (with update disk)/OTM 1.0 management PC Contents This section contains information on the following topics: Overview ..........159 ITG Engineering rules .
Page 160: Network Setup Guidelines
Page 160 of 302 ITG MAT 6.67.07 (with update disk)/OTM 1.0 management PC All MAT/OTM ITG data is stored in a single database file. The entire database is read into PC memory when you launch the program. If a large ITG network is to be managed from a single MAT/OTM server, then each client must have more than 32 Mb RAM.
Page 161: Remote Access Configuration
ITG MAT 6.67.07 (with update disk)/OTM 1.0 management PC Page 161 of 302 Remote Access configuration Support for remote access varies according to the support organizations access to the customer’s data network LAN or WAN. There are three possible remote access scenarios. Refer to Figure 26 on page 162 for an illustration of remote access configuration.
Page 162 Page 162 of 302 ITG MAT 6.67.07 (with update disk)/OTM 1.0 management PC Figure 26 Remote access with full access to the customer’s LAN/WAN I2004 T-LAN E-LAN C -LAN Router Core 0 Core 1 DHCP Server MAT / OTM Netgear RM 356 Modem Router PSTN 553-3001-204 Preliminary 0.10 August 2000...
Page 163: Pc Description
ITG MAT 6.67.07 (with update disk)/OTM 1.0 management PC Page 163 of 302 PC description The MAT/OTM PC can be attached to a LAN to provide multi-user, multi-site access. The MAT/OTM applications and database must reside on a LAN Server with each client accessing the files from the server. Note: The server used for MAT/OTM is used as a file server only and must not be used to access MAT/OTM as a client PC.
Page 164 Page 164 of 302 ITG MAT 6.67.07 (with update disk)/OTM 1.0 management PC — One GB or larger hard disk drive with 500 MB or more free space (includes Windows 95/NT 4.0 requirements). Please refer to system datastore column in the hard drive requirements chart that follows: •...
Page 165: Hard Drive Requirements
ITG MAT 6.67.07 (with update disk)/OTM 1.0 management PC Page 165 of 302 Hard drive requirements For a single MAT/OTM PC configuration, refer to Table 25 to select the hard drive space required on the MAT/OTM PC. Consider both program and data store requirements.
Page 166 Page 166 of 302 ITG MAT 6.67.07 (with update disk)/OTM 1.0 management PC 553-3001-204 Preliminary 0.10 August 2000...
Page 167: Overview
Page 167 of 302 Installation and maintenance of i2004 Internet Telephone Contents This section contains information on the following topics: Overview ..........167 Before you begin .
Page 168: Before You Begin
Page 168 of 302 Installation and maintenance of i2004 Internet Telephone • Procedure 26, “Automatic first-time installation of the i2004 Internet Telephone” on page 172. • Procedure 27, “Changing the TN of an existing i2004 Internet Telephone” on page 173. •...
Page 169: Manual First-Time I2004 Internet Telephone Installation
Installation and maintenance of i2004 Internet Telephone Page 169 of 302 You must be familiar with the three configuration modes that you will be prompted to choose from as you proceed through the installation of your i2004 Internet Telephone: • Partial DHCP mode: works with standard DHCP server •...
Page 170 There are only four seconds between plugging in the i2004’s power transformer and the appearance of the Nortel Networks logo on the display. When you see the logo, you have one second to respond by pressing the four feature keys at the bottom of the display in sequence from left to right.
Page 171 Installation and maintenance of i2004 Internet Telephone Page 171 of 302 Power-up the i2004 Internet Telephone. When the Nortel Networks logo appears on the display, immediately press the four feature keys at the bottom of the display in sequence from left to right.
Page 172: Automatic First-Time Installation Of An I2004 Internet Telephone
Internet Telephone-aware DHCP server. DHCP allows the dynamic allocation of IP addresses to different clients. The Nortel Networks i2004 Internet Telephone can act as a DHCP client. As part of the startup routine, the i2004 Internet Telephone can request automatic network and local configuration parameters from a DHCP server.
Page 173: I2004 Internet Telephone Power Cycle Description
Installation and maintenance of i2004 Internet Telephone Page 173 of 302 Follow the steps in “Manual first-time i2004 Internet Telephone installation” on page 169 to install the footstand, Ethernet cable, power transformer, handset, handset cord. Power-up the i2004 Internet Telephone. Connect the i2004 Internet Telephone to the LAN using the supplied Ethernet cable.
Page 174: Replace An I2004 Internet Telephone
Page 174 of 302 Installation and maintenance of i2004 Internet Telephone Press the "Clear" softkey during the five-second period. The existing node and TN will be cleared. The i2004 Internet Telephone prompts the user for new Node Number and TN information. ——————————...
Page 175 Installation and maintenance of i2004 Internet Telephone Page 175 of 302 Physical TNs, which are seen as card units, are managed using existing Overlay 32 commands. Because virtual TNs are configured on virtual superloops, Virtual TN maintenance has no meaning. It is already provided by the Meridian 1 for phantom loops.
Page 176 Page 176 of 302 Installation and maintenance of i2004 Internet Telephone If the i2004 Internet Telephone is not registered, an NPR0048 message is generated. If the i2004 Internet Telephone is registered but does not respond, the system prints the i2004 Internet Telephone IP address and ITG card IP address and generates an NPR0503 message.
Page 177 Installation and maintenance of i2004 Internet Telephone Page 177 of 302 Table 27 LD32 Available Maintenance Commands for the i2004 Internet Telephone Prompt Response Description STAT lscu UNEQ Display the i2004 state. STAT cu IDLE REGISTERED UNEQ, IDLE, BUSY and DSBL IDLE UNREGISTERED.
Page 178: Lamp Audit And Keep Alive
Page 178 of 302 Installation and maintenance of i2004 Internet Telephone Lamp audit and keep alive The Meridian 1 Lamp Audit function provides a continuous source of heartbeat messages to ensure the i2004 Internet Telephone is powered and the IP connection is alive. Since there is a reliable UDP connection from the Meridian 1 core through to the i2004 Internet Telephone, any failure of the i2004 Internet Telephone, the ITG card or the IP connection is detected.
Page 179 Page 179 of 302 ITG line card 2.0 administration Contents This section contains information on the following topics: Overview ..........180 MAT/OTM OA&M administration procedures .
Page 180: Overview
Page 180 of 302 ITG line card 2.0 administration Display ITG card properties ........200 Transfer files using the command-line interface .
Page 181: Mat/Otm Oa&M Administration Procedures
When a report is generated, the application retrieves the latest OM data from each ITG Line 2.0 card defined in MAT/OTM. Note: Nortel Networks recommends that you schedule report generation once a day. ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 182 Page 182 of 302 ITG line card 2.0 administration Procedure 30 Report scheduling In the ITG Main window, click File | Report | Generate. In the ITG - Generate Report window, select the Schedule report generation radio button. Click OK. The Scheduling window appears (see Figure 27). In the “Job”...
Page 183: View Itg Info And Error Log
ITG line card 2.0 administration Page 183 of 302 Procedure 31 Report generation In the IP Telephony Gateway- IP Phones window, click File | Report | Generate. In the ITG - Generate Report window, click Generate OM Report now. Click OK. MAT/OTM creates and displays a report named "ITG IP Phones - Operational Measurement Report."...
Page 184 Page 184 of 302 ITG line card 2.0 administration Procedure 33 Viewing ITG info and error log To view ITG error conditions that are abnormal events, but not severe enough to raise an alarm: In the “MAT/OTM Navigator” window, select the ITG IP Phones icon from the “Services”...
Page 185: Configure Snmp Traps
ITG line card 2.0 administration Page 185 of 302 Configure SNMP traps Procedure 34 Configuring SNMP Traps Return to the "MAT/OTM Navigator" window. In the MAT/OTM Navigator window select Utilities | Alarm Notification. The "MAT/OTM Alarm Notification" dialog box appears (Figure 29).
Page 186 Page 186 of 302 ITG line card 2.0 administration Figure 29 Alarm Notification Run Options (General tab) 553-3001-204 Preliminary 0.10 August 2000...
Page 187 ITG line card 2.0 administration Page 187 of 302 Figure 30 Alarm Notification Run Options (Control Files tab ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 188 Page 188 of 302 ITG line card 2.0 administration Figure 31 Open dialog box 553-3001-204 Preliminary 0.10 August 2000...
Page 189 ITG line card 2.0 administration Page 189 of 302 Figure 32 Devices.txt Notepad Table 28 Format of Devices.txt file Device Type IP Address Device Name ITG_IP_PHONES xxx.xxx.xxx.xxx Site_Leader_0 ITG_IP_PHONES xxx.xxx.xxx.xxx Site_Leader_1 ITG_IP_PHONES xxx.xxx.xxx.xxx Site_Follower_2 ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 190: Back Up And Restore Mat/Otm Data
Page 190 of 302 ITG line card 2.0 administration Back up and restore MAT/OTM data The MAT/OTM Backup Wizard is used to backup and restore any or all of MAT/OTM PC based data, including ITG MAT/OTM data. All of the ITG data is stored in an Access database file on the MAT/OTM PC or Server.
Page 191: Delete An Itg Line 2.0 Card From The Node
ITG line card 2.0 administration Page 191 of 302 Delete an ITG Line 2.0 card from the node Procedure 37 Deleting an ITG Line card from the node In the “MAT/OTM Navigator” window select the ITG IP Phones icon from the “Services” folder. If the ITG Line 2.0 card to be deleted is a Leader 0 or Leader 1, then: •...
Page 192: Update Itg Line 2.0 Card Properties
Page 192 of 302 ITG line card 2.0 administration Click the “Transmit to selected nodes” radio button. Click the “Node Properties” check box. Click the Start Download button. The results of the download appear in the “Transmit control” box. Click Close. If you have changed the IP addresses of any cards, restart the cards for the changes to take effect.
Page 193: Use The Retrieve Command
ITG line card 2.0 administration Page 193 of 302 Use the Retrieve command The Retrieve command sends information from the ITG Line 2.0 cards to the MAT /OTM ITG node. The Retrieve command is used for: • a remote MAT/OTM user to download a node or card configuration Note: This can also be performed by doing the “Add ITG Node”...
Page 194: Add An Itg Node On Mat /Otm By Retrieving An Existing Node
Page 194 of 302 ITG line card 2.0 administration Add an ITG node on MAT /OTM by retrieving an existing node Use this optional procedure in the following cases: • Add existing nodes to a particular MAT/OTM ITG PC to manage the ITG network from a single point of view.
Page 195 ITG line card 2.0 administration Page 195 of 302 Figure 33 Add ITG Node dialog box In the “Retrieve ITG node” window, select the “MAT/OTM Site”, and “Meridian 1 System” fields. Select the “Meridian 1 Customer” number. Note: The site name, Meridian 1 system name, and Meridian 1 customer number must exist in the MAT/OTM Navigator before you can add a new ITG node.
Page 196 Page 196 of 302 ITG line card 2.0 administration Figure 34 Retrieve ITG node 553-3001-204 Preliminary 0.10 August 2000...
Page 197: Port
ITG line card 2.0 administration Page 197 of 302 In the main window, select Leader 0 of the newly added node. Use the Configuration|Synchronize|Retrieve command to retrieve the card properties for all ITG Line 2.0 cards in the selected node. ——————————...
Page 198: Telnet And Ftp Security Information
Page 198 of 302 ITG line card 2.0 administration The MAT/OTM PC opens a Telnet window and automatically connects to the ITG Line 2.0 card by using the management IP address. Enter a username and password to access the ITG shell command-line interface.
Page 199: Reset The Operational Measurements
ITG line card 2.0 administration Page 199 of 302 Procedure 44 Downloading ITG data from the MAT PC At the ITG shell prompt, type: currOMFilePut <hostname, username, password, directory path, filename> for the current file, or prevOMFilePut <hostname, username, password, directory path, filename>...
Page 200: Display Itg Card Properties
Page 200 of 302 ITG line card 2.0 administration Display ITG card properties To display information about an ITG Line 2.0 card, enter the following command: itgCardShow The following commands give additional information about an ITG Line 2.0 card: • ifShow •...
Page 201 ITG line card 2.0 administration Page 201 of 302 The following commands can be entered at the ITG shell command-line: Table 3 ITGL Shell Commands Shell commands swDownload <hostname> <username> <password> <directory path> <filename> configFileGet <hostname> <username> <password> <directory path> <filename> bootPFileGet <hostname>...
Page 202: Ip Configuration Commands
Page 202 of 302 ITG line card 2.0 administration IP configuration commands Table 4 IP configuration commands IP configuration command Function setLeader Performs all the necessary actions to make a leader. Sets IP address, gateway, subnet mask, boot method to static, and leader bit in NVRAM.
Page 203 ITG line card 2.0 administration Page 203 of 302 When the ITG card detects the i2004 Internet Telephone has been disconnected, the ITG card logs the event and sends an UNREGISTER message to the Meridian 1for that i2004 Internet Telephone. When the Meridian 1 CPU detects a loss of connection with the ITG card, Meridian 1 logs a message and UNREGISTERS all of the i2004 Internet Telephones and gateway channels associated with that ITG card.
Page 204 Page 204 of 302 ITG line card 2.0 administration Table 29 LD 32 - Administration commands for the ITG Line 2.0 card Command Function IDC l s c Print the Card ID information for the specified card, where: l = loop, s = shelf, c = card Note 1: This command will display the PEC (Product Engineering Code) and serial number for the card.
Page 205 Page 205 of 302 ITG Line card 2.0 maintenance Contents This section contains information on the following topics: Overview ..........206 Faceplate maintenance display codes .
Page 206: Overview
If the maintenance display shows a persistent T:20 indicating an ITG software failure and if this occurs after the card was reset during a software download procedure, call your Nortel Networks technical support for assistance in attempting to download new software onto the card...
Page 207 ITG Line card 2.0 maintenance Page 207 of 302 Table 30 Faceplate maintenance display codes Normal code Fault code Message T:00 F:00 Initialization T:01 F:01 Testing Internal RAM T:02 F:02 Testing ALU T:03 F:03 Testing address mode T:04 F:04 Testing Boot ROM T:05 F:05 Testing timers...
Page 208 Page 208 of 302 ITG Line card 2.0 maintenance Table 30 Faceplate maintenance display codes T:20 CardLAN enabled, transmitting bootp requests. If this display persists, then the ITG 2.0 card is running in BIOS ROM mode due to card software failure. T:21 CardLAN operational, A07 enabled , display now under host control.
Page 209: System Error Messages
ITG Line card 2.0 maintenance Page 209 of 302 System error messages When an error or specific event occurs, SNMP sends an alarm trap to MAT/OTM or any SNMP manager that is configured in the SNMP Manager’s list in the ITG Line 2.0 card properties. It also puts the system error message into the error log file containing error messages.
Page 210 Page 210 of 302 ITG Line card 2.0 maintenance Table 31 Critical ITG and ITS Error messages Corresponding Maintenance Display Circuital Error Description Message G008 ITG1008 Null pointer encountered <file> <line> Name of pointer. G009 ITG1009 Invalid block <file> <line> Type of block.
Page 211 ITG Line card 2.0 maintenance Page 211 of 302 Table 31 Critical ITG and ITS Error messages Corresponding Maintenance Display Circuital Error Description Message G024 ITG1024 DSP failure <dsp> <errno> <errtext>. G025 ITG1025 DSP download failed retrying <dsp>. G026 ITG1026 DSP download retry succeeded <dsp>.
Page 212: Replacing An Itg Line 2.0 Card
Page 212 of 302 ITG Line card 2.0 maintenance Table 31 Critical ITG and ITS Error messages Corresponding Maintenance Display Circuital Error Description Message S004 ITS1004 Failed to retrieve node ID and TN <ip> <hwid> S005 ITS1005 Invalid node ID <ip> <hwid>. S006 ITS1006 Corrupted node ID/TN field <ip>...
Page 213 ITG Line card 2.0 maintenance Page 213 of 302 • If a voice channel on the ITG Line 2.0 card has a consistent voice quality fault, such as persistent noise or lack of voice path, even after resetting the card and retransmitting the card properties. Procedure 45 Replacing an ITG line card Before replacing the ITG line card, first remove it for 2-3 seconds and...
Page 214 Page 214 of 302 ITG Line card 2.0 maintenance Use the Configuration | Synchronize | Transmit command to transmit the Node Properties from MAT/OTM to the active leader card (Leader 0 or Leader 1) of the ITG node. Leave the default radio button selection "Transmit to Selected Nodes".
Page 215: Verify Itg Card Software And Firmware
“http://www.nortelnetworks.com/servsup/esd/meridian1” The default user name is usa. The default password is usa. See your Nortel Network representative to register for a new default name and password if the default does not work. Navigate through the site until you reach the Release Notes and associated software and firmware zip files.
Page 216 Page 216 of 302 ITG Line card 2.0 maintenance Figure 35 ITG Transmit Options dialog box Select the radio button “Transmit to selected cards”. Check the “Card properties" boxes only. Click the Start Transmit button. The transmission status is displayed in the “Transmit control” box. Confirm that Card Properties are transmitted successfully.
Page 217: Access The Command Line From Mat
ITG Line card 2.0 maintenance Page 217 of 302 Use the Overlay 32 ENLC command to re-enable the ITG Line 2.0 card. In the “IP Telephony Gateway” main window, select View | Refresh. The card status now shows “Enabled.” Update the Installation Summary Sheet with the new MAC address. Verify the TN, management interface MAC address and IP address for each ITG Line 2.0 card.
Page 218: Adding A "Dummy" Node For Retrieving And Viewing Itg Node
Page 218 of 302 ITG Line card 2.0 maintenance Adding a “dummy” node for retrieving and viewing ITG node configuration Use this procedure to create a “dummy” ITG node for retrieving and viewing the actual ITG node configuration, without over-writing the existing ITG configuration data for an existing node in the MAT/OTM ITG database.
Page 219: Retrieving Itg Configuration Information From The Itg Node
ITG Line card 2.0 maintenance Page 219 of 302 Use the Configuration|Synchronize|Retrieve function to retrieve data from that node. Confirm to over-write the MAT/OTM ITG data for the “dummy” node. —————————— End of Procedure —————————— Retrieving ITG configuration information from the ITG node The following Procedure on page 219, is an optional procedure that may be used in the following cases: •...
Page 220 Page 220 of 302 ITG Line card 2.0 maintenance Figure 36 ITG main window - Node Add Leave the defaulted “Retrieve to selected nodes” option selected, or click the “Retrieve from selected cards,” depending upon the situation: Leave the defaulted “Retrieve to selected nodes” when the MAT/OTM ITG data is out of date and you intend to synchronize all MAT/OTM ITG node data with the data from the ITG Line 2.0 cards on the node, or if you are adding a node on MAT/OTM by...
Page 221: Itg Line 2.0/I2004 Internet Telephone Maintenance And Diagnostics
ITG Line card 2.0 maintenance Page 221 of 302 Click the Start retrieve button. Monitor the progress of the retrieval in the “Retrieve control” box. The retrieved “Node Properties,” "GK Properties" and “Card Properties,” will over-write the existing MAT/OTM ITG configuration data for the respective node or card.
Page 222 Page 222 of 302 ITG Line card 2.0 maintenance Because Meridian 1 must request the information from the i2004 Internet Telephone, the IDU is effectively a "ping" command and can be used to test the end-to-end IP connectivity of the i2004 Internet Telephone. The output format of the IDU command in LD32 is shown in Table 32.
Page 223 ITG Line card 2.0 maintenance Page 223 of 302 Table 33 LD 32 Maintenance Commands for the i2004 Internet Telephone Prompt Response Description STAT lscu UNEQ Display the i2004 Internet STAT cu IDLE REGISTERED Telephone state. IDLE UNREGISTERED. UNEQ, IDLE, BUSY and DSBL BUSY, have the usual meaning.
Page 224: Itg Line Shell Commands
Page 224 of 302 ITG Line card 2.0 maintenance ITG line shell commands ITG line shell commands are designed to supplement overlay commands, and to introduce new features specific to the ITG platform. The ITG shell commands are accessed by connecting a TTY to the MAINT port on the ITG Line 2.0 card faceplate.
Page 225 ITG Line card 2.0 maintenance Page 225 of 302 Table 34 ITG Line 2.0 ITGL shell commands (Part 2 of 6) =>Command Description numChannelsShow Displays number of available channels. swVersionShow Displays software version. resetOm Resets the operational measurement file timer. This command will reset all operational measurement parameters collected since last log dump.
Page 226 Page 226 of 302 ITG Line card 2.0 maintenance Table 34 ITG Line 2.0 ITGL shell commands (Part 3 of 6) =>Command Description configFileGet "hostname", Updates the config.ini file on the ITG Line 2.0 card with the "username", "password", config.ini file on the specified host, account and path. The "directory path", "filename"...
Page 227 ITG Line card 2.0 maintenance Page 227 of 302 Table 34 ITG Line 2.0 ITGL shell commands (Part 4 of 6) =>Command Description prevOmFilePut "hostname", The omFilePut task on the ITG host initiates an FTP "username", "password", session with the given parameters and downloads the ITG "directory path", "filename"...
Page 228 Page 228 of 302 ITG Line card 2.0 maintenance Table 34 ITG Line 2.0 ITGL shell commands (Part 5 of 6) =>Command Description IP configuration commands: NVRIPSet Sets the IP address in NVRAM. NVRGWSet Sets the default gateway address in NVRAM. NVRSMSet Sets the subnet mask in NVRAM.
Page 229 ITG Line card 2.0 maintenance Page 229 of 302 Table 34 ITG Line 2.0 ITGL shell commands (Part 6 of 6) =>Command Description ping "host", "numpackets" This command sends an ICMP ECHO_REQUEST packet to a network host. The host matching the destination address in the packets will respond to the request.
Page 230: Itg Line 2.0 Card Selftests
Page 230 of 302 ITG Line card 2.0 maintenance ITG Line 2.0 card selftests During power-up, the ITG Line 2.0 card performs diagnostic tests to ensure correct operation. The faceplate RS-232 port on the ITG Line 2.0 card can be used to monitor the progress of these tests.
Page 231 ITG Line card 2.0 maintenance Page 231 of 302 Examples of booting sequences: Case 1: The following excerpt from the booting sequence indicates the amount of memory onboard. Memory Configuration Onboard: 4MB SIMM: 16MB Total: 20MB In the absence or failure of the SIMM, the total memory is 4MB, which is not enough to support the ITG application.
Page 232: Warm Rebooting The Itg Line 2.0 Card
Page 232 of 302 ITG Line card 2.0 maintenance Solutions Case 1: If a SIMM is missing, install a 16MB SIMM into the SIMM slot which is found underneath the ITG daugherboard. If the SIMM is present, check that the SIMM is properly seated. Otherwise, the SIMM is faulty and needs replacement.
Page 233: Work With Alarm And Log Files
ITG Line card 2.0 maintenance Page 233 of 302 Work with alarm and log files Alarm and log file output is turned on via the ITG shell. The following commands may be performed at the ITG shell prompt: • to turn on/off the error log file, type: logFileOn logFileOff •...
Page 234 Page 234 of 302 ITG Line card 2.0 maintenance 553-3001-204 Preliminary 0.10 August 2000...
Page 235: Ntmf94Ea I/O Cable
Page 235 of 302 Appendix A: I/O, maintenance and extender cable description Contents This section contains information on the following topics: NTMF94EA I/O cable ........235 Connector pin assignments .
Page 236 Page 236 of 302 It is important to use the mounting screw provided to secure the top of the NTMF94EA cable 25-pair Amphenol connector to the Meridian 1. The screw ties the LAN cable shield to the Meridian 1 frame ground for EMC compliance.
Page 237 Page 237 of 302 Table 35 NTMF94EA E-LAN, T-LAN and RS-232 Serial Maintenance I/O cable Mounting Screw Shielded RJ-45 Cable Shielded 25-Pair Amphenol Connector Shielded RJ45 Mating Coupler To Hub Ferrite To Hub 9 Pin D-Sub Female ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 238: Connector Pin Assignments
Page 238 of 302 Connector pin assignments Table 36 shows the I/O connector pin designations for the ITG Line 2.0 card. Table 36 ITG I/O Panel Pinout (Part 1 of 2) Normal Normal Assignment Assignment Assignment Assignment Not Used Not Used Not Used Not Used Not Used...
Page 239 Page 239 of 302 Table 36 ITG I/O Panel Pinout (Part 2 of 2) Normal Normal Assignment Assignment Assignment Assignment SGNDA BDCDA- BSINA- BSOUTA- BDTRA- SGND BDSRA- BRTSA- BCTSA- BSINB- BSOUTB- BDCDB- BDTRB- BDSRB- no connect no connect no connect no connect Table 37 NTMF94EA cable pin description (Part 1 of 2)
Page 240 Page 240 of 302 Table 37 NTMF94EA cable pin description (Part 2 of 2) I/O Panel: P1 Signal Name P2, P3,P4 Color P1-25 SHLD GRND P1-50 SHLD GRND P1-18 RXDB+ P4-3 GRN/WHT P1-19 TXDB+ P4-1 ORG/WHT P1-43 RXDB- P4-6 WHT/GRN P1-44 TXDB- P4-2...
Page 241: Prevent Ground Loops On Connection To External Customer Lan
Page 241 of 302 Prevent ground loops on connection to external customer LAN equipment The shielded RJ45 coupler is the connection point for the customer’s shielded Category 5 LAN cable to the hub, switch, or router supporting the T-LAN and E-LAN.
Page 242: Ntag81Ba Maintenance Extender Cable
Page 242 of 302 Figure 37 NTAG81CA Maintenance cable DIN-8 DB-9 female 553-9244 Table 38 NTAG81CA maintenance cable pin description 8-pin Mini-DIN 9-pin D-Sub Signals Signals (MIX Side) (PC Side) (MIX Side) (PC Side) Male Female DTRB- DSR- SOUTB- SIN- SINB- SOUT- SINA-...
Page 243: Replace Cable Nt8D81Ba With Nt8D81Aa
Page 243 of 302 Figure 38 NTAG81BA Maintenance Extender cable DB-9 male DB-9 female 553-9245 Table 39 NTAG81BA Maintenance cable pin description 9-pin D-Sub (Male) 9-pin D-Sub (Female) Replace cable NT8D81BA with NT8D81AA This procedure explains how to replace the NT8D81BA cable with the NT8D81AA cable and how to install the NTCW84JA special IPE filter.
Page 244 Page 244 of 302 In NT8D37BA and NT8D37EC (and later vintage) IPE Modules, all 16 IPE card slots support 24-pair cable connections. Table 40 shows the cable connections from the backplane to the inside of the I/O panel. Figure 39 shows the designations for the backplane end of the cables, the backplane slot designations for the cable connections, and the associated network segments for the backplane slots.
Page 245: Tools List
Page 245 of 302 Figure 39 Backplane slot designations Segment 3 Segment 2 Segment 1 Segment 0 L15 L14 L13 L12 L11 L10 L9 553-5391 Tools list • Ty-wrap cutter • Ty-wraps • Needle nose pliers • Slotted screwdriver Procedure 51 Removing an NT8D81BA cable Identify the I/O panel and backplane designation that corresponds to the LEFT slot of the pair of card slots, viewed front the front, in which...
Page 246: Installing An Ntcw84Ja Filter And Nt8D81Aa Cable
Page 246 of 302 To remove the ribbon cables from IPE backplane: Apply gentle pressure on the tab on the right side of the shroud while pulling on the connector until it pulls free from the shroud. Remove connector 1 first, then remove connectors 2 and 3. Discard NT8D81BA cable.
Page 247: Overview
Meridian 1 site LAN (called the embedded LAN or E-LAN as opposed to the customer's enterprise network or C-LAN) in order to provide remote support access for ITG and other IP-enabled Nortel Networks products. The Netgear RM356 modem router integrates the functions of a V.90 modem,...
Page 248: Rm356 Modem Router Security Features
Use shielded Cat5 10BaseT Ethernet cables to connect the modem router to the Management interface of up to four ITG cards. Other IP- enabled Nortel Networks products on the E-LAN can be connected to the RM356 modem router, including the Meridian 1 PBX, a local MAT 6.6/OTM 1.0 6.6/OTM 1.0 PC, Symposium Call Center Server, and...
Page 249 Page 249 of 302 Figure 40 Remote support using Netgear RM356 modem router I2004 T-LAN E-LAN C -LAN Router Core 0 Core 1 DHCP Server MAT / OTM Netgear RM 356 Modem Router PSTN Connect the modem router to the AC power source. The power LED will light.
Page 250: Configure The Rm356 Modem Router By The Manager Menu
Page 250 of 302 Connect the other end of the manager cable to an RS232 terminal or PC COM port configured for the following communication parameters: 9600 bps, 8, none, and 1. The local maintenance cable connects directly to data terminal equipment (DTE).
Page 251 Page 251 of 302 Type in the system name (19 characters, no spaces), location, and contact person's name for the Meridian 1 site. Use the up and down arrow keys to move the cursor to the prompt "Press ENTER to Confirm or ESC to Cancel:"...
Page 252 Page 252 of 302 Type in a descriptive route name, for example, "DefaultGW" (no spaces). Toggle "Active=Yes/No" for security purposes. The gateway IP address is the Management GW IP address on the E-LAN where the modem router is connected. " Press Enter to confirm and save data to ROM, then press Esc to return from the sub-menu to the main menu.
Page 253 OTM 1.0 PC must provide the user name and password defined here when dialing up the modem router. Set "Callback=Yes/No" according to the customer's network security policy and practices. Nortel Networks Customer Technical Services (CTS), does not currently accept Callback security calls from the modem router.
Page 254: Rm356 Modem Router Manager Menu Description (Application Notes On Meridian 1 E-Lan Installation)
Page 254 of 302 —————————— End of Procedure —————————— RM356 modem router manager menu description (application notes on Meridian 1 E-LAN installation) This section displays the various menus of the RM356 modem router: RM356 Main Menu Getting Started Advanced Management 1.
Page 255 Page 255 of 302 Advanced Setup= No Press ENTER to Confirm or ESC to Cancel: Menu 3 - Ethernet Setup 1. General Setup 2. TCP/IP and DHCP Setup Enter Menu Selection Number: Menu 3.1 - General Ethernet Setup Input Filter Sets= 2 Output Filter Sets= Press ENTER to Confirm or ESC to Cancel: Menu 3.2 - TCP/IP and DHCP Ethernet Setup...
Page 256 Page 256 of 302 Menu 12 - Static Route Setup 1. DefaultGW 2. ________ 3. ________ 4. ________ Enter Menu Selection Number: Menu 12.1 - Edit IP Static Route Route #: 1 Route Name= DefaultGW Active= Yes Destination IP Address= 0.0.0.0 IP Subnet Mask= 0.0.0.0 Gateway IP Address= 47.177.16.1 Metric= 2...
Page 257 Page 257 of 302 Allocated Budget(min)= Period(hr)= Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle. Menu 14 - Dial-in User Setup 1. itgadmin 2. ________ 3. ________ 4. ________ 5. ________ 6. ________ 7. ________ 8.
Page 258 Page 258 of 302 Menu 21 - Filter Set Configuration Filter Filter Set # Comments Set # Comments ------ ----------------- ------ ----------------- NetBEUI_WAN _______________ NetBEUI_LAN _______________ _______________ _______________ _______________ _______________ _______________ _______________ _______________ _______________ Enter Filter Set Number to Configure= 0 Edit Comments= Press ENTER to Confirm or ESC to Cancel: Menu 21.1 - Filter Rules Summary...
Page 259 Page 259 of 302 New Password= ? Retype to confirm= ? Enter here to CONFIRM or ESC to CANCEL: Menu 24 - System Maintenance System Status Terminal Baud Rate Log and Trace Diagnostic Backup Configuration Restore Configuration Software Update Command Interpreter Mode Call Control Enter Menu Selection Number: Menu 24.1 -- System Maintenance - Status...
Page 260 Page 260 of 302 COMMANDS: 1-Drop Port 1 9-Reset Counters ESC-Exit Menu 24.2 -- System Maintenance - Change Terminal Baud Rate Terminal Baud Rate: 9600 Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle. Menu 24.3 == System Maintenance - Log and Trace 1.
Page 261 Page 261 of 302 Menu 24.3.2 -- System Maintenance - Syslog and Accounting Syslog: Active= No Syslog IP Address= ? Log Facility= Local 1 Press ENTER to Confirm or ESC to Cancel: Press Space Bar to Toggle. Menu 24.4 - System Maintenance - Diagnostic MODEM System Drop MODEM...
Page 262 Page 262 of 302 553-3001-204 Preliminary 0.10 August 2000...
Page 263: Reliability
Page 263 of 302 Appendix C: Product integrity Contents This section contains information on the following topics: Reliability ..........263 Mean time between failures (MTBF) .
Page 264: Temperature-Related Conditions
Page 264 of 302 Temperature-related conditions Refer to Table 41 for a display of acceptable temperature and humidity ranges for the ITG Line 2.0 card. Table 41 ITG Line 2.0 card environmental specifications Specification Minimum Maximum Normal Operation Recommended 15° C 30°...
Page 265: Electrical Regulatory Standards
Page 265 of 302 Electrical regulatory standards The following three tables list the safety and electro-magnetic compatibility regulatory standards for the ITG Line 2.0 card, listed by geographic region. Specifications for the ITG Line 2.0 card meet or exceed the standards listed in these regulations.
Page 266 Page 266 of 302 Electro-magnetic compatibility (EMC) Table 43 lists Electro-magnetic emissions regulations met by the ITG Line 2.0 card, along with the country’s standard that lists each regulation. Table 43 Electro-Magnetic Emissions Regulation Identifier Regulatory Agency FCC part 15 Class A United States Radiated Emissions CSA C108.8 Canada Radiated Emissions...
Page 267 Page 267 of 302 Table 44 lists Electro-magnetic immunity regulations met by the ITG Line 2.0 card, along with the country’s standard that lists each regulation. Table 44 Electro-Magnetic Immunity Regulation Identifier Regulatory Agency CISPR 22 Sec. 20 Class B I/O conducted noise IEC 801-2 (level 4) ESD (Basic Standard)
Page 268 Page 268 of 302 553-3001-204 Preliminary 0.10 August 2000...
Page 269 Page 269 of 302 Appendix D: Subnet mask conversion from CIDR to dotted decimal format Subnet masks are expressed in Classless Inter Domain Routing (CIDR) format, appended to the IP address. For example 10.1.1.1/20. The subnet mask must be converted from CIDR format to dotted decimal format in order to configure IP addresses.
Page 270 Page 270 of 302 If there is a remainder, refer to Table 45, to obtain the dotted decimal value for the field following the last field containing “255”. In the example of /20 above, the remainder is four. In Table 45, a remainder of four equals a binary value of 1111 0000 and the dotted decimal value of the next and last field is 240.
Page 271 Page 271 of 302 Appendix E: ITG System Messages Contents This section contains information on the following topics: ITG messages ..........271 ITS messages .
Page 272 Page 272 of 302 ITG0100 Successful bootup. All alarms cleared. ITG0101 Exit form QoS fallback. Normal operation restored. ITG0102 Ethernet voice port restored to normal operation. ITG0103 Ethernet management port restored to normal operation. ITG0104 DSP successfully reset. ITG0105 Exit from card fallback. Leader card restored. ITG0150 D-channel restored.
Page 273 Page 273 of 302 ITG0309 Unexpected DSP channel closed. Channel is unusable. ITG0310 Cannot open DSP channel. ITG0311 Unable to get response from Follower card. ITG0312 Unable to push BOOTP tab file to backup leader. ITG0313 Keycode failed validation. Configuration file discarded. ITG0350 Gatekeeper RAS reject threshold exceeded.
Page 274 Page 274 of 302 ITG0417 Update to followers. ITG0418 H-323 stack failed to initialize. ITG0450 D-channel loss of signal. Associated channels busied out. ITG0451 D-channel hardware failure. Associated channels busied out. ITG0452 Meridian -1 messaging failure. Unable to process calls. ITG0453 Cannot open Gateway DN file.
Page 275 Page 275 of 302 where x = 1-6 ITGx009 Invalid block <file> <line> Type of block. where x = 1-6 ITGx010 Unable to locate data block <file> <line> Type of block. where x = 1-6 ITGx011 Failed to push file <file> <host>. where x = 1-6 ITGx012 Failed to retrieve file <file>...
Page 276 Page 276 of 302 ITGx022 DSP channel not responding, channel disabled <channel>. where x = 1-6 ITGx023 DSP device failure, operating at reduced capacity <dsp>. where x = 1-6 ITGx024 DSP failure <dsp> <errno> <errtext>. where x = 1-6 ITGx025 DSP download failed retrying <dsp>.
Page 277 Page 277 of 302 where x = 1-6 ITGx036 Encountered unexpected open channel, closed it <channel>. where x = 1-6 ITS messages ITS messages incorporate the severity category of the message in the first digit of the four digit number. ITSx000 VTI function call timeout.
Page 278 Page 278 of 302 where x = 1-6 ITSx011 Communication link to M1 is down. where x = 1-6 ITSx012 Communication link to M1 is up. where x = 1-6 SCH messages SCH1360 On the M3903 M3904 M3905 and i2004 sets key 17 is reserved for the TRN mnemonic.
Page 279 Page 279 of 302 SCH1968 Key 0 must be a DN key on an i2004 set (I.e. one of SCR SCN MCR MCN PLN PLR ACD DN). SCH1970 Message Waiting Key (MWK) must be defined on key 16 on an i2004 set. ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 280 Page 280 of 302 553-3001-204 Preliminary 0.10 August 2000...
Page 281 Page 281 of 302 Appendix F: DHCP Supplementary Information Contents This section contains information on the following topics: Introduction to DHCP ........282 DHCP messages .
Page 282: Introduction To Dhcp
Page 282 of 302 Introduction to DHCP In order to understand how the i2004 Internet Telephone acquires the needed network configuration parameters automatically, the following section briefly describes the Dynamic Host Configuration Protocol (DHCP) protocol. It is recommended that readers, unfamiliar with the subject, read this section. Topics discussed will be helpful for the configuration and future maintenance of the DHCP server and ensure correct implementation with the i2004 Internet Telephone.
Page 283: Dhcp Messages
Page 283 of 302 DHCP messages There are seven different DHCP messages. Each message relates certain information between the client and server (see Table 2). Table 46 DHCP message types DHCP Message Types Description DHCPDISCOVER Initiates a client request to all servers. DHCPOFFER Offer from server following client request.
Page 284: Dhcp Message Exchange
Page 284 of 302 Figure 41 DHCP message format Refers to next bootstrap server Relay agent IP address DHCP Message Exchange For a client to receive services from a DHCP server, an exchange of DHCP messages between the client and server must take place. The sequence and types of DHCP message exchanged can differ, but the mechanism of acquiring and supplying information remains the same.
Page 285: Dhcp Options
Page 285 of 302 At this point, the client has no information about the server or the IP address it is going to receive (unless it is requesting a renewal), so the fields in the DHCP message are empty. However, the client knows its own MAC address and includes it in the Client hardware address field.
Page 286: Vendor Specific/Encapsulated Option
If the Vendor Encapsulation option is used, the information will have to first be encoded in a Site Specific option. Nortel Networks has provided a list of five possible Site Specific option codes to implement the ITG Line 2.0 card information.
Page 287: Ip Acquisition Sequence
Page 287 of 302 IP Acquisition Sequence This section focuses on the mechanics and sequence of the DHCP message exchange as the i2004 Internet Telephone uses DHCP for IP acquisition. Although the i2004 Internet Telephone requests many network configuration parameters as well as an IP address, the following cases focus on the concept of "how"...
Page 288: Case 2
Page 288 of 302 DHCPDISCOVER message. A DHCP server on the network sees the broadcast, reads the message, and records the MAC address of the client. It checks its own IP address pool(s) for an available IP address and broadcasts a DHCPOFFER message if one is available. (Usually the server ARPs or PINGs the IP address to make sure it is not being used.) The i2004 Internet Telephone sees the broadcast and after matching its MAC address with the offer, reads the rest of the message to find out...
Page 289: Case 3
Page 289 of 302 Figure 43 IP Acquisition Sequence - Case 2 Case 3 Finally, when a client is finished with a particular IP address, it sends a DHCPRELEASE message to the server which reclaims the IP address. If the client requires the same IP address again, it can initiate the process as follows: i2004 Internet Telephone broadcasts a DHCPREQUEST to a particular DHCP server by including the server's IP address in the Server IP...
Page 290: Multiple Dhcpoffers
The i2004 Internet Telephone only responds to DHCPOFFERs, that have the same unique string identifier, "Nortel-i2004-A" as the i2004 Internet Telephone. This string must appear in the beginning of the list of ITG Line 2.0 card parameters. Without this string, the i2004 Internet Telephone does not accept the DHPCOFFER, even if all parameters requested and ITG Line 2.0 card information are present.
Page 291: I2004 Support For Dhcp
DHCP DHCP support in the i2004 Internet Telephone includes sending a Class Identifier option with the value "Nortel-i2004-A" in each DHCP Discovery and Request. Additionally, the i2004 checks for either a Vendor Specific option message with a specific, unique to Nortel i2004, encapsulated sub-type, or a Site Specific DHCP option.
Page 292 Page 292 of 302 553-3001-204 Preliminary 0.10 August 2000...
Page 293 Page 293 of 302 List of terms Active Leader The Leader that at a given instant of time is performing the Leader role of being the designated point of contact in the group of Follower cards for all the Meridian systems in the network. The active leader card also provides endpoint management including registration/unregistration, authentication, address resolution (DN to IP and endpoint to gateway), and maintaining a list of endpoints currently active on the network.
Page 294 Page 294 of 302 List of terms Coordinated Dialing Plan. Class of Service. Central Office. Codec Equipment or circuits that digitally code and decode voice signals. The ITG Line 2.0 card product uses the G.729 Annex AB codec. Communications protocol A set of agreed-upon communications formats and procedures between devices on a data communications network.
Page 295 List of terms Page 295 of 302 Full-duplex transmission Simultaneous two-way independent transmission in both directions. Gateway Gateways in the system contain two interfaces: one interface to the Meridian 1, and the other to the IP network. The gateway provides the necessary conversion for both call signalling and voice stream/packets across the two interfaces.
Page 296 Page 296 of 302 List of terms Leader 0 The Leader 0 card is the MAT term for the ITG Line 2.0 card that initially assumes the active Leader role. See also Active Leader, Backup Leader, and Leader 1. Leader 1 The Leader 1 ITG card is the MAT term for the ITG Line 2.0 card that initially assumes the backup Leader role.
Page 297 List of terms Page 297 of 302 Noise Random electrical signals, generated by circuit components or by natural disturbances, that corrupt communications. Numbering Plan Area. Numbering Plan Exchange (Central Office). OA&M Operations, Administration, and Maintenance. Packet Group of bits transmitted as a complete package on a packet-switched network.
Page 298 Page 298 of 302 List of terms Round Trip Time. SNMP System Network Management Protocol. Protocol used to communicate MAT ITG alarms or events. Subnet Means of splitting packets into two fields to separate packets for local destinations from packets for remote destinations in TCP/IP networks. This makes small networks more efficient.
Page 299 List of terms Page 299 of 302 VoIP Voice over IP. Used synonymously with XoIP. XoIP Voice or Fax over IP. Wide Area Network. Network using common carrier-provided lines that covers an extended geographical area. Contrast with LAN. ITG Line 2.0/i2004 Internet Telephone Description, Installation, and Operation...
Page 300 Page 300 of 302 List of terms 553-3001-204 Preliminary 0.10 August 2000...
Page 301 Page 301 of 302 Index alarm files, 213 log files, 213 backplanes mean time between failures, 243 connectors, 223 MICB I/O panel connections, 224 regulatory standards, 245 backup, 183 NT8D02 Digital Line Card connector pin assignments connector pin assignments, 218 NT8D02 Digital Line Card, 218 environmental specifications, 37 connectors, 223...
Page 302 Page 302 of 302 Index X11 system software requirements, 32 553-3001-204 Preliminary 0.10 August 2000...
Page 304 Gateway (ITG) Line 2.0/i2004 Internet Telephone Description, Installation, and Operation Copyright © @ 1999 - 2000 Nortel Networks All Rights Reserved Information is subject to change without notice. Nortel Networks reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant.
