Page 1 IES-1248-71/73 ADSL2+ IP DSLAM User’s Guide Version 3.52 (LS.0), (TR.0) 9/2006 Edition 2 www.zyxel.com...
Page 3: About This User's Guide
Help us help you. Send all User Guide-related comments, questions or suggestions for improvement to the following address, or use e-mail instead. Thank you! The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 300, Taiwan. E-mail: techwriters@zyxel.com.tw IES-1248-71/73 User’s Guide...
Page 4: Document Conventions
• The IES-1248 may be referred to as the “IES-1248”, the “IES”, the “device” or the “system” in this User’s Guide. • “IES-1248” refers to the IES-1248-71 for ADSL over POTS (Annex A) and the IES-1248- 73 for ADSL over ISDN (Annex B). Differentiation is made where needed.
Page 5 A firmware version includes the model code and release number as shown in the following example. Firmware Version: V3.52(LS.0) "LS" is the model code. "0" is this firmware's release number. This varies as new firmware is released. Your firmware's release number may not match what is displayed in this User's Guide. IES-1248-71/73 User’s Guide...
Page 6: Safety Warnings
• Do NOT obstruct the device ventilation slots, as insufficient airflow may harm your device. • Fuse Warning! Replace a fuse only with a fuse of the same type and rating. • The length of exposed (bare) power wire should not exceed 7mm. IES-1248-71/73 User’s Guide...
Page 7 Safety Warnings • Fan Module Warning! Use the fan module handle when pulling out or pushing in the fan module. Be careful not to put fingers or objects inside the fan module. IES-1248-71/73 User’s Guide...
Page 8 Safety Warnings IES-1248-71/73 User’s Guide...
Page 9: Table Of Contents
MAC Filter ..........................187 Spanning Tree Protocol ......................189 Port Authentication ........................195 Port Security ..........................199 DHCP Relay ..........................201 DHCP Snoop ........................... 205 2684 Routed Mode ........................209 PPPoA to PPPoE ........................217 DSCP ............................223 IES-1248-71/73 User’s Guide...
Page 10 Packet Filter Commands ......................349 IP Commands .......................... 353 Firmware and Configuration File Maintenance ................ 357 SNMP ............................363 ADSL Commands ........................365 Virtual Channel Management ....................395 ACL Commands ........................419 Troubleshooting ........................425 Appendices and Index ......................437 IES-1248-71/73 User’s Guide...
Page 11: Table Of Contents
2.3 Connecting the Frame Ground .................... 50 Chapter 3 Front Panel Connections ....................... 53 3.1 Front Panel .......................... 53 3.1.1 Front Panel Ports ....................... 53 3.1.2 Front Panel LEDs ....................... 54 3.2 1000/100M Auto-Sensing Ethernet ..................55 3.2.1 Ethernet Default Settings ................... 55 IES-1248-71/73 User’s Guide...
Page 12 5.1 Power Connections Overview ..................... 69 5.2 Power Connections ......................70 5.2.1 AC Power Connections (IES-1248-71 AC Power Version Only) ........ 70 5.2.2 DC Power Connections (IES-1248-71, IES-1248-73) ..........70 5.3 Procedure to Turn on the IES-1248 Power ................70 Chapter 6 Fan Maintenance........................
Page 13 13.2.3 Daisychain Switch Mode ..................112 13.2.4 Port Isolation with Daisychain Switch Mode Example ..........112 13.3 Switch Setup Screen ......................113 Chapter 14 IP Setup..........................117 Chapter 15 ENET Port Setup ........................119 Chapter 16 xDSL Port Setup........................121 IES-1248-71/73 User’s Guide...
Page 14 Chapter 18 xDSL Line Data........................151 18.1 xDSL Line Rate Info Screen .................... 151 18.2 xDSL Performance Screen ....................152 18.3 xDSL Line Data Screen ....................155 Part III: Advanced Application ............157 Chapter 19 VLAN ............................159 IES-1248-71/73 User’s Guide...
Page 15 22.3 MVLAN Setup Screen ..................... 180 22.4 MVLAN Group Screen ..................... 182 Chapter 23 Filtering..........................185 23.1 Packet Filter Screen ......................185 Chapter 24 MAC Filter ..........................187 24.1 MAC Filter Introduction ....................187 24.2 MAC Filter Screen ......................187 IES-1248-71/73 User’s Guide...
Page 16 30.1 2684 Routed Mode ......................209 30.1.1 2684 Routed Mode Example .................. 209 30.2 2684 Routed PVC Screen ....................210 30.3 2684 Routed Domain Screen ..................212 30.4 RPVC Arp Proxy Screen ....................213 30.5 2684 Routed Gateway Screen ..................214 IES-1248-71/73 User’s Guide...
Page 17 Syslog ............................ 239 36.1 Syslog ..........................239 36.2 SysLog Screen ........................ 239 Chapter 37 Access Control........................241 37.1 Access Control Screen ....................241 37.2 Access Control Overview ....................241 37.3 SNMP ..........................241 37.3.1 Supported MIBs ..................... 243 IES-1248-71/73 User’s Guide...
Page 18 41.2 Log Format ........................267 41.2.1 Log Messages ......................267 41.3 LDM Test Parameters ...................... 268 41.4 ToneDiag Parameters ...................... 269 Chapter 42 MAC Table..........................271 42.1 Introduction to MAC Table ....................271 42.2 MAC Table Screen ......................272 IES-1248-71/73 User’s Guide...
Page 19 46.3 Alarm Show Command ....................305 46.4 Alarm Port Show Command .................... 306 46.5 Alarm Port Set Command ....................307 46.6 Alarm Tablelist Command ....................308 46.7 Log Format ........................309 46.8 Alarm History Show Command ..................310 IES-1248-71/73 User’s Guide...
Page 20 48.4 IEEE VLAN1Q Tagged VLAN Configuration Commands ..........322 48.4.1 VLAN Port Show Command ................... 322 48.4.2 VLAN PVID Command ................... 322 48.4.3 VLAN Priority Command ..................322 48.4.4 VLAN Set Command ....................323 48.4.5 VLAN Frame Type Command ................324 IES-1248-71/73 User’s Guide...
Page 21 50.4 IGMP Bandwidth Commands ..................338 50.4.1 IGMP Bandwidth Default Command ..............338 50.4.2 IGMP Bandwidth Set Command ................339 50.4.3 IGMP Bandwidth Delete Command ............... 339 50.5 IGMP Bandwidth Port Commands ................... 339 50.5.1 IGMP Bandwidth Port Disable Command .............. 339 IES-1248-71/73 User’s Guide...
Page 22 52.3.2 Ping Command ...................... 354 52.3.3 Route Set Command ....................354 52.3.4 Route Delete Command ..................355 52.3.5 Route Show Command ..................355 52.3.6 ARP Show Command .................... 355 52.3.7 ARP Flush Command .................... 356 52.4 Statistics IP Command ....................356 IES-1248-71/73 User’s Guide...
Page 23 55.1.15 ADSL Downstream Carrier1 Command ............... 374 55.1.16 PMM Parameters Command ................375 55.1.17 Impulse Noise Protection Command ..............376 55.1.18 Annex L Enable Command .................. 377 55.1.19 Annex L Disable Command ................. 377 55.2 Statistics ADSL Commands ..................... 378 IES-1248-71/73 User’s Guide...
Page 24 56.7.2 RPVC Gateway Set Command ................405 56.7.3 RPVC Gateway Show Command ................405 56.7.4 RPVC Gateway Delete Command ................. 405 56.7.5 RPVC Set Command ..................... 406 56.7.6 RPVC Show Command ..................407 56.7.7 RPVC Delete Command ..................407 IES-1248-71/73 User’s Guide...
Page 25 58.6 DSL Data Transmission ....................427 58.7 There Is No Voice on an ADSL Connection ..............427 58.8 Testing Wiring ........................428 58.9 Local Server ........................430 58.10 Data Rate ........................430 58.11 Configured Settings ....................... 431 IES-1248-71/73 User’s Guide...
Page 26 58.17 Recovering the Firmware ....................434 Part VI: Appendices and Index ............437 Appendix A Product Specifications..................439 Appendix B Removing and Installing a Fuse ............... 447 Appendix C Legal Information ....................449 Appendix D Customer Support..................... 453 Index............................457 IES-1248-71/73 User’s Guide...
Page 27: List Of Figures
Figure 5 Rack Mounting ......................... 50 Figure 6 IES-1248 Frame Ground ......................51 Figure 7 IES-1248-71 DC Power Version Front Panel ................53 Figure 8 IES-1248-71 AC Power Version Front Panel ................53 Figure 9 SFP Mini GBIC Slot ........................56 Figure 10 Transceiver Installation ......................
Page 28 Figure 76 Static VLAN Setting ......................162 Figure 77 VLAN Port Setting ........................ 164 Figure 78 Select Ports .......................... 165 Figure 79 IGMP Proxy Network Example ..................... 168 Figure 80 IGMP (Status) ........................169 Figure 81 IGMP Bandwidth ........................170 IES-1248-71/73 User’s Guide...
Page 29 Figure 119 ACL Setup .......................... 232 Figure 120 ACL Profile Setup ....................... 234 Figure 121 ACL Profile Map ......................... 236 Figure 122 Downstream Broadcast ...................... 237 Figure 123 SysLog ..........................239 Figure 124 Access Control ........................241 IES-1248-71/73 User’s Guide...
Page 30 Figure 163 VLAN CPU Set Command Example .................. 323 Figure 164 Modifying the Static VLAN Example ................... 324 Figure 165 VLAN Frame Type Command Example ................325 Figure 166 VLAN CPU Set Command Example .................. 325 Figure 167 VLAN CPU Set Command Example .................. 325 IES-1248-71/73 User’s Guide...
Page 31 Figure 206 IP Settings and Default Gateway Address Command Example ......... 354 Figure 207 Route Show Command Example ..................355 Figure 208 ARP Show Command Example ..................356 Figure 209 Statistics IP Command Example ..................356 Figure 210 FTP Put Configuration File Example .................. 357 IES-1248-71/73 User’s Guide...
Page 32 Figure 249 Linedata Command Example ..................... 379 Figure 250 Lineinfo Command Example ....................380 Figure 251 Lineperf Command Example ....................381 Figure 252 15 Minute Performance Command Example ..............382 Figure 253 1Day Performance Command Example ................384 IES-1248-71/73 User’s Guide...
Page 33 Figure 293 TLS PVC Set Command Example ..................417 Figure 294 TLS PVC Show Command Example ................. 417 Figure 295 ACL Profile Set Command Example .................. 420 Figure 296 ACL Profile Show Map Command Example ..............421 IES-1248-71/73 User’s Guide...
Page 34 Figure 303 Example Xmodem Upload ....................434 Figure 304 USER Telco-50 Pin Assignments ..................444 Figure 305 CO Telco-50 Pin Assignments .................... 444 Figure 306 Console Cable RJ-11 Male Connector ................445 Figure 307 Console Cable DB-9 Female Connector ................446 IES-1248-71/73 User’s Guide...
Page 35: List Of Tables
Table 33 Static VLAN Setting ....................... 162 Table 34 VLAN Port Setting ......................... 164 Table 35 IGMP (Status) ........................169 Table 36 IGMP Bandwidth ........................170 Table 37 Bandwidth Port Setup ......................172 Table 38 IGMP Setup .......................... 173 IES-1248-71/73 User’s Guide...
Page 36 Table 76 SNMP ............................ 245 Table 77 Service Access Control ......................246 Table 78 Remote Management (Secured Client Setup) ..............247 Table 79 Static Routing ........................251 Table 80 Alarm Status .......................... 253 Table 81 Alarm Descriptions ........................ 254 IES-1248-71/73 User’s Guide...
Page 37 Table 119 Power Input Specifications ....................440 Table 120 Fuse Specifications (IES-1248-71 AC Power Version) ............440 Table 121 Fuse Specifications (IES-1248-71 DC power version and IES-1248-73) ......440 Table 122 Default Settings ........................442 Table 123 Hardware Telco-50 Connector Port and Pin Numbers ............444 Table 124 Console Cable Connector Pin Assignments ...............
Page 38 List of Tables IES-1248-71/73 User’s Guide...
Page 39: Introduction
Introduction Getting to Know the IES-1248 (41) Product Specifications (439) Hardware Installation (47) Front Panel Connections (53) MDF Connections (61) Power Connections (69) Fan Maintenance (71)
Page 41: Getting To Know The Ies-1248
(MTU), that leverages existing phone line wiring to provide Internet access to all tenants. Note that ADSL service can coexist with voice service on the same line. IES-1248-71/73 User’s Guide...
Page 42: Curbside Application
The IES-1248 can also be used by an Internet Service Provider (ISP) in a street cabinet to form a “mini POP (Point-of-Presence)” to provide broadband services to residential areas that are too far away from the ISP to avail of DSL services. Residents need an ADSL modem, connected as shown in the previous figure. IES-1248-71/73 User’s Guide...
Page 43: Other Applications
You can use mini GBIC transceivers for fiber connections to backbone Ethernet switches. Stacking Daisy-chain up to three IES-1248 (or other Ethernet devices). Integrated Splitters The integrated DSL splitter eliminates the need to use external splitters that separate the voice- band and ADSL signals. IES-1248-71/73 User’s Guide...
Page 44 ATM Quality of Service (QoS) allows you to regulate the average rate and fluctuations of data transmission. This helps eliminate congestion to allow the transmission of real time data (such as audio and video). IES-1248-71/73 User’s Guide...
Page 45 With IGMP snooping, group multicast traffic is only forwarded to ports that are members of that group. IGMP Snooping generates no additional network traffic, allowing you to significantly reduce multicast traffic passing through your IES-1248. Up to eight channels on each DSL port at the time of writing. IES-1248-71/73 User’s Guide...
Page 46 (R)STP detects and breaks network loops and provides backup links between switches, bridges or routers. It allows a switch to interact with other (R)STP -compliant switches in your network to ensure that only one path exists between any two stations on the network. IES-1248-71/73 User’s Guide...
Page 47: Hardware Installation
4 Remove the adhesive backing from the rubber feet. 5 Attach the rubber feet to each corner on the bottom of the IES-1248. These rubber feet help protect the IES-1248 from shock or vibration and ensure space between IES-1248 when stacking. IES-1248-71/73 User’s Guide...
Page 48: Rack-Mounted Installation
Take all necessary precautions to anchor the rack securely before installing the unit. • Use a #2 Philips screwdriver to install the screws. • See Appendix A on page 439 for the gauge of wire to use for the frame ground connections. IES-1248-71/73 User’s Guide...
Page 49: Figure 4 Attaching Mounting Brackets And Screws
3 After attaching both mounting brackets, position the IES-1248 in the rack by lining up the holes in the brackets with the appropriate holes on the rack. Secure the IES-1248 to the rack with the rack-mounting screws. IES-1248-71/73 User’s Guide...
Page 50: Connecting The Frame Ground
Chapter 2 Hardware Installation Figure 5 Rack Mounting 2.3 Connecting the Frame Ground Follow the directions in this section for the IES-1248-71 DC power version and IES-1248-73. This section is not applicable for the IES-1248-71 AC power version. Appendix A on page 439 for the ground wire gauge.
Page 51: Figure 6 Ies-1248 Frame Ground
Chapter 2 Hardware Installation Figure 6 IES-1248 Frame Ground Frame Ground IES-1248-71/73 User’s Guide...
Page 52 Chapter 2 Hardware Installation IES-1248-71/73 User’s Guide...
Page 53: Front Panel Connections
IES-1248’s front panel. 3.1 Front Panel The following figure shows the front panel of the IES-1248. Figure 7 IES-1248-71 DC Power Version Front Panel Figure 8 IES-1248-71 AC Power Version Front Panel 3.1.1 Front Panel Ports The following table describes the ports on the front panel of the IES-1248.
Page 54: Front Panel Leds
There is not a link to a 1000 Mbps (1 Gbps) Ethernet network or the 1000 Mbps network link is down. SFP 1,2 ACT Green Blinking The system is transmitting/receiving Ethernet traffic. The system is not transmitting/receiving Ethernet traffic. IES-1248-71/73 User’s Guide...
Page 55: 1000/100M Auto-Sensing Ethernet
Pluggable (SFP) Transceiver MultiSource Agreement (MSA). See the SFF committee’s INF- 8074i specification Rev 1.0 for details. You can change transceivers while the IES-1248 is operating. You can use different transceivers to connect to Ethernet switches with different types of fiber-optic connectors. IES-1248-71/73 User’s Guide...
Page 56: Transceiver Installation
3 Insert the fiber-optic cables into the transceiver (you may need to remove cable dust covers). 4 Insert the transceiver into the IES-1248’s SFP slot with the exposed section of PCB board facing down. 5 Press the transceiver firmly until it clicks into place. Figure 10 Transceiver Installation IES-1248-71/73 User’s Guide...
Page 57: Transceiver Removal
1 Remove the fiber-optic cables from the transceiver. 2 Unlock the transceiver’s latch (latch styles vary). 3 Pull the transceiver out of the slot. 4 Put the transceiver’s dust cover on the transceiver. Figure 12 Opening the Transceiver Latch IES-1248-71/73 User’s Guide...
Page 58: Console Port Connection
2 and 6. Examples of an alarm on the IES-1248 are when the IES-1248’s voltage or temperature is outside of the normal range. Figure 14 ALARM Pins Layout Pin 5 Pin 1 Pin 9 Pin 6 IES-1248-71/73 User’s Guide...
Page 59: Adsl Connections
1248 has a built-in splitter that separates the high frequency ADSL signal from the voice band signal and feeds the ADSL signal to the IES-1248, while the voice band signal is diverted to the CO port. See Chapter 4 on page 61 for more information on the Telco-50 connections. IES-1248-71/73 User’s Guide...
Page 60 Chapter 3 Front Panel Connections IES-1248-71/73 User’s Guide...
Page 61: Mdf Connections
Figure 15 MDF (Main Distribution Frame) Wiring • Connect wiring to end-user equipment to the lower ports of an MDF and connect wiring from the telephone company to the upper ports of an MDF (see the previous figure). IES-1248-71/73 User’s Guide...
Page 62: Telco-50 Cables
Connect the CO Telco-50 connectors to the PBX or PSTN/ISDN switch. Connect the USER Telco-50 connectors to the subscribers’ telephone wiring. In most multi- tenant unit applications, the USER pins connect to the subscribers’ telephone wiring via Main Distribution Frame (MDF). IES-1248-71/73 User’s Guide...
Page 63: Mdf Scenarios
MDFs. There is no phone service and you want to install the IES-1248 for data-access only. You may connect using an MDF or attach RJ-11 connectors to the non-IES-1248 end of the Telco-50 cable and then connect to DSL modems directly. IES-1248-71/73 User’s Guide...
Page 64: Installation Scenario B
(see the next figure). Figure 19 One MDF for End-user and CO Connections This installation scenario requires three MDFs. Please see the following figure for the connection schema. • MDF 1 is the original MDF used for telephone connections only. IES-1248-71/73 User’s Guide...
Page 65: Figure 20 Installation Scenario B
5 Connect the wiring on the other side of the Telco-50 cable to the lower ports of MDF 2 using a punch-down tool. 6 Connect the upper ports of MDF 2 to the lower ports of MDF 1 using telephone wires. 7 Connect the upper ports of MDF 1 to the telephone company. IES-1248-71/73 User’s Guide...
Page 66: Installation Scenario C
• MDFs 1 and 2 are the two original MDFs. • MDFs 3 and 4 are two additional MDFs you need. User A still has telephone service only. User B now has telephone and DSL service (see the following figure) IES-1248-71/73 User’s Guide...
Page 67: Figure 22 Installation Scenario C
6 Connect the wiring on the other side of the Telco-50 cable to the lower ports of MDF 4 using a punch-down tool. 7 Connect the top ports of MDF 4 to the bottom ports of MDF 1 using telephone wires. 8 Connect the top ports of MDF 1 to the telephone company. IES-1248-71/73 User’s Guide...
Page 68 Chapter 4 MDF Connections IES-1248-71/73 User’s Guide...
Page 69: Power Connections
IES-1248-71 DC power version and IES-1248-73 power connections. • (IES-1248-71 AC power version only) Use the included power cord for the IES-1248’s power connections. • Keep the IES-1248 power switch in the OFF position until you come to the procedure for turning on the power.
Page 70: Power Connections
Chapter 5 Power Connections 5.2 Power Connections 5.2.1 AC Power Connections (IES-1248-71 AC Power Version Only) Connect the female end of the power cord to the power socket of your IES-1248. Connect the other end of the cord to a power outlet. Make sure that no objects obstruct the airflow of the fans.
Page 71: Fan Maintenance
1 Loosen the thumbscrew on the front of the fan module. 2 Slide out the fan module. 3 Use a different fan module from the manufacturer. 4 Slide the fan module into the fan module slot. 5 Tighten the thumbscrew. Figure 23 Fan Module Thumbscrews IES-1248-71/73 User’s Guide...
Page 72: Figure 24 Removing The Fan Module
Chapter 6 Fan Maintenance Figure 24 Removing the Fan Module Figure 25 Fan Module Removed IES-1248-71/73 User’s Guide...
Page 73: Basic Settings
Basic Settings Introducing the Web Configurator (75) Initial Configuration (83) Home and Port Statistics Screens (89) System Information (101) General Setup (105) Switch Setup (111) IP Setup (117) ENET Port Setup (119) xDSL Port Setup (121) xDSL Profiles Setup (137) xDSL Line Data (151)
Page 75: Introducing The Web Configurator
Use the following instructions to log on to the web configurator. 1 Launch your web browser, and enter the IP address of the IES-1248 (default: 192.168.1.1 is the factory default) in the Location or Address field. Press Enter. The Login screen appears. IES-1248-71/73 User’s Guide...
Page 76: Figure 26 Login
B - Click this to open the Home screen. (This is the same screen that is displayed above.) See Chapter 9 on page 89 for more information. C - Click this to log out of the web configurator. IES-1248-71/73 User’s Guide...
Page 77: Navigation Panel
Use this screen to configure general identification information about the device and the time and date settings. User Account Use this screen to configure system administrator accounts. Switch Setup Use this screen to set up system-wide parameters such as MAC address learning and priority queues. IES-1248-71/73 User’s Guide...
Page 78 Use this screen to configure service access control and configure SNMP and remote management. Routing Protocol Static Routing Use this screen to configure static routes. A static route defines how the IES- 1248 should forward traffic by configuring the TCP/IP parameters manually. Alarm IES-1248-71/73 User’s Guide...
Page 79: Changing Your Password
After you log in for the first time, it is recommended you change the default administrator password. Click Basic Setting and then User Account to display the User Account screen. Figure 28 User Account Click the index number 1 to edit the default administrator account settings. IES-1248-71/73 User’s Guide...
Page 80: Saving Your Configuration
Click Logout in any screen to exit the web configurator. You have to log in with your password again after you log out. This is recommended after you finish a management session both for security reasons and so you do not lock out other device administrators. IES-1248-71/73 User’s Guide...
Page 81: Figure 30 Logout
Chapter 7 Introducing the Web Configurator Figure 30 Logout IES-1248-71/73 User’s Guide...
Page 82 Chapter 7 Introducing the Web Configurator IES-1248-71/73 User’s Guide...
Page 83: Initial Configuration
3 Use this screen to change the IP address, subnet mask, and default gateway IP address for your network. Apply the settings. If you change the IP address of the IES-1248, after you click Apply IP setting, you have to use the new IP address to log into the web configurator again. IES-1248-71/73 User’s Guide...
Page 84: Figure 32 Xdsl Port Setup
VLAN ID. 5 In the navigation panel, click Basic Setting, xDSL Port Setup. The xDSL Port Setup screen appears. Figure 32 xDSL Port Setup 6 Click VC Setup. The following screen appears. IES-1248-71/73 User’s Guide...
Page 85: Figure 33 Vc Setup
Chapter 8 Initial Configuration Figure 33 VC Setup 7 Select any virtual channel’s Select radio button, and click Delete. The following screen appears. Figure 34 VC Setup, Delete 8 Click OK. The following screen appears. IES-1248-71/73 User’s Guide...
Page 86: Figure 35 Select Ports
10 Select Super Channel to allow the channel to forward frames belonging to multiple VLAN groups (that are not assigned to other channels). Then, enter the VPI and VCI that you use. Leave the other default settings, and click Add. The VC Setup screen is updated. IES-1248-71/73 User’s Guide...
Page 87: Figure 37 Vc Setup
11 Select the new channel’s Select radio button. Click Copy, and then click Paste. The following screen appears. The following screen appears. Figure 38 Select Ports 12 Click All, and then click Apply. The VC Setup screen is updated. IES-1248-71/73 User’s Guide...
Page 88: Figure 39 Vc Setup
Figure 41 Config Save, Save Successful You can now use the device (with the other settings set to the defaults) to provide service to ADSL subscribers. See Appendix A on page 439 for information on other default settings. IES-1248-71/73 User’s Guide...
Page 89: Home And Port Statistics Screens
The following fields are related to the Ethernet ports. ENET This field displays the number of the Ethernet port. Click a port number to display that port’s statistics screen. The Ethernet Port Statistics Screen appears. Section 9.1.1 on page IES-1248-71/73 User’s Guide...
Page 90: Ethernet Port Statistics Screen
Click this to set the Poll Interval(s) and Port fields to their default values and to refresh the screen. 9.1.1 Ethernet Port Statistics Screen Use this screen to display statistics about an Ethernet port. To open this screen, click an Ethernet port’s number in the Home screen. IES-1248-71/73 User’s Guide...
Page 91: Figure 43 Port Statistics (Ethernet)
This field shows the number of good broadcast frames received of 64 to 1518 octets in length (for non VLAN) or 1522 octets (for VLAN), not including multicast frames. Frames with range or length errors are also not taken into account. IES-1248-71/73 User’s Guide...
Page 92 64 octets or less in length (this includes FCS octets but excludes framing bits). packet(65-127) This field shows the number of frames received and transmitted (including bad frames) that were 65 to 127 octets in length (this includes FCS octets but excludes framing bits). IES-1248-71/73 User’s Guide...
Page 93: Adsl Port Statistics Screen
Click this to set the Poll Interval(s) and Port fields to their default values and to refresh the screen. 9.1.2 ADSL Port Statistics Screen Use this screen to display statistics about an ADSL port. To open this screen, click an ADSL port’s number in the Home screen. IES-1248-71/73 User’s Guide...
Page 94: Figure 44 Port Statistics (Adsl)
This field shows the number of broadcast packets received on this port. packets Tx discard packets This field shows the number of outgoing packets that were dropped on this port. The “Tx discard packets” counter always displays “0” because the IES-1248 does not discard packets that it sends. IES-1248-71/73 User’s Guide...
Page 95: Rmon Statistics Screen
Click this to set the Poll Interval(s) and Port fields to their default values and to refresh the screen. 9.1.3 RMON Statistics Screen Use this screen to display RMON statistics about a port. To open this screen, click RMON in the ADSL Port Statistics screen or Ethernet Port Statistics screen. IES-1248-71/73 User’s Guide...
Page 96: Figure 45 Port Statistics (Rmon)
EtherStatsCRCAlignErrors This field displays the total number of CRC (Cyclical Redundancy Check) alignment errors on this port. EtherStatsUndersizePkts This field displays the total number of packets that were too small received/transmitted on this port. IES-1248-71/73 User’s Guide...
Page 97: Rmon History Screen
9.1.4 RMON History Screen Use this screen to display general information (such as sample time) on history samples. To open this screen, click any port number in the RMON Statistics screen. IES-1248-71/73 User’s Guide...
Page 98: Rmon History Detail Screen
Utilization This field displays the port utilization status. 9.1.5 RMON History Detail Screen Use this screen to display detailed RMON history. To open this screen, click any index number in the RMON History screen. IES-1248-71/73 User’s Guide...
Page 99: Figure 47 Port Statistics (Rmon History Detail))
This field displays the total number of packets that were too big received/ transmitted in the sampling period. Fragments This is the number of frames received/transmitted that were less than 64 octets long, and contained an invalid FCS, including non-integral and integral lengths. IES-1248-71/73 User’s Guide...
Page 100 This is the number of frames for which transmission failed due to excessive collisions. Excessive collision is defined as the number of maximum collisions before the retransmission count is reset. Utilizations This field displays the port utilization status in the sampling period. IES-1248-71/73 User’s Guide...
Page 101: System Information
The System Information screen displays general device information (such as firmware version number) and hardware polling information (such as fan status). You can check the firmware version number and monitor the hardware status in this screen. To open this screen, click Basic Setting, System Information. IES-1248-71/73 User’s Guide...
Page 102: Figure 48 System Info
Table 11 System Info LABEL DESCRIPTION System Name This field displays the device 's model name. ZyNOS F/W Version This field displays the version number of the device’s current ZyXEL Network Operating System (ZyNOS) firmware including the date created. IES-1248-71/73 User’s Guide...
Page 103 This field displays the minimum RPM measured at this point. Average This field displays the average RPM measured at this sensor. Threshold (Low) This field displays the lowest RPM limit at this sensor. Threshold (Hi) This field displays the highest RPM limit at this sensor. IES-1248-71/73 User’s Guide...
Page 104 The text box displays how often (in seconds) this screen refreshes. You may change the refresh interval by typing a new number in the text box and then Set Interval clicking Set Interval. Stop Click Stop to halt statistic polling. IES-1248-71/73 User’s Guide...
Page 105: General Setup
Enter the geographic location of your device. You can use up to 31 ASCII characters; spaces are not allowed. Contact Person's Enter the name of the person in charge of this device. You can use up to 31 Name ASCII characters; spaces are not allowed. IES-1248-71/73 User’s Guide...
Page 106 1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to start configuring the screen again. IES-1248-71/73 User’s Guide...
Page 107: User Account
Select this check box to turn on the administrator account. Name Enter a user name for the administrator account. Password Enter a password for the administrator account. Retype Password to Re-enter the administrator account’s password to verify that you have entered it Confirm correctly. IES-1248-71/73 User’s Guide...
Page 108: Authentication Screen
Click Cancel to start configuring the screen afresh. 12.2 Authentication Screen Use this screen to set up the authentication policies and settings by which administrators can access the IES-1248. To open this screen, click Basic Setting, User Account, Authentication. Figure 51 Authentication IES-1248-71/73 User’s Guide...
Page 109: Table 14 User Account
Select middle to allow the administrator to use middle or low privilege commands. Select low to allow the administrator to use only low privilege commands. Low privilege commands are read only. Select deny to prevent the administrator from accessing the IES-1248. IES-1248-71/73 User’s Guide...
Page 110 Chapter 12 User Account IES-1248-71/73 User’s Guide...
Page 111: Switch Setup
(see Figure 52 on page 112 for an example). If you have multiple IES- 1248 connected on the same network and set to standalone mode, they do not all need to have the same port isolation setting. IES-1248-71/73 User’s Guide...
Page 112: Port Isolation With Standalone Switch Mode Example
In the example below, the IES-1248 1 has its Ethernet port one (ENET 1) connected to the Ethernet backbone switch (3) and it’s Ethernet port two (ENET2) connected to Ethernet port one (ENET 1) of the daisychained IES-1248 (2). IES-1248-71/73 User’s Guide...
Page 113: Switch Setup Screen
(3 in the figure). A and B also cannot communicate with C without their communications going through another switch or router. Figure 53 Port Isolation with Daisychain Switch Mode Example 13.3 Switch Setup Screen To open this screen, click Basic Setting, Switch Setup. IES-1248-71/73 User’s Guide...
Page 114: Figure 54 Switch Setup
Leave Timer sets the duration of the Leave Period timer for GVRP in milliseconds. Each port has a single Leave Period timer. Leave Time must be two times larger than Join Timer; the default is 600 milliseconds. IES-1248-71/73 User’s Guide...
Page 115 1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to begin configuring this screen afresh. IES-1248-71/73 User’s Guide...
Page 116 Chapter 13 Switch Setup IES-1248-71/73 User’s Guide...
Page 117: Ip Setup
Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to begin configuring the fields again. IES-1248-71/73 User’s Guide...
Page 118 Chapter 14 IP Setup IES-1248-71/73 User’s Guide...
Page 119: Enet Port Setup
Select 1000 Copper if the Ethernet port has a 1000 MB (1 gigabit) electrical connection. Select 1000 Fiber if the Ethernet port has a 1000 MB (1 gigabit) fiber optic connection. Duplex The IES-1248 uses full duplex Ethernet connections by default. IES-1248-71/73 User’s Guide...
Page 120 1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to begin configuring this screen afresh. IES-1248-71/73 User’s Guide...
Page 121: Xdsl Port Setup
G.dmt Annex B (IES-1248-73) 8160 Kbps 1024 Kbps G.lite (IES-1248-71/71A) 4096 Kbps 1024 Kbps ETSI (IES-1248-73) 8160 Kbps 1024 Kbps ANSI T1.413 issue 2 (IES-1248-71/71A) 8160 Kbps 1024 Kbps ADSL2 12000 Kbps 1200 Kbps ADSL2+ 25000 Kbps 1200 Kbps 16.2 Downstream and Upstream Downstream refers to traffic going out from the IES-1248 to the subscriber’s ADSL modem or...
Page 122: Interleave Delay
1248 automatically uses a maximum downstream rate of 8160 Kbps. This means that if you configure a profile with very high rates, you can still use it with any port. See Table 18 on page for a list of the maximum rates supported by the different ADSL standards. IES-1248-71/73 User’s Guide...
Page 123: Default Settings
DSL ports (see Section 16.9 on page 130). PPVC Setup Click PPVC Setup to open the PPVC Setup screen where you can configure priority PVC settings for the DSL ports (see Section 16.11 on page 134). IES-1248-71/73 User’s Guide...
Page 124: Figure 58 Select Ports
Alarm Profile Setup screen (see Section 17.6 on page 145). PVID & Priority Select this check box to copy this port’s PVID and priority settings. These are configured in the VLAN Port Setting screen (see Chapter 19 on page 159). IES-1248-71/73 User’s Guide...
Page 125: Xdsl Port Setting Screen
This is configured in the VC Setup screen (see Section 16.9 on page 130). 16.7.1 xDSL Port Setting Screen To open this screen, click Basic Setting, xDSL Port Setup, and then click a port’s index number. IES-1248-71/73 User’s Guide...
Page 126: Figure 59 Xdsl Port Setting
Select the port’s alarm profile. The alarm profile defines alarm thresholds for the ADSL port. The IES-1248 sends an alarm trap and generates a syslog entry when the thresholds of the alarm profile are exceeded (see Section 17.6 on page 145). IES-1248-71/73 User’s Guide...
Page 127 If you enter a number that is not a multiple of 4, the system uses the next lower multiple of 4. If you enter 39, for example, the system will use 36. Set this to 0 to have the system automatically assign a value. IES-1248-71/73 User’s Guide...
Page 128 1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to begin configuring the fields again. IES-1248-71/73 User’s Guide...
Page 129: Virtual Channels
Virtual channel profiles allow you to configure the virtual channels efficiently. You can configure all of the virtual channels with the same profile, thus removing the need to configure the virtual channels one-by-one. You can also change an individual virtual channel by assigning it a different profile. IES-1248-71/73 User’s Guide...
Page 130: Vc Setup Screen
VLAN groups (that are not assigned to other channels). The super channel functions in the same way as the channel in a single channel environment. Type the Virtual Path Identifier for a channel on this port. IES-1248-71/73 User’s Guide...
Page 131 (0 VID) received on this channel. An asterisk (*) denotes a super channel. Priority This is the priority value (0 to 7) added to incoming frames without a (IEEE 802.1p) priority tag. An asterisk (*) denotes a super channel. IES-1248-71/73 User’s Guide...
Page 132: Figure 61 Basic Setting, Xdsl Port Setup, Vc Setup, Delete
5 Select to which ports you want to copy the settings. Use All to select every port. Use None to clear all of the check boxes. 6 Click Apply to delete the channels. Figure 62 Select Ports IES-1248-71/73 User’s Guide...
Page 133: Priority-Based Pvcs
Table 22 IEEE 802.1p Priority to PPVC Mapping IEEE 802.1 PRIORITY MAPS TO: PPVC 0/33, PRIORITY QUEUE -> level 7 -> level 6 -> level 5 -> level 4 -> level 3 -> level 2 -> level 1 -> level 0 IES-1248-71/73 User’s Guide...
Page 134: Ppvc Setup Screen
The IES-1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non- volatile memory when you are done configuring. Cancel Click Cancel to start configuring the screen again. IES-1248-71/73 User’s Guide...
Page 135: Ppvc Setup Members Screen
The member PVCs must be created on the subscriber’s device. To open this screen, click Basic Setting, xDSL Port Setup, PPVC Setup. Then, click a PPVC’s member number to open the PPVC Setup Members screen. Figure 65 PPVC Setup, Edit IES-1248-71/73 User’s Guide...
Page 136: Table 24 Ppvc Setup, Edit
The IES-1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non- volatile memory when you are done configuring. Close Click Close to exit the screen without saving your changes. IES-1248-71/73 User’s Guide...
Page 137: Xdsl Profiles Setup
A profile is a list of settings that you define. Then you can assign them to one or more individual ports. For background information about many of these settings, see Chapter 16 on page 121. 17.1 Port Profile Screen To open this screen, click Basic Setting, xDSL Profiles Setup. Figure 66 Port Profile IES-1248-71/73 User’s Guide...
Page 138: Table 25 Port Profile
Type the target upstream signal to noise margin (0-31 dB). Configure the target upstream signal to noise margin to be greater than or equal to the minimum upstream signal to noise margin and less than or equal to the maximum upstream signal to noise margin. IES-1248-71/73 User’s Guide...
Page 139 1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to start configuring the screen again. IES-1248-71/73 User’s Guide...
Page 140: Atm Qos
The nrt-VBR (non real-time Variable Bit Rate) type is used with bursty connections that do not require closely controlled delay and delay variation. An example of an nrt-VBR connection would be non-time sensitive data file transfers. IES-1248-71/73 User’s Guide...
Page 141: Traffic Parameters
If the PCR, SCR or MBS is set to the default of “0”, the system will assign a maximum value that correlates to your upstream line rate. The following figure illustrates the relationship between PCR, SCR and MBS. IES-1248-71/73 User’s Guide...
Page 142: Figure 67 Pcr, Scr And Mbs In Traffic Shaping
C, it is discarded or tagged for not complying with the TAT. Time C is calculated based on the CDVT or BT. Figure 68 TAT, CDVT and BT in Traffic Shaping IES-1248-71/73 User’s Guide...
Page 143: Upstream Policing
PVC's upstream traffic (CBR, VBR, or UBR), the IES-1248 will drop any upstream traffic that violates the specified ATM VC profile. 17.5 VC Profile Screen To open this screen, click Basic Setting, xDSL Profiles Setup, VC Profile. IES-1248-71/73 User’s Guide...
Page 144: Figure 69 Vc Profile
Select a VC profile’s Select radio button and click Modify to edit the VC profile Modify Delete Select a VC profile’s Select radio button and click Delete to remove the VC profile The rest of the screen is for PVC configuration. IES-1248-71/73 User’s Guide...
Page 145: Alarm Profile Screen
To open this screen, click Basic Setting, xDSL Profiles Setup, Alarm Profile. Use the top part of the screen (with the Add and Cancel buttons) to add or edit alarm profiles. The rest of the screen displays the configured alarm profiles. IES-1248-71/73 User’s Guide...
Page 146: Figure 70 Alarm Profile
Click Cancel to start configuring the screen again. Threshold Specify limits for the individual performance counters. The IES-1248 sends an alarm trap and generates a syslog entry when one of these thresholds is exceeded. A value of 0 disables the alarm threshold. IES-1248-71/73 User’s Guide...
Page 147: Igmp Filtering
(such as content information distribution) based on service plans and types of subscription. You can set the device to filter the multicast group join reports on a per-port basis by configuring an IGMP filtering profile and associating the profile to a port. IES-1248-71/73 User’s Guide...
Page 148: Igmp Filter Profile Screen
To open this screen, click Basic Setting, xDSL Profiles Setup, IGMP Filter Profile. The top of the screen displays the configured IGMP filter profiles. Use the bottom part of the screen (with the Add and Cancel buttons) to add or edit alarm profiles. Figure 71 IGMP Filter Profile IES-1248-71/73 User’s Guide...
Page 149: Table 28 Igmp Filter Profile
1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to start configuring the screen again. IES-1248-71/73 User’s Guide...
Page 150 Chapter 17 xDSL Profiles Setup IES-1248-71/73 User’s Guide...
Page 151: Xdsl Line Data
155). Port Use this drop-down list box to select a port for which you wish to view information. Refresh Click Refresh to display updated information. Port Name This section displays the name of the port. IES-1248-71/73 User’s Guide...
Page 152: Xdsl Performance Screen
Info Service Mode This field displays the ADSL standard that the port is using. The IES-1248-71/ 71A uses G.dmt, G.lite, ANSI T1.413 issue 2, ADSL2, or ADSL2+. The IES- 1248-73 uses G.dmt Annex B, ETSI, ADSL2, or ADSL2+.
Page 153: Figure 73 Xdsl Performance
Chapter 18 xDSL Line Data To open this screen, click Basic Setting, xDSL Line Data, Line Performance. Figure 73 xDSL Performance IES-1248-71/73 User’s Guide...
Page 154: Table 30 Xdsl Performance
The number of Errored Seconds that have occurred within the period. init The number of successful initializations that have occurred within the period. The number of Severely Errored Seconds that have occurred within the period. The number of UnAvailable Seconds that have occurred within the period. IES-1248-71/73 User’s Guide...
Page 155: Xdsl Line Data Screen
In the screen shown, the downstream channel is carried on tones 48 to 255 and the upstream channel is carried on tones 16 to 31 (space is left between the channels to avoid interference). Figure 74 xDSL Line Data IES-1248-71/73 User’s Guide...
Page 156: Table 31 Xdsl Line Data
(from the IES-1248 to the subscriber’s DSL modem or router). “US carrier load” displays the number of bits received per DMT tone for the upstream channel (from the subscriber’s DSL modem or router to the IES- 1248). IES-1248-71/73 User’s Guide...
Page 157: Advanced Application
Advanced Application VLAN (159) IGMP (167) Static Multicast (177) Multicast VLAN (179) Filtering (185) MAC Filter (187) Spanning Tree Protocol (189) Port Authentication (195) Port Security (199) DHCP Relay (201) DHCP Snoop (205) 2684 Routed Mode (209) PPPoA to PPPoE (217) DSCP (223) TLS PVC (227) ACL (231)
Page 159: Vlan
4,096 (2^12) VLANs. Note that user priority and VLAN ID are independent of each other. A frame with VID (VLAN Identifier) of null (0) is GVRP (GARP VLAN Registration Protocol) defines a way for switches to automatically configure switches in a VLAN network. IES-1248-71/73 User’s Guide...
Page 160: Forwarding Tagged And Untagged Frames
VID of a frame, then the frame is transmitted as a tagged frame; otherwise, it is transmitted as an untagged frame. 19.3 VLAN Status Screen To open this screen, click Advanced Application, VLAN. IES-1248-71/73 User’s Guide...
Page 161: Figure 75 Vlan Status
T, an untagged port is marked as U and ports not participating in a VLAN are marked as “–“. Elapsed Time This field shows how long it has been since a normal VLAN was registered or a static VLAN was set up. IES-1248-71/73 User’s Guide...
Page 162: Static Vlan Setting Screen
Click VLAN Status to see which of the IES-1248’s ports are members of which VLANs (see Section 19.3 on page 160) VLAN Port Setting Click VLAN Port Setting to specify Port VLAN IDs (PVIDs). See Section 19.5 on page 163. IES-1248-71/73 User’s Guide...
Page 163: Vlan Port Setting Screen
19.5 VLAN Port Setting Screen Use this screen to specify port VLAN IDs and to set whether or not Ethernet ports propagate VLAN information to other devices. To open this screen, click Advanced Application, VLAN, VLAN Port Setting. IES-1248-71/73 User’s Guide...
Page 164: Figure 77 Vlan Port Setting
Click Apply to save your changes to the IES-1248’s volatile memory. The IES- 1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. IES-1248-71/73 User’s Guide...
Page 165: Figure 78 Select Ports
4 Click Apply to paste the settings. Figure 78 Select Ports At the time of writing, the VLAN Acceptable Frame Type field is read-only for the Ethernet ports. The IES-1248 accepts both tagged and untagged incoming frames on the Ethernet ports. IES-1248-71/73 User’s Guide...
Page 166 Chapter 19 VLAN IES-1248-71/73 User’s Guide...
Page 167: Igmp
IGMP snooping generates no additional network traffic, allowing you to significantly reduce multicast traffic passing through your device. 20.2.2 IGMP Proxy To allow better network performance, you can use IGMP proxy instead of a multicast routing protocol in a simple tree network topology. IES-1248-71/73 User’s Guide...
Page 168: Igmp Status Screen
In daisychain mode, Ethernet interface 1 is set as the upstream interface and Ethernet interface 2 and the DSL ports are set as downstream interfaces. 20.3 IGMP Status Screen Use this screen to view current IGMP information. To open this screen, click Advanced Application, IGMP. IES-1248-71/73 User’s Guide...
Page 169: Figure 80 Igmp (Status)
This is how many IGMP groups the IES-1248 has identified on the local Groups network. Previous Click one of these buttons to show the previous/next screen if all of the information cannot be seen in one screen. Next Reload Click this button to refresh the screen. IES-1248-71/73 User’s Guide...
Page 170: Igmp Bandwidth Screen
Click Port Setup to open the Bandwidth Port Setup screen where you can set up multicast bandwidth requirements on specified ports (see Section 20.4.1 on page 171). Default Bandwidth Enter the default bandwidth for multicast channels for which you have not configured bandwidth requirements. IES-1248-71/73 User’s Guide...
Page 171: Bandwidth Port Setup Screen
Click this to un-select all entries in the table. 20.4.1 Bandwidth Port Setup Screen Use this screen to set up multicast bandwidth requirements for specific ports. To open this screen, click Advanced Application, IGMP, Bandwidth Setup, Port Setup. IES-1248-71/73 User’s Guide...
Page 172: Igmp Setup Screen
Select None Click this to un-select all entries in the table. 20.5 IGMP Setup Screen Use this screen to configure your IGMP settings. To open this screen, click Advanced Application, IGMP, IGMP Setup. Figure 83 IGMP Setup IES-1248-71/73 User’s Guide...
Page 173: Igmp Filter Setup Screen
2 channels at a time. This also effectively limits the subscriber to using only two IPTVs with the DSL connection. To open this screen, click Advanced Application, IGMP, Count Setup. IES-1248-71/73 User’s Guide...
Page 174: Igmp Port Info Screen
Click this to un-select all entries in the table. 20.8 IGMP Port Info Screen Use this screen to display the current number of IGMP-related packets received on each port. To open this screen, click Advanced Application, IGMP, IGMP Port Info. IES-1248-71/73 User’s Guide...
Page 175: Igmp Port Group Screen
This resets every counter in this screen. 20.9 IGMP Port Group Screen Use this screen to display the current list of multicast groups each port joins. To open this screen, click Advanced Application, IGMP, IGMP Port Group. Figure 86 IGMP Port Group IES-1248-71/73 User’s Guide...
Page 176: Table 41 Igmp Port Group
This field shows the IP address of the multicast group joined by this port. Source IP This field shows the IP address of the client that joined the multicast group on this port. Refresh Click Refresh to display updated information. IES-1248-71/73 User’s Guide...
Page 177: Static Multicast
The Number of This is the number of static multicast entries configured on the IES-1248. Static Multicast Page X of X This identifies which page of information is displayed and the total number of pages of information. IES-1248-71/73 User’s Guide...
Page 178 Clicking Add saves your changes to the IES-1248’s volatile memory. The IES- 1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. IES-1248-71/73 User’s Guide...
Page 179: Multicast Vlan
Ethernet port should join the multicast VLAN. 22.2 MVLAN Status Screen Use this screen to look at a summary of all multicast VLAN on the IES-1248. To open this screen, click Advanced Application, Multicast VLAN. Figure 88 MVLAN Status IES-1248-71/73 User’s Guide...
Page 180: Mvlan Setup Screen
This field shows whether this multicast VLAN is active (Enable) or inactive (Disable). 22.3 MVLAN Setup Screen Use this screen to configure basic settings and port members for each multicast VLAN. To open this screen, click Advanced Application, Multicast VLAN, MVLAN Setup. IES-1248-71/73 User’s Guide...
Page 181: Figure 89 Mvlan Setup
Select this if you want the multicast VLAN to be active. Clear this if you want the multicast VLAN to be inactive. Name Enter a descriptive name for the multicast VLAN. The name can be 1-31 printable ASCII characters long. Spaces are not allowed. IES-1248-71/73 User’s Guide...
Page 182: Mvlan Group Screen
Click Cancel to begin configuring the fields afresh. 22.4 MVLAN Group Screen Use this screen to configure ranges of multicast IP addresses for each multicast VLAN. To open this screen, click Advanced Application, Multicast VLAN, MVLAN Group. Figure 90 MVLAN Group IES-1248-71/73 User’s Guide...
Page 183: Table 45 Mvlan Group
This field displays the end of this range of multicast IP addresses. Select Select this, and click Delete to remove the multicast VLAN group. Delete Click this to remove the selected multicast VLAN groups. Cancel Click Cancel to begin configuring the fields afresh. IES-1248-71/73 User’s Guide...
Page 184 Chapter 22 Multicast VLAN IES-1248-71/73 User’s Guide...
Page 185: Filtering
Select the check boxes of the types of packets to accept on the ADSL port. When you clear one of these check boxes, the field label changes to Filter Out and the system drops the corresponding type of packets IES-1248-71/73 User’s Guide...
Page 186 When you select PPPoE Only,”#” appears for all of the packet types. With PPPoE Only, the IES-1248 rejects all packet types except for PPPoE (packet types that are not listed are also rejected). IES-1248-71/73 User’s Guide...
Page 187: Mac Filter
Type a device’s MAC address in hexadecimal notation (xx:xx:xx:xx:xx:xx, where x is a number from 0 to 9 or a letter from a to f) in this field. The MAC address must be a valid MAC address. IES-1248-71/73 User’s Guide...
Page 188 Click Apply to save your changes to the IES-1248’s volatile memory. The IES- 1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. IES-1248-71/73 User’s Guide...
Page 189: Spanning Tree Protocol
After a bridge determines the lowest cost-spanning tree with RSTP, it enables the root port and the ports that are the designated ports for the connected LANs, and disables all other ports that participate in RSTP. Network packets are therefore only forwarded between enabled ports, eliminating any possible network loops. IES-1248-71/73 User’s Guide...
Page 190: Figure 93 Stp Root Ports And Designated Ports
Forwarding Forwarding All BPDUs are received and processed. All information frames are received and forwarded. See the IEEE 802.1w standard for more information on RSTP. See the IEEE 802.1D standard for more information on STP. IES-1248-71/73 User’s Guide...
Page 191: Spanning Tree Protocol Status Screen
This is the number of times the spanning tree has been reconfigured. times Time since change This is the time since the spanning tree was last reconfigured. Cost to root This is the path cost from the root port on this switch to the root switch. IES-1248-71/73 User’s Guide...
Page 192: Spanning Tree Protocol Screen
Set Interval clicking Set Interval. Stop Click Stop to halt STP statistic polling. 25.3 Spanning Tree Protocol Screen To open this screen, click Advanced Application, Spanning Tree Protocol, STP Config. IES-1248-71/73 User’s Guide...
Page 193: Figure 95 Spanning Tree Protocol
(provided in the last BPDU) becomes the designated port for the attached LAN. If it is a root port, a new root port is selected from among the switch ports attached to the network. The allowed range is 6 to 40 seconds. IES-1248-71/73 User’s Guide...
Page 194 1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to begin configuring this screen afresh. IES-1248-71/73 User’s Guide...
Page 195: Port Authentication
At the time of writing, Windows XP of the Microsoft operating systems supports 802.1x. See the Microsoft web site for information on other Windows operating system support. For other operating systems, see its documentation. If your operating system does not support 802.1x, then you may need to install 802.1x client software. IES-1248-71/73 User’s Guide...
Page 196: Radius Screen
Select this check box to have the IES-1248 use its internal database of user Setting names and passwords to authenticate users. Name Type the user name of the user profile. Password Type a password up to 31 characters long for this user profile. IES-1248-71/73 User’s Guide...
Page 197: Screen
Table 53 802.1x LABEL DESCRIPTION RADIUS/Local Click this link to configure the RADIUS server or local profile settings (see Profile Section 26.2 on page 196). Enable Select this check box to turn on IEEE 802.1x authentication on the switch. IES-1248-71/73 User’s Guide...
Page 198 1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to begin configuring this screen afresh. IES-1248-71/73 User’s Guide...
Page 199: Port Security
1~128. Address Note: If you also use MAC filtering on a port, it is recommended that you set this limit to be equal to or greater than the number of MAC filter entries you configure. IES-1248-71/73 User’s Guide...
Page 200: Figure 100 Select Ports
3 Select to which ports you want to copy the settings. Use All to select every port. Use None to clear all of the check boxes. 4 Click Apply to paste the settings. Figure 100 Select Ports IES-1248-71/73 User’s Guide...
Page 201: Dhcp Relay
The next field is 2 bytes and displays the DHCP request packet’s VLAN ID. The last field (A) can range from 0 to 24 bytes and is optional information (that you specify) about this relay agent. Figure 101 DHCP Relay Agent Circuit ID Sub-option Format IES-1248-71/73 User’s Guide...
Page 202: Dhcp Relay Screen
ADSL name and ADSL telephone number fields are separated by forward slashes. Figure 102 DHCP Relay Agent Remote ID Sub-option Format 28.3 DHCP Relay Screen To open this screen, click Advanced Application, DHCP Relay. Figure 103 DHCP Relay IES-1248-71/73 User’s Guide...
Page 203: Table 55 Dhcp Relay
DHCP requests. Secondary Server This field displays the IP address of a second DHCP server to which the switch should relay DHCP requests. This field is 0.0.0.0 if the primary server is the only DHCP relay. IES-1248-71/73 User’s Guide...
Page 204 Select the check box in the Select column for an entry, and click Delete to remove the entry. Delete Select All Click this to select all entries in the Server List. Select None Click this to un-select all entries in the Server List. IES-1248-71/73 User’s Guide...
Page 205: Dhcp Snoop
DHCP Counter Click DHCP Counter to open the screen where you can look at a summary of the DHCP packets on each port (see Section 29.4 on page 207). Port This field displays each ADSL port number. IES-1248-71/73 User’s Guide...
Page 206: Dhcp Snoop Status Screen
This field displays the number of requests from DHCP clients above this limit. Appendix A on page 439 for the current specification. Overflow requests are dropped by the IES-1248. This field displays the IP address assigned to a client on this port. IES-1248-71/73 User’s Guide...
Page 207: Dhcp Counter Screen
This field displays the number of DHCP Offer packets on this port. Request This field displays the number of DHCP Request packets on this port. This field displays the number of DHCP Acknowledge packets on this port. IES-1248-71/73 User’s Guide...
Page 208 Appendix A on page 439 for the current specification. Overflow requests are dropped by the IES-1248. Clear Click Clear to delete the information the IES-1248 has learned about DHCP packets. This resets every counter in this screen. IES-1248-71/73 User’s Guide...
Page 209: 2684 Routed Mode
192.168.10.200. The routed domain is the LAN IP addresses behind the CPE device. The CPE device’s LAN IP address is 10.10.10.10 and the LAN computer’s IP address is 10.10.10.1. This includes the CPE device’s LAN IP addresses and the IP addresses of the LAN computers. IES-1248-71/73 User’s Guide...
Page 210: 2684 Routed Pvc Screen
• The subnet range of any RPVC and RPVC domain must be unique. 30.2 2684 Routed PVC Screen Use this screen to configure PVCs for 2684 routed mode traffic. To open this screen, click Advanced Application, 2684 Routed Mode. IES-1248-71/73 User’s Guide...
Page 211: Figure 108 2684 Routed Pvc
Config Save link on the navigation panel to save your changes to the non- volatile memory when you are done configuring. Cancel Click Cancel to start configuring the screen again. Index This field displays the number of the routed PVC. IES-1248-71/73 User’s Guide...
Page 212: 2684 Routed Domain Screen
IP addresses behind the subscriber’s device (the CPE). This includes the CPE device’s LAN IP addresses and the IP addresses of the LAN computers. To open this screen, click Advanced Application, 2684 Routed Mode, Routed Domain. Figure 109 2684 Routed Domain IES-1248-71/73 User’s Guide...
Page 213: Rpvc Arp Proxy Screen
Use this screen to view the Address Resolution Protocol table of IP addresses of CPE devices using 2684 routed mode and configure how long the device is to store them. To open this screen, click Advanced Application, 2684 Routed Mode, RPVC ARP Proxy. IES-1248-71/73 User’s Guide...
Page 214: 2684 Routed Gateway Screen
Flush Click Flush to remove all of the entries from the ARP table. 30.5 2684 Routed Gateway Screen Use this screen to configure gateway settings. To open this screen, click Advanced Application, 2684 Routed Mode, Routed Gateway. IES-1248-71/73 User’s Guide...
Page 215: Figure 111 2684 Routed Gateway
The IES-1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non- volatile memory when you are done configuring. Cancel Click Cancel to start configuring the screen again. IES-1248-71/73 User’s Guide...
Page 216 Chapter 30 2684 Routed Mode IES-1248-71/73 User’s Guide...
Page 217: Pppoa To Pppoe
Use this screen to set up PPPoA to PPPoE conversions on each port. This conversion is set up by creating a PAE PVC. See Chapter 16 on page 121 for background information about creating PVCs. To open this screen, click Advanced Application, PPPoA to PPPoE. IES-1248-71/73 User’s Guide...
Page 218: Figure 113 Pppoa To Pppoe
Note: Make sure the VID is not already used for multicast VLAN or TLS PVC. Priority Use the drop-down list box to select the priority value (0 to 7) to add to incoming frames without a (IEEE 802.1p) priority tag. IES-1248-71/73 User’s Guide...
Page 219 Select the check box in the Select column for an entry, and click Delete to remove the entry. Delete Select All Click this to select all entries in the table. Select None Click this to un-select all entries in the table. IES-1248-71/73 User’s Guide...
Page 220: Pppoa To Pppoe Status Screen
This field displays how long the current session has been up. AC Name This field displays the hostname of the remote access concentrator if there are two access concentrators (or BRAS) on the network or if you want to allow PAE translation to the specified access concentrator. IES-1248-71/73 User’s Guide...
Page 221 IES-1248 checks the AC name field in the BRAS's reply PDU and finds a mismatch, however. PPPoE Generic This field displays the number of other types of errors that occur in the PPPoE Error session between the IES-1248 and the BRAS. IES-1248-71/73 User’s Guide...
Page 222 Chapter 31 PPPoA to PPPoE IES-1248-71/73 User’s Guide...
Page 223: Dscp
The higher the value, the higher the priority. Lower-priority packets may be dropped if the total traffic exceeds the capacity of the network. 32.2 DSCP Setup Screen Use this screen to activate or deactivate DSCP on each port. To open this screen, click Advanced Application, DSCP. Figure 115 DSCP Setup IES-1248-71/73 User’s Guide...
Page 224: Dscp Map Screen
Table 66 DSCP Map LABEL DESCRIPTION DSCP Map Click DSCP Setup to open the screen where you can activate or deactivate DSCP on each port (see Section 32.2 on page 223). Source DSCP This field displays each DSCP value. IES-1248-71/73 User’s Guide...
Page 225 Click Apply to save your changes to the IES-1248’s volatile memory. The IES- 1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. IES-1248-71/73 User’s Guide...
Page 226 Chapter 32 DSCP IES-1248-71/73 User’s Guide...
Page 227: Tls Pvc
VLANs within its network by adding tag 37 to distinguish customer A and tag 48 to distinguish customer B at edge device 1 and then stripping those tags at edge device 2 as the data frames leave the network. IES-1248-71/73 User’s Guide...
Page 228: Tls Pvc Screen
Use this screen to set up Transparent LAN Services on each port. This is set up by creating a TLS PVC. See Chapter 16 on page 121 for background information about creating PVCs. To open this screen, click Advanced Application, TLS PVC. You can NOT configure PPPoA-to-PPPoE and TLS settings on the same PVC. IES-1248-71/73 User’s Guide...
Page 229: Figure 118 Tls Pvc
Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to start configuring the screen again. IES-1248-71/73 User’s Guide...
Page 230 Select the check box in the Select column for an entry, and click Delete to remove the entry. Delete Select All Click this to select all entries in the table. Select None Click this to un-select all entries in the table. IES-1248-71/73 User’s Guide...
Page 231: Acl
<eport> {|dstport <sport> <eport>}}}}} The input values for these values have the following ranges. • <vid>: 1~4094 • <priority>: 1~7 • <etype>: 0~65535 • <protocol>: tcp|udp|ospf|igmp|ip|gre|icmp|<ptype> • <ptype>: 0~255 • <mask>: 0~32 • <tos>: 0~255 • <port>: 0~65535 IES-1248-71/73 User’s Guide...
Page 232: Acl Profile Actions
VLAN ID of the traffic (901) to the VID of the PVC (900), the IES-1248 drops the packets because they do not match. 34.2 ACL Setup Screen Use this screen to assign ACL profiles to each PVC. To open this screen, click Advanced Application, ACL. Figure 119 ACL Setup IES-1248-71/73 User’s Guide...
Page 233: Acl Profile Setup Screen
Click this to select all entries in the table. Select None Click this to un-select all entries in the table. 34.3 ACL Profile Setup Screen Use this screen to set up ACL profiles. To open this screen, click Advanced Application, ACL, ACL Profile Setup. IES-1248-71/73 User’s Guide...
Page 234: Figure 120 Acl Profile Setup
Click ACL Profile Map to open the screen where you can look at which ACL profiles are assigned to which PVCs (see Section 34.4 on page 235). Profile Name Enter a descriptive name for the ACL profile. The name can be 1-31 printable ASCII characters long. Spaces are not allowed. IES-1248-71/73 User’s Guide...
Page 235: Acl Profile Map Screen
Click this to un-select all entries in the table. 34.4 ACL Profile Map Screen Use this screen to look at all the ACL profiles and the PVCs to which each one is assigned. To open this screen, click Advanced Application, ACL, ACL Profile Map. IES-1248-71/73 User’s Guide...
Page 236: Figure 121 Acl Profile Map
This field displays the ADSL port number on which the PVC is configured. VPI/VCI This field displays the Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI). The VPI and VCI identify a channel on this port. IES-1248-71/73 User’s Guide...
Page 237: Downstream Broadcast
Config Save link on the navigation panel to save your changes to the non- volatile memory when you are done configuring. Blocking Table Port Use this drop-down list box to select a port for which you wish to display settings. IES-1248-71/73 User’s Guide...
Page 238 Config Save link on the navigation panel to save your changes to the non- volatile memory when you are done configuring. Select All Click All to mark all of the check boxes. Select None Click None to un-mark all of the check boxes. IES-1248-71/73 User’s Guide...
Page 239: Syslog
1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to begin configuring this screen afresh. IES-1248-71/73 User’s Guide...
Page 240 Chapter 36 Syslog IES-1248-71/73 User’s Guide...
Page 241: Access Control
SNMP is a member of TCP/IP protocol suite. A manager station can manage and monitor the IES-1248 through the network via SNMP version one (SNMPv1) and/or SNMP version 2c. The next figure illustrates an SNMP management operation. SNMP is only available if TCP/IP is configured. IES-1248-71/73 User’s Guide...
Page 242: Figure 125 Snmp Management Model
Get operation, followed by a series of GetNext operations. Allows the manager to set values for object variables within an agent. Trap Used by the agent to inform the manager of some events. IES-1248-71/73 User’s Guide...
Page 243: Supported Mibs
This trap is sent when the voltage of the system is back within the normal range. The variable is the current voltage of the system in volts. extAlarmInputTrigger This trap is sent when there is an external alarm input. extAlarmInputRelease This trap is sent when the external alarm input stops. IES-1248-71/73 User’s Guide...
Page 244 15-minute interval. adslAtucSesLThreshTrap The number of severely errored seconds within 15 minutes for the ATUC has reached the threshold. currValue is the number of severely errored seconds that have occurred within the 15-minute interval. IES-1248-71/73 User’s Guide...
Page 245: Snmp Screen
Enter the trap community, which is the password sent with each trap to the SNMP manager. Trap Destination Enter the IP address of a station to send your SNMP traps to. Port Enter the port number upon which the station listens for SNMP traps. IES-1248-71/73 User’s Guide...
Page 246: Service Access Control Screen
1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to begin configuring this screen afresh. IES-1248-71/73 User’s Guide...
Page 247: Remote Management Screen
1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to begin configuring this screen afresh. IES-1248-71/73 User’s Guide...
Page 248 Chapter 37 Access Control IES-1248-71/73 User’s Guide...
Page 249: Routing Protocol, Alarm And Management
Routing Protocol, Alarm and Management Static Routing (251) Alarm (253) Maintenance (261) Diagnostic (265) MAC Table (271) ARP Table (273)
Page 251: Static Routing
Gateway IP Address Enter the IP address of the gateway. The gateway is an immediate neighbor of your device that will forward the packet to the destination. The gateway must be a router on the same segment as your device. IES-1248-71/73 User’s Guide...
Page 252 This field displays the cost of transmission for routing purposes. Delete Select the rule(s) that you want to remove in the Delete column, and then click the Delete button. Cancel Click Cancel to clear the selected check boxes in the Delete column. IES-1248-71/73 User’s Guide...
Page 253: Alarm
See Section 39.5 on page 258. Alarm Type Select which type of alarms to display by Severity, or select All to look at all the alarms. Refresh Click this button to update this screen. IES-1248-71/73 User’s Guide...
Page 254: Alarm Descriptions
FACILITY SNMP SYSLOG SEVERITY (5000)line_up local1 info (5001)line_down local1 minor (5002)ad_perf_lol_thres local1 minor (5003)ad_perf_lof_thres local1 minor (5004)ad_perf_los_thres local1 minor (5005)ad_perf_lop_thres local1 minor (5006)ad_perf_es_thres local1 minor (5007)ad_perf_ses_thre local1 minor (5008)ad_perf_uas_thre local1 minor (5009)ad_atuc_loftrap local1 minor (5010)ad_atuc_lostrap local1 minor IES-1248-71/73 User’s Guide...
Page 255: Alarm Event Setup Screen
39.4 Alarm Event Setup Screen This screen lists the alarms that the system can generate along with the severity levels of the alarms and where the system is to send them. To open this screen, click Alarm, Alarm Event Setup. IES-1248-71/73 User’s Guide...
Page 256: Figure 131 Alarm Event Setup
This field displays a text description for the condition under which the alarm applies. Facility This field displays the log facility (local1~local7) on the syslog server where the system is to log this alarm. This is for alarms that send alarms to a syslog server. IES-1248-71/73 User’s Guide...
Page 257: Edit Alarm Event Setup Screen
Select this check box to keep an alarm report generated by this alarm event in the system until the conditions that caused the alarm report are no longer present. IES-1248-71/73 User’s Guide...
Page 258: Alarm Port Setup Screen
1248 loses these changes if it is turned off or loses power, so use the Config Save link on the navigation panel to save your changes to the non-volatile memory when you are done configuring. Cancel Click Cancel to start configuring the screen again. IES-1248-71/73 User’s Guide...
Page 259 Chapter 39 Alarm IES-1248-71/73 User’s Guide...
Page 260 Chapter 39 Alarm IES-1248-71/73 User’s Guide...
Page 261: Maintenance
Be sure to upload the correct model firmware as uploading the wrong model firmware may damage your device. To open this screen, click Management, Maintenance, Click here (Firmware Upgrade). IES-1248-71/73 User’s Guide...
Page 262: Restore Configuration Screen
40.4 Backing Up a Configuration File Backing up your device configurations allows you to create various “snap shots” of your device from which you may restore at a later date. IES-1248-71/73 User’s Guide...
Page 263: Load Factory Defaults
This takes up to two minutes. If you want to access the web configurator again, you may need to change the IP address of your computer to be in the same subnet as that of the default device IP address (192.168.1.1). IES-1248-71/73 User’s Guide...
Page 264: Reboot System
This takes up to two minutes. This does not affect the device’s configuration. 40.7 Command Line FTP Chapter 53 on page 357 for how to upload or download files to or from the device using FTP commands. IES-1248-71/73 User’s Guide...
Page 265: Diagnostic
H A P T E R Diagnostic This chapter explains the Diagnostic screens. 41.1 Diagnostic Screen Use this screen to check system logs, ping IP addresses or perform loopback tests. To open this screen, click Management, Diagnostic. Figure 140 Diagnostic IES-1248-71/73 User’s Guide...
Page 266: Table 85 Diagnostic
Get ToneDiag data to display the ADSL port’s tone diagnostics. The tone diagnostic information displays in the format defined in the ITU-T G.992.3 standard. Use the information to analyze problems with the physical ADSL line. Note: ToneDiag is faster than the LDM test but displays less information. IES-1248-71/73 User’s Guide...
Page 267: Log Format
Someone attempted to upload a firmware file with a wrong Received Firmware WARN identity via FTP. Invalid! A file was uploaded to the IES-1248 by FTP. Received File <file>! INFO <file> - received file’s name IES-1248-71/73 User’s Guide...
Page 268: Ldm Test Parameters
The signal-to-noise ratio margin is the maximum that the received noise power could increase with the IES-1248 still being able to meet its transmission targets. This is the upstream and downstream Attainable Net Data Rate (in bit/s). attndr: IES-1248-71/73 User’s Guide...
Page 269: Tonediag Parameters
This is the upstream and downstream Attainable Net Data Rate (in bit/s). attndr: This is the upstream and downstream Far End Actual Aggregate Transmit farEndActatp: Power (in dBm) This is the index number of the DMT sub-carrier. IES-1248-71/73 User’s Guide...
Page 270 SNR is the ratio between the received signal power and the received noise power. The SNR can be used in analyzing time dependent changes in crosstalk levels and line attenuation (such as those caused by temperature variations and moisture). IES-1248-71/73 User’s Guide...
Page 271: Mac Table
2 The device checks to see if the frame's destination MAC address matches a source MAC address already learned in the MAC table. • If the device has already learned the port for this MAC address, then it forwards the frame to that port. IES-1248-71/73 User’s Guide...
Page 272: Mac Table Screen
This is the MAC address of the device from which this incoming frame came. Refresh Click Refresh to update the list of dynamically learned MAC addresses. Flush Click Flush to remove all of the dynamically learned MAC address entries from the MAC table. IES-1248-71/73 User’s Guide...
Page 273: Arp Table
ARP Table for future reference and then sends the packet to the MAC address that replied. 43.2 ARP Table Screen The ARP table can hold up to 500 entries. To open this screen, click Management, ARP Table. IES-1248-71/73 User’s Guide...
Page 274: Figure 143 Arp Table
This is the MAC address of the device with the listed IP address. Previous Page Click one of these buttons to show the preceding or following screen if the information cannot be displayed in one screen. Next Page IES-1248-71/73 User’s Guide...
Page 275: Commands And Troubleshooting
Commands and Troubleshooting Commands (277) Command Examples (297) Alarm Commands (305) DHCP Commands (313) IEEE 802.1Q Tagged VLAN Commands (321) MAC Commands (329) IGMP Commands (335) Packet Filter Commands (349) IP Commands (353) Firmware and Configuration File Maintenance (357) SNMP (363) ADSL Commands (365) Virtual Channel Management (395) ACL Commands (419)
Page 277: Commands
High privilege commands are only available to administrators with high privilege access. High privilege commands include things like creating administrator accounts, restarting the system and resetting the factory defaults. Administrators with high privilege access can use all commands including the lower privilege commands. IES-1248-71/73 User’s Guide...
Page 278: Saving Your Configuration
Sets the reboot timer or displays reboot [show|sec|cancel] the timer and remaining time for reboot. If a reboot has been scheduled, use this command to prevent a reboot. Displays SNMP settings. snmp show Sets the SNMP GetRequest snmp getcommunity <community> community. IES-1248-71/73 User’s Guide...
Page 279 <yyyy mm dd> Displays the system’s time server. M/L timeserver show Sets the system to not use a time timeserver set <none> server. Sets the time service protocol and timeserver set <daytime> <ip> time server’s IP address. [nosync] IES-1248-71/73 User’s Guide...
Page 280 Turns on the specified user name user enable <name> of multi-login. Turns off the specified user name user disable <name> of multi-login. Creates or edits the password and user set <username> privilege level of the specified <password> user name. <high|middle|low> IES-1248-71/73 User’s Guide...
Page 281 <up up-shift margin> <down down-shift margin> <down up- shift margin>] Removes an ADSL profile. profile delete <profile> IES-1248-71/71A: Assigns a profile map <portlist> specific profile to a port(s) and <profile> sets the port’s ADSL mode. <glite|gdmt|t1413| auto|adsl2|adsl2+> IES-1248-73: Assigns a specific profile map <portlist>...
Page 282 <member vci> Remove Priority PVC. ppvc delete <portlist> <vpi> <vci> Set gateway for RPVC. rpvc gateway set <gateway ip> <vlan id> [<priority>] Delete gateway for RPVC. rpvc gateway <gateway ip> delete Display gateway for RPVC. rpvc gateway show IES-1248-71/73 User’s Guide...
Page 283 Display PPPoAoE PVC counter paepvc counter <portlist> [<vpi> <vci>] Delete a TLS PVC tlspvc delete [<portlist>[<vpi> <vci>]] Create/modify a TLS PVC tlspvc set <portlist> <vpi> <vci> <DS <profile>: vcprofile[,US <vid>: s-tag VLAN id vcprofile]> <pvid> <priority>: priority for s-tag <priority> IES-1248-71/73 User’s Guide...
Page 284 [port number] port mapping. showmap Displays which alarm profile alarmprofile <port number> parameters are mapped to an showport ADSL port. Display or set Maximum nominal usnompsd <portNo> [<max transmit PSD in the US direction. nominal psd>] IES-1248-71/73 User’s Guide...
Page 285 Displays the Power Management pmm show <portlist> feature setting for the specified port(s). Sets the Power Management pmm set <portlist> mode <L0|L2|L3> Displays or sets the Power pmm param <portlist> Management parameter [<l0time> <l2time> <l2atpr> <l2atprt>][<max_l2 rate> <min_l2rate> <l0tol2_rate>] IES-1248-71/73 User’s Guide...
Page 286 Sets the DSL port threshold of port set <all|<portlist>> severity which will issue an alarm. <severity> Displays the system alarm table. tablelist [<alarm>|all] [<severity>|all] [<fac>|all] [<target>[,<target >]] [<condition>|all] switch Displays the IGMP snooping igmpsnoop show setting. IES-1248-71/73 User’s Guide...
Page 287 <vid> <portlist>:<F<T|U> |X > [<portlist>: <F<T|U>|X> ...] [name] Show multicast vlans, igmpsnoop mvlan <vlanlist> show Include group information Turns off a MVLAN entry. igmpsnoop mvlan <vid> disable Turns on a MVLAN entry. igmpsnoop mvlan <vid> enable IES-1248-71/73 User’s Guide...
Page 288 Set system rstp’s forward delay rstp fwdelay <fwdelay sec> time. Display enet port rstp status. rstp port show Set enet port to enable rstp. rstp port enable <portlist> Set enet port to disable rstp. rstp port disable <portlist> IES-1248-71/73 User’s Guide...
Page 289 Turns on option 82 sub-option 2 dhcprelay opt82sub2 enable Turns off option 82 sub-option 2 dhcprelay opt82sub2 disable Adds the specified information for dhcprelay <relay info> sub-option 2 opt82sub2 set delete an acl profile acl profile delete <profile> IES-1248-71/73 User’s Guide...
Page 290 Remove an acl profile from PVC acl delete <portlist> <vpi> <vci> <profile> <profile>: string32 up to 8 profiles if only one PVC has profiles Apply an acl profile to a PVC acl set <portlist> <vpi> <vci> <profile> Max. 8 profiles per port IES-1248-71/73 User’s Guide...
Page 291 Set the port(s) to enable or vlan gvrp <portlist> disable gvrp. <enable|disable> Sets the specified DSL port to vlan frametype <portlist> accept tagged, untagged or <all|tag> Ethernet frames (or both). Note: enet1, enet2 are fixed at ‘all’. IES-1248-71/73 User’s Guide...
Page 292 Display dot1x settings. dot1x show [portlist] Turn on dot1x. dot1x enable Turn off dot1x. dot1x disable Set authentication method to dot1x auth <profile|radius> profile or radius. Turn on dot1x on port. dot1x port enable <portlist> IES-1248-71/73 User’s Guide...
Page 293 Removes a static multicast filter smcast delete <mac> entry by deleting the associated MAC address. Displays the subscriber isolation isolation show feature’s current setting. Turns the subscriber isolation isolation enable feature on. Turns the subscriber isolation isolation disable feature off. IES-1248-71/73 User’s Guide...
Page 294 15-minute periods. Displays line performance adsl 1dayperf <portlist> statistics for the current and previous 24 hours. Display protocol packets counters igmpsnoop info [clear] & number of learned groups Display IGMP learned group igmpsnoop group [<vid> member information [<mcast_ip>]] IES-1248-71/73 User’s Guide...
Page 295 Displays a Management port’s status and performance data. config Displays the device’s show <sys|sw|adsl|ip|st configuration. at|all> [nopause] Saves the current configuration. save Reloads the factory default restore configuration. Ends the console or telnet exit session. IES-1248-71/73 User’s Guide...
Page 296 Chapter 44 Commands IES-1248-71/73 User’s Guide...
Page 297: Command Examples
Table 93 Log Format LABEL DESCRIPTION This is the index number of the log entry. <item no> This is the time and date when the log was created. <time> This is the process that created the log. <process> IES-1248-71/73 User’s Guide...
Page 298: Log Messages
<port> - 1 is ENET1, 2 is ENET2 SN - an internal sequencer number <speed> - Ethernet connection speed, for example 1000M or 100M An external alarm is over and the input has returned to a normal state. External alarm is INFO released. IES-1248-71/73 User’s Guide...
Page 299 THERMO LOW WARN TEMPERATURE: dev:<id> <id> - threshold:<threshold> 0: sensor near the ADSL chipset (degree C) 1: sensor near the CPU value:<temp>(degree 2: thermal sensor chip <threshold> - temperature limit <temp> - temperature when the entry was logged IES-1248-71/73 User’s Guide...
Page 300: Log Clear Command
If you clear a log (using the log clear command), you cannot view it again. 45.3.3 Info Show Command Syntax: ras> sys info show This command shows general system settings, the BIN (firmware) version, system uptime and bootbase version. IES-1248-71/73 User’s Guide...
Page 301: Isolation Commands
45.4.2 Isolation Enable Command Syntax: ras> switch isolation enable This command turns on the subscriber isolation feature. 45.4.3 Isolation Disable Command Syntax: ras> switch isolation disable This command turns off the subscriber isolation feature. IES-1248-71/73 User’s Guide...
Page 302: Statistics Monitor Command
You can specify a single port <1>, all ports <*> or a list of ports <portlist> <1,3,enet1>. You can also include a range of ports <1,5,6~10,enet1,enet2>. The VPI and VCI of an individual PVC. <vpi> <vci> IES-1248-71/73 User’s Guide...
Page 303: Figure 148 Statistics Port Command Example
This field shows the number of non-unicast (broadcast and rx nonuni- packets multicast) packets received on this port. Chapter 9 on page 89 for details on the other port statistics fields. IES-1248-71/73 User’s Guide...
Page 304 Chapter 45 Command Examples IES-1248-71/73 User’s Guide...
Page 305: Alarm Commands
[<severity>|all] [<alarm>|all] [<condition>|all] [detail] where Display in-depth alarm information. [detail] This command displays the current alarms by severity, alarm category or alarm condition. The following example displays the current critical level alarms for all alarm categories and conditions. IES-1248-71/73 User’s Guide...
Page 306: Alarm Port Show Command
46.4 Alarm Port Show Command Syntax: ras> alarm port show [<severity>|all] This command displays port alarm severity level thresholds. The system reports an alarm on a port if the alarm has a severity equal to or higher than the port’s threshold. IES-1248-71/73 User’s Guide...
Page 307: Alarm Port Set Command
The system reports an alarm on a port if the alarm has a severity equal to or higher than the port’s threshold. The following example has the IES-1248 only record critical alarms on DSL port 7. Figure 151 Alarm Port Set Command Example ras> alarm port set 7 critical IES-1248-71/73 User’s Guide...
Page 308: Alarm Tablelist Command
See your syslog program’s documentation for details. snmp|syslog|all The type of alarm messages that the <target> device is to send (SNMP, syslog or all). This command lists alarm settings. IES-1248-71/73 User’s Guide...
Page 309: Log Format
Digital Subscriber Line (DSL) alarms. enet represents Ethernet alarms. sys represents system alarms. There is a condition code number for the specific alarm message and a text condition description for the condition under which the alarm applies. IES-1248-71/73 User’s Guide...
Page 310: Alarm History Show Command
* IES-1248:Fan 2 speed 0, low 2000, high 8000 2 eqpt +fan_err critical 07/28 15:23:35 eqpt * IES-1248:Fan 3 speed 0, low 2000, high 8000 3 eqpt +fan_err critical 07/28 15:23:33 eqpt * IES-1248:Fan 1 speed 0, low 2000, high 8000 IES-1248-71/73 User’s Guide...
Page 311: Alarm History Clear Command
This command sets the severity level of an alarm(s) and where the system is to send the alarm(s). Use the command to display alarm setting details. alarm tablelist IES-1248-71/73 User’s Guide...
Page 312: Alarm Cutoff Command
The alarm entry remains in the system. 46.12 Alarm Clear Command Syntax: ras> alarm clear This command erases the clearable alarm entries. IES-1248-71/73 User’s Guide...
Page 313: Dhcp Commands
----- ----- ------------------ ------------------ 1 (*)212.212.212.212 213.213.213.213 2 (*)214.214.214.214 215.215.215.251 option82 sub-opt1 info (Circuit ID) ----------------- ------------------------------ option82 sub-opt2 info (Remote ID) ----------------- ------------------------------ 47.1.2 Enable Command Syntax: ras> switch dhcprelay enable This command turns on the DHCP relay feature. IES-1248-71/73 User’s Guide...
Page 314: Disable Command
Syntax: ras> switch dhcprelay server active <vid> <active-server> where The ID of the VLAN served by the specified DHCP server(s). <vid> 1: The primary DHCP server is active. <active-server> = 2: The secondary DHCP server is active. IES-1248-71/73 User’s Guide...
Page 315: Relaymode Command
47.2.2 Option 82 Sub-option 1 Disable Command Syntax: ras> switch dhcprelay option82 disable This command turns off the DHCP relay agent information (Option 82, Sub-option 1) feature. 47.2.3 Option 82 Sub-option 1 Set Command Syntax: ras> switch dhcprelay option82 set [<relay info>] IES-1248-71/73 User’s Guide...
Page 316: Dhcp Relay Option 82 (Agent Information) Sub-Option 2 (Remote Id)
IES-1248 to add to the DHCP requests that it relays to a DHCP server. Examples of information you could add would be the name of the IES-1248 or the ISP. This command adds the specified information for the relay agent. IES-1248-71/73 User’s Guide...
Page 317: Dhcp Snoop Commands
47.4.3 DHCP Snoop Flush Command Syntax: ras> switch dhcpsnoop flush <portlist> where You can specify a single port <1>, all ports <*> or a list of ports <portlist> <1,3,enet1>. You can also include a range of ports <1,5,6~10,enet1,enet2>. IES-1248-71/73 User’s Guide...
Page 318: Dhcp Snoop Show Command
Use this command to display a summary of DHCP packets on the specified port(s). The following example displays the settings of port 1. Figure 159 DHCP Counter Statistics Command Example ras> statistics dhcp counter 1 port discover offer request overflow ----- -------- -------- -------- -------- -------- IES-1248-71/73 User’s Guide...
Page 319: Dhcp Snoop Statistics Command
Overflow requests are dropped by the IES-1248. The MAC address of a client on this port to which the DHCP server assigned an IP address. The IP address assigned to a client on this port. IES-1248-71/73 User’s Guide...
Page 320 Chapter 47 DHCP Commands IES-1248-71/73 User’s Guide...
Page 321: Ieee 802.1Q Tagged Vlan Commands
A filtering database stores and organizes VLAN registration information useful for switching frames to and from the IES-1248. A filtering database consists of static entries (Static VLAN or SVLAN table). 48.3.1 Static Entries (SVLAN Table) Static entry registration information is added, modified and removed by administrators only. IES-1248-71/73 User’s Guide...
Page 322: Ieee Vlan1Q Tagged Vlan Configuration Commands
The following example sets the default VID of port 1 to 200. Figure 162 VLAN PVID Command Example ras> switch vlan pvid 1 200 48.4.3 VLAN Priority Command Syntax: ras> switch vlan priority <portlist> <priority> IES-1248-71/73 User’s Guide...
Page 323: Vlan Set Command
A name to identify the SVLAN entry. [name] This command adds or modifies an entry in the static VLAN table. Use the switch vlan show command to display your configuration. An example of a configuration is shown next. IES-1248-71/73 User’s Guide...
Page 324: Vlan Frame Type Command
Ethernet frames that have a VLAN tag. Use all to have the specified port(s) accept both tagged and untagged incoming Ethernet frames. This command sets the specified DSL ports to accept VLAN tagged Ethernet frames, or both tagged and untagged Ethernet frames. IES-1248-71/73 User’s Guide...
Page 325: Vlan Cpu Show Command
2 48.4.8 Configuring Management VLAN Example After the following example configuration, you must connect to the first Ethernet port through a VLAN aware device that is using the proper VLAN ID in order to perform management. IES-1248-71/73 User’s Guide...
Page 326: Vlan Delete Command
2 in the static VLAN table. Figure 170 VLAN Delete Command Example ras> switch vlan delete 2 48.5 VLAN Enable Syntax: ras> switch vlan enable <vid> This command enables the specified VLAN ID in the SVLAN (Static VLAN) table. IES-1248-71/73 User’s Guide...
Page 327: Vlan Disable
* vid name F:fixed X:forbidden N:normal U:untag T:tag ---- ---------------- --------------------------------------------------- enabled 123456789012345678901234567890123456789012345678 12 FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF FF UUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUU UU disabled 123456789012345678901234567890123456789012345678 12 FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF FF UUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUU UU 2000 - enabled 123456789012345678901234567890123456789012345678 12 FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF FF UUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUU UU IES-1248-71/73 User’s Guide...
Page 328 Chapter 48 IEEE 802.1Q Tagged VLAN Commands IES-1248-71/73 User’s Guide...
Page 329: Mac Commands
ADSL port 5. Figure 172 MAC Filter Show Command Example ras> sw mac filter show 5 status:V, enable mac filter function. status:-, disable mac filter function. port mode status mac ---- ------ ------ ----------------- 5 accept 00:a0:c5:12:34:56 IES-1248-71/73 User’s Guide...
Page 330: Mac Filter Enable Command
MAC addresses. deny = Block frames from MAC addresses that you specify and allow frames from other MAC addresses. This command sets whether the IES-1248 allows or blocks access for the MAC addresses you specify. IES-1248-71/73 User’s Guide...
Page 331: Mac Filter Set Command
MAC count commands are listed next. When the MAC filter accept mode is enabled (see Section 49.2 on page 329), the IES-1248 ignores the MAC count setting and accepts all of the MAC addresses listed for the port in the MAC filter settings. IES-1248-71/73 User’s Guide...
Page 332: Mac Count Show Command
Syntax: ras> switch mac count disable <portlist> where You can specify a single ADSL port <1>, all ADSL ports <*> or <portlist> a list of ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. IES-1248-71/73 User’s Guide...
Page 333: Mac Count Set Command
The following example sets the MAC count filter to allow up to 50 MAC addresses to be dynamically learned on ADSL port 7. Figure 181 MAC Count Set Command Example ras> switch mac count set 7 50 IES-1248-71/73 User’s Guide...
Page 334 Chapter 49 MAC Commands IES-1248-71/73 User’s Guide...
Page 335: Igmp Commands
This command turns on IGMP proxy or snooping. Use proxy to have the device use IGMP proxy. Use IGMP snooping to have the device passively learn multicast groups. The following example sets the device to use IGMP proxy. Figure 183 IGMP Snoop Enable Command Example ras> switch igmpsnoop enable proxy IES-1248-71/73 User’s Guide...
Page 336: Igmp Snoop Disable Command
-------------------------------------- DEFVAL 50.3.2 IGMP Filter Set Command Syntax: ras> switch igmpfilter set [<port>|*] <name> where You can specify a single ADSL port <1> or all ADSL ports <*>. [<port>|*] The name of an IGMP filter profile. <name> IES-1248-71/73 User’s Guide...
Page 337: Igmp Filter Profile Set Command
The name of an IGMP filter profile. <name> This command removes an IGMP filter profile. The following example removes the voice IGMP filter profile. Figure 188 IGMP Filter Profile Delete Command Example ras> switch igmpfilter profile delete voice IES-1248-71/73 User’s Guide...
Page 338: Igmp Filter Profile Show Command
Use the IGMP bandwidth commands to set up bandwidth budgets for specific multicast channels. 50.4.1 IGMP Bandwidth Default Command Syntax: ras> switch igmpsnoop bandwidth default <bandwidth> where Allowed bandwidth between 1 and 1000 000 kbps (kilo bits per <bandwidth> second). IES-1248-71/73 User’s Guide...
Page 339: Igmp Bandwidth Set Command
This command removes the specified multicast bandwidth configuration profile. 50.5 IGMP Bandwidth Port Commands Use the IGMP bandwidth port commands to set up bandwidth budgets for multicast traffic on specific ports. 50.5.1 IGMP Bandwidth Port Disable Command Syntax: ras> switch igmpsnoop bandwidth port disable <portlist> IES-1248-71/73 User’s Guide...
Page 340: Igmp Bandwidth Port Enable Command
<portlist> where You can specify a single ADSL port <1>, all ADSL ports <*> or <portlist> a list of ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. IES-1248-71/73 User’s Guide...
Page 341: Igmp Count Limit Commands
The following command turns off the IGMP count limit for port 4. Figure 191 IGMP Count Disable Command Example ras> switch igmpsnoop igmpcount disable 4 50.6.2 IGMP Count Enable Command Syntax: ras> switch igmpsnoop igmpcount enable <portlist> IES-1248-71/73 User’s Guide...
Page 342: Igmp Count Set Command
ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. This command displays the IGMP count limit setting status for the specified ADSL port(s). The following example displays the IGMP count limit settings for ports 1-5. IES-1248-71/73 User’s Guide...
Page 343: Igmp Snoop Statistics Commands
[<vid> [<mcast_ip>]] where The VLAN ID [1 – 4094]. <vid> The multicast IP address. <mcast_ip> This command displays the information about IGMP groups learned on the system, specified VLAN, or specified multicast address on the specified VLAN(s). IES-1248-71/73 User’s Guide...
Page 344: Igmp Port Info Statistics Command
This command displays the IGMP groups a port joins. The following figure shows an example for port 1. Figure 198 IGMP Port Group Statistics Command Example ras> statistics igmpsnoop port group 1 port vid mcast_ip source ip ----- ---- --------------- --------------- IES-1248-71/73 User’s Guide...
Page 345: Multicast Vlan Commands
<vlanlist> where You can specify a single VLAN: <1>, all VLAN: <*>, a list of <vlanlist> VLAN: <1,3>, you can also include a range of VLAN: <1,5,6~10>. This command removes the specified multicast VLAN configuration(s). IES-1248-71/73 User’s Guide...
Page 346: Multicast Vlan Disable Command
This command displays the current multicast VLAN settings. In the state column, “-” indicates the multicast VLAN is not active while “V” indicates the multicast VLAN is active. Figure 200 Multicast VLAN Show Command Example ras> switch igmpsnoop mvlan show 1 vid name F:fixed X:forbidden U:untag T:tag ---- ---------------- ---------------------------------------- IES-1248-71/73 User’s Guide...
Page 347: Multicast Vlan Group Set Command
This command removes the specified multicast VLAN group setting. 50.8.8 Multicast VLAN Group Show Command Syntax: ras> switch igmpsnoop mvlan group show [<vid>] where The multicast VLAN ID [1 – 4094]. <vid> This command displays a multicast to VLAN translation entry. IES-1248-71/73 User’s Guide...
Page 348 Chapter 50 IGMP Commands IES-1248-71/73 User’s Guide...
Page 349: Packet Filter Commands
9 V: pass through, -: filter out, #:Don't care E: Enable, D: Disable port pppoe ip arp netbios dhcp eapol igmp | PPPoE-Only 51.1.2 Packet Filter Set Command Syntax: ras> switch pktfilter set <portlist> [filter] IES-1248-71/73 User’s Guide...
Page 350: Packet Filter Pppoe Only Command
The following example sets ADSL port 9 to reject ARP, PPPoE and IGMP packets. Figure 203 Packet Filter Set Command Example ras> switch pktfilter set 9 arp pppoe igmp 51.1.3 Packet Filter PPPoE Only Command Syntax: ras> switch pktfilter pppoeonly <portlist> IES-1248-71/73 User’s Guide...
Page 351: Figure 204 Packet Filter Pppoe Only Command Example
This command sets the IES-1248 to allow only PPPoE traffic on the specified ADSL port(s). The system will drop any non-PPPoE packets. The following example sets ADSL port 1 to accept only PPPoE packets. Figure 204 Packet Filter PPPoE Only Command Example ras> switch pktfilter pppoeonly 1 IES-1248-71/73 User’s Guide...
Page 352 Chapter 51 Packet Filter Commands IES-1248-71/73 User’s Guide...
Page 353: Ip Commands
The default gateway IP address you want to configure for the <ip> IES-1248. The first command changes the IP settings for the IES-1248’s uplink, downlink and IES-1248 DSL ports. If you don’t enter the subnet mask, the system automatically computes the subnet mask. IES-1248-71/73 User’s Guide...
Page 354: General Ip Commands
52.3.3 Route Set Command Syntax: ras> ip route set <dst ip>[/netmask] <gateway ip> [metric] <name> ras> ip route set default <gateway ip> <metric> where The destination IP address of packets that this static route is to <dst ip> route. IES-1248-71/73 User’s Guide...
Page 355: Route Delete Command
192.168.1.254 52.3.6 ARP Show Command Syntax: ras> ip arp show This command displays the IES-1248’s IP Address Resolution Protocol table. This is the list of IP addresses and matching MAC addresses that the IES-1248 has resolved. IES-1248-71/73 User’s Guide...
Page 356: Arp Flush Command
: 172.23.14.253 netmask: 0.0.0.0 broadcast: 172.23.255.255 mtu: 1500 in octet 10728504 in unicast : in multicast 232488 in discard : in error in unknown proto: out octet 41361 out unicast: out multicast out discard: out error IES-1248-71/73 User’s Guide...
Page 357: Firmware And Configuration File Maintenance
The OS (Operating System) firmware (sometimes referred to as the “ras” file) has a “bin” filename extension. With many FTP and clients, the filenames are similar to those shown next. Figure 210 FTP Put Configuration File Example ftp> put firmware.bin ras IES-1248-71/73 User’s Guide...
Page 358: Editable Configuration File
Do not upload any invalid files to the IES-1248’s configuration file, as it may permanently damage your IES-1248. 53.3.1 Editable Configuration File Backup Configure your system, and then use FTP to backup the plain-text configuration file onto your computer. Do the following to backup the configuration file: IES-1248-71/73 User’s Guide...
Page 359: Edit Configuration File
Ensure that any changes you make to the commands in the configuration file correspond to the commands documented in this User’s Guide. The wrong configuration file or an incorrectly configured configuration file can render the device inoperable. IES-1248-71/73 User’s Guide...
Page 360: Editable Configuration File Upload
Figure 217 Example: Use an FTP Client to Connect to the IES-1248 C:\> ftp <IES-1248 IP address> Type your user name and press [ENTER]. User (172.23.15.86:(none)): admin Enter the management password (1234 by default). Figure 218 Example: Enter the Management Password Password: 1234 230 Logged in IES-1248-71/73 User’s Guide...
Page 361: Firmware File Upgrade
IES-1248 is named firmware.bin. The internal firmware file on the IES- 1248 is named ras. Figure 223 Example: Transfer the Firmware File ftp> put firmware.bin ras Quit FTP. Figure 224 Example: Close FTP Client ftp> quit Wait for the update to finish. The IES-1248 restarts automatically. IES-1248-71/73 User’s Guide...
Page 362 Chapter 53 Firmware and Configuration File Maintenance IES-1248-71/73 User’s Guide...
Page 363: Snmp
The password for the incoming Set- requests from the <community> management station. Enter this command with the community to set the password. 54.1.3 Trusted Host Set Command Syntax: ras> sys snmp trusthost <ip> where The IP address of a trusted host. <ip> IES-1248-71/73 User’s Guide...
Page 364: Trap Community Command
1248 sends SNMP traps. If you leave the trap destination set to 0.0.0.0 (default), the IES-1248 will not send any SNMP traps. 54.1.6 Show SNMP Settings Command Syntax: ras> sys snmp show This command displays the current SNMP get community, set community, trap community, trusted hosts and trap destination settings. IES-1248-71/73 User’s Guide...
Page 365: Adsl Commands
55.1.2 ADSL Enable Command Syntax: ras> adsl enable <portlist> where You can specify a single ADSL port <1>, all ADSL ports <*> or <portlist> a list of ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. IES-1248-71/73 User’s Guide...
Page 366: Adsl Disable Command
DEFVAL 01. DEFVAL latency mode: interleave up stream down stream --------- ----------- max rate (kbps): 2048 min rate (kbps): latency delay (ms): max margin (db): min margin (db): target margin (db): up shift margin(db): down shift margin(db): IES-1248-71/73 User’s Guide...
Page 367: Adsl Profile Set Command
The upstream up shift noise margin (0~31 in dB). <up up shift margin> The downstream down shift noise margin (0~31 in dB). <down down shift margin> The downstream up shift noise margin (0~31 in dB). <down up shift margin>] IES-1248-71/73 User’s Guide...
Page 368: Adsl Profile Delete Command
256 0 6 0 6 After you create an ADSL profile, you can assign it to any of the ADSL ports on any of the ADSL IES-1248 in the IES-1248. 55.1.6 ADSL Profile Delete Command Syntax: ras> adsl profile delete <profile> IES-1248-71/73 User’s Guide...
Page 369: Adsl Profile Map Command
ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. The profile that will define the settings of this port. <profile> The ADSL operational mode. The IES-1248-71/71A and the <glite|gdmt|ets i|t1413|auto|ad IES-1248-73 have different choices.
Page 370: Adsl Name Command
This command records the telephone number of an ADSL subscriber telephone number. The following example records the telephone number 12345678 for ADSL port 5. Figure 232 ADSL Tel Command Example ras> adsl tel 5 12345678 55.1.10 ADSL Loopback Command Syntax: ras> adsl loopback <portlist> < f5> <vpi> <vci> IES-1248-71/73 User’s Guide...
Page 371: Adsl Upstream Psd Command
The following example sets the upstream maximum nominal transmit PSD for port 7 to 10 dBm/Hz. Figure 234 ADSL Upstream PSD Command Example ras> adsl usnompsd 7 100 55.1.12 ADSL Downstream PSD Command Syntax: ras> adsl dsnompsd <portNo> [<max nominal psd>] IES-1248-71/73 User’s Guide...
Page 372: Adsl Upstream Carrier Command
(0-23 and 25-31). The following example disables upstream carrier tones 0~15 for ADSL port 5. Figure 236 ADSL Upstream Carrier Command Example ras> adsl uscarrier 5 ffff0000 IES-1248-71/73 User’s Guide...
Page 373: Adsl Downstream Carrier0 Command
The following example disables downstream carrier tone 71 for ADSL port 5. Figure 238 ADSL Downstream Carrier0 Command Example 1 ras> adsl dscarrier0 5 0 01000000 0 0 0 0 0 IES-1248-71/73 User’s Guide...
Page 374: Adsl Downstream Carrier1 Command
The following example disables downstream carrier tone 307 for ADSL2+ port 5. Figure 241 ADSL Downstream Carrier1 Command Example 1 ras> adsl dscarrier1 5 0 00001000 0 0 0 0 0 0 IES-1248-71/73 User’s Guide...
Page 375: Pmm Parameters Command
Set the maximum Aggregate Transmit Power Reduction Total <l2atprt> (ATPRT) in decibels (dB) that is permitted in the L2 power mode. This is the total transmit power decrease that is allowed to occur in the L2 power mode. The range is 1~40(dB). IES-1248-71/73 User’s Guide...
Page 376: Impulse Noise Protection Command
Sets the minimum upstream (us) impulse noise protection setting. Use <usINP> 0~3 to define a number of DMT symbols. 0 = 0 DMT symbols, 1 = 0.5 DMT symbols, 2 = 1 DMT symbols, 3 = 2 DMT symbols. IES-1248-71/73 User’s Guide...
Page 377: Annex L Enable Command
Figure 245 Impulse Noise Protection Command Example ras> adsl inp 5 2 1 55.1.18 Annex L Enable Command This command is available for the IES-1248-71. Syntax: ras> adsl annexl enable <portlist> This command turns on the Annex L reach extended feature on the specified ADSL2 port(s).
Page 378: Statistics Adsl Commands
(from the subscriber’s DSL modem or router to the IES-1248). “downstream carrier load” displays the number of bits received per DMT tone for the downstream channel (from the IES-1248 to the subscriber’s DSL modem or router). IES-1248-71/73 User’s Guide...
Page 379: Lineinfo Command
You can specify a single ADSL port <1>, all ADSL ports <*> or <portlist> a list of ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. This command shows the line operating values of an ADSL port. IES-1248-71/73 User’s Guide...
Page 380: Figure 250 Lineinfo Command Example
- serial number : 0000000000000000000000000000000000000000000000000000000000000000 The service type in operation is the ADSL standard that the port is using. The IES-1248-71/ 71A uses G.lite, G.dmt, ANSI T1.413 issue 2, ADSL2, or ADSL2+. The IES-1248-73 uses G.dmt Annex B, ETSI, ADSL2, or ADSL2+.
Page 381: Lineperf Command
The Number of Severely Errored Seconds. This is how many seconds contained 30% or more errored blocks. This is a subset of n-es. The Number of Unavailable Seconds. The Number of times a Loss of Power (on the ATUR) has occurred. IES-1248-71/73 User’s Guide...
Page 382: Minute Performance Command
ATUR lofs: loss: lols: lprs: eSs: inits: sesl: uasl: History 15 Min PM-1: ATUC ATUR lofs: loss: lols: lprs: eSs: inits: sesl: uasl: History 15 Min PM-2: ATUC ATUR lofs: loss: lols: lprs: eSs: inits: sesl: uasl: IES-1248-71/73 User’s Guide...
Page 383: Day Performance Command
You can specify a single ADSL port <1>, all ADSL ports <*> or <portlist> a list of ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. This command displays line performance statistics for the current and previous 24 hours. IES-1248-71/73 User’s Guide...
Page 384: Line Diagnostics Set Command
<port number> Use this command to display the line diagnostics results after using the line diagnostics set command on an ADSL port. Use the line diagnostics results to analyze problems with the physical ADSL line. IES-1248-71/73 User’s Guide...
Page 385: Figure 255 Line Diagnostics Get Command Example
ADSL connection is using. The channel characteristics function is represented in linear format by a scale hlinScale: factor and a complex number. These are the maximum upstream and downstream scale factors used in producing the channel characteristics function. IES-1248-71/73 User’s Guide...
Page 386: Line Diagnostics Get 992.3 Command
G.992.3 standard after using the line diagnostics set command on an ADSL port. Use the line diagnostics results to analyze problems with the physical ADSL line. Wait at least one minute after using the line diagnostic set command before using this command. IES-1248-71/73 User’s Guide...
Page 387: Figure 256 Line Diagnostics Get 992.3 Command Example
These are the maximum upstream and downstream scale factors used in producing the channel characteristics function. This is the upstream and downstream Line Attenuation (in dB). latn: This is the upstream and downstream Signal Attenuation (in dB). satn: IES-1248-71/73 User’s Guide...
Page 388: Tone Diagnostics 992.3 Command
Use this command to display the tone diagnostics for a port in the format defined in the ITU-T G.992.3 standard. You do not need to use the line diagnostics set command first. Use the tone diagnostics to analyze problems with the physical ADSL line. IES-1248-71/73 User’s Guide...
Page 389: Figure 257 Tone Diagnostics Command Example
This is the upstream and downstream Attainable Net Data Rate (in bit/s). attndr: This is the upstream and downstream Far End Actual Aggregate Transmit farEndActatp: Power (in dBm) This is the index number of the DMT sub-carrier. IES-1248-71/73 User’s Guide...
Page 390: Alarm Profile Commands
Figure 258 Alarm Profile Show Command Example ras> adsl alarmprofile show DEFVAL 01. DEFVAL ATU-C ATU-R ---------- ---------- Thresh15MinLofs (sec): Thresh15MinLoss (sec): Thresh15MinLols (sec): Thresh15MinLprs Thresh15MinESs (sec): ThreshFastRateUp (bps): ThreshInterleaveRateUp (bps): ThreshFastRateDown (bps): ThreshInterleaveRateDown (bps): InitFailureTrap(1-enable, 2-disable): Thresh15MinFailedFast Thresh15MinSes (sec): Thresh15MinUas (sec): IES-1248-71/73 User’s Guide...
Page 391: Alarm Profile Set Command
“1” sets the profile to trigger an alarm for an initialization <init fail enable> failures trap. “2” sets the profile to not trigger an alarm for an initialization failures trap. The number of failed fast retrains that are permitted to occur <atuc fail fast> within 15 minutes. IES-1248-71/73 User’s Guide...
Page 392: Alarm Profile Delete Command
You can specify a single ADSL port <1>, all ADSL ports <*> or a list of <portlist> ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. The name of an alarm profile. <profile> Sets the IES-1248 to use an (already-configured) alarm profile with the specified ADSL ports. IES-1248-71/73 User’s Guide...
Page 393: Alarm Profile Showmap Command
The following example displays which alarm profile the IES-1248 is set to use for ADSL port Figure 262 Alarm Profile Showmap Command Example ras> adsl alarmprofile showmap 5 ADSL alarm profile mapping: Port 5: Alarm Profile = DEFVAL IES-1248-71/73 User’s Guide...
Page 394 Chapter 55 ADSL Commands IES-1248-71/73 User’s Guide...
Page 395: Virtual Channel Management
The name of the virtual channel profile (up to 31 ASCII <vcprofile> characters). You cannot change the DEFVAL or DEFVAL_VC profiles. The type of encapsulation (vc or llc). <vc|llc> The ubr (unspecified bit rate) or cbr (constant bit rate) or ATM <ubr|cbr> traffic class. IES-1248-71/73 User’s Guide...
Page 396: Delete Virtual Channel Profile Command
(CDVT) is set to 100 cells. Figure 265 Set Virtual Channel Profile Command Example 3 ras> adsl vcprofile set gold llc cbr 50000 100 56.2.3 Delete Virtual Channel Profile Command Syntax: ras> adsl vcprofile delete <vcprofile> IES-1248-71/73 User’s Guide...
Page 397: Pvc Channels
You can specify a single ADSL port <1>, all ADSL ports <*> or <portlist> a list of ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. The VPI setting can be 0 to 255. <vpi> IES-1248-71/73 User’s Guide...
Page 398: Pvc Delete Command
You can specify a single ADSL port <1>, all ADSL ports <*> or <portlist> a list of ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. The VPI and VCI of an individual PVC. [<vpi> <vci>] This command deletes the specified PVC channel. IES-1248-71/73 User’s Guide...
Page 399: Priority-Based Pvcs
Figure 268 PPVC Set Command Example ras> adsl ppvc set 5 8 35 llc 25 3 56.4.2 PPVC Member Set Command Syntax: ras> adsl ppvc member set <portlist> <vpi> <vci> <member vpi> <member vci> <DS vcprofile[,US vcprofile]> <level> IES-1248-71/73 User’s Guide...
Page 400: Ppvc Member Delete Command
Figure 269 PPVC Member Set Command Example ras> adsl ppvc member set 5 8 35 8 36 DEFVAL,DEFVAL 2 56.5 PPVC Member Delete Command Syntax: ras> adsl ppvc member delete <portlist> <vpi> <vci> <member vpi> <member vci> IES-1248-71/73 User’s Guide...
Page 401: Ppvc Member Show Command
The following example displays the PVCs that are members of a PPVC for port 5. Figure 271 PPVC Member Show Command Example ras> adsl ppvc member show 5 port vpi vci mvpi mvci level DS/US vcprofile ---- --- ----- ---- ----- ------ -------------------- 2 DEFVAL/DEFVAL IES-1248-71/73 User’s Guide...
Page 402: Ppvc Show Command
This command removes a PPVC. Removing a PPVC also deletes all of the member PVCs. The following example removes a PPVC with VPI 8 and VCI 35 for port 5. Figure 273 PPVC Delete Command Example ras> adsl ppvc delete 5 8 35 IES-1248-71/73 User’s Guide...
Page 403: 2684 Routed Mode Commands
CPE device. The CPE device’s LAN IP address is 10.10.10.10 and the LAN computer’s IP address is 10.10.10.1. This includes the CPE device’s LAN IP addresses and the IP addresses of the LAN computers. IES-1248-71/73 User’s Guide...
Page 404: Figure 274 2684 Routed Mode Example
Use the following command sequence to configure the IES-1248 for this example set up. Figure 275 2684 Routed Mode Commands Example ras> adsl rpvc gateway set 192.168.10.102 1 ras> adsl rpvc set 1 8 35 DEFVAL 192.168.10.200/32 192.168.10.102 ras> adsl rpvc route set 1 8 35 10.10.10.1/24 IES-1248-71/73 User’s Guide...
Page 405: Rpvc Gateway Set Command
PVC. Enter the IP address in dotted decimal notation. This command removes a gateway IP address that the device was set to use for 2684 routed mode traffic. IES-1248-71/73 User’s Guide...
Page 406: Rpvc Set Command
PVC. Enter the IP address in dotted decimal notation. This command adds a PVC to handle 2684 routed mode traffic. You must use the command to configure the gateway’s rpvc gateway set settings before you use the command. rpvc set IES-1248-71/73 User’s Guide...
Page 407: Rpvc Show Command
ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. The VPI of the RPVC. <vpi> The VCI of the RPVC. <vci> This command removes a PVC for 2684 routed mode traffic. IES-1248-71/73 User’s Guide...
Page 408: Rpvc Route Set Command
This includes the CPE device’s LAN IP addresses and the IP addresses of the LAN computers. Figure 282 RPVC Route Set Command Example ras> adsl rpvc route set 1 8 35 10.10.10.1/24 56.7.9 RPVC Route Show Command Syntax: ras> adsl rpvc route show <portlist> IES-1248-71/73 User’s Guide...
Page 409: Rpvc Route Delete Command
The CPE device’s LAN IP address is 10.10.10.10 and uses a subnet mask of 255.255.255.0. This includes the CPE device’s LAN IP addresses and the IP addresses of the LAN computers. Figure 284 RPVC Route Delete Command Example ras> adsl rpvc route delete 1 8 35 10.10.10.1/24 IES-1248-71/73 User’s Guide...
Page 410: Rpvc Arp Agingtime Set Command
This command displays how long the device stores the IP addresses of 2684 routed mode gateways in the Address Resolution Protocol table. The following is an example. Figure 287 RPVC ARP Agingtime Show Command Example ras> adsl rpvc arp show gateway ip --------------- ---- ----------------- 192.168.10.102 1 00:0d:9d:d9:43:3b IES-1248-71/73 User’s Guide...
Page 411: Rpvc Arp Flush Command
ADSL port <1>, all ADSL ports <*> or a list of ADSL ports <1,3,5>. You can also include a range of ports <1,5,6~10>. The VPI of the PAE PVC. <vpi> The VCI of the PAE PVC. <vci> This command removes a PAE PVC. IES-1248-71/73 User’s Guide...
Page 412: Pae Pvc Set Command
1, and the IEEE 802.1p priority is 0. This configuration is for the video service on the vom access concentrator. The switch waits 10 seconds before terminating the PPPoE session. Figure 289 PAE PVC Set Command Example ras> adsl paepvc set 1 1 33 DEFVAL 1 0 acname vom srvcname video hellotime 10 IES-1248-71/73 User’s Guide...
Page 413: Pae Pvc Show Command
The VPI of the PAE PVC. <vpi> The VCI of the PAE PVC. <vci> This command displays the status of PPPoA-to-PPPoE PVC sessions on the specified port(s) or PVCs. The following example displays the settings for port 1. IES-1248-71/73 User’s Guide...
Page 414: Pae Pvc Counter Command
Each value is described below. The values in these columns are for packets transmitted (tx) or tx/rx received (rx) by the IES-1248. IES-1248-71/73 User’s Guide...
Page 415: Transparent Lan Service (Tls)
Before the IES-1248 sends the frames from the customers, the VLAN ID is added to the frames. When packets intended for specific customers are received on the IES-1248, the outer VLAN tag is removed before the traffic is sent. Section 33.1.1 on page 227 for an example. IES-1248-71/73 User’s Guide...
Page 416: Tls Pvc Delete Command
PVC. This command sets the second VLAN tag to add to the packets from the PVC. The following example adds VLAN tag 100 to traffic using the DEFVAL ATM profile on PVC (1/33) on port 2. IES-1248-71/73 User’s Guide...
Page 417: Tls Pvc Show Command
This command displays the TLS settings for the specified port(s) or PVC(s). The following example shows the TLS settings on port 2. Figure 294 TLS PVC Show Command Example ras> adsl tlspvc show 2 port vpi pvid pri DS/US vcprofile ---- --- ----- ----- --- ---------------------------------- 0 DEFVAL IES-1248-71/73 User’s Guide...
Page 418 Chapter 56 Virtual Channel Management IES-1248-71/73 User’s Guide...
Page 419: Acl Commands
• etype <etype> vlan <vid> • etype <etype> smac <mac> • etype <etype> dmac <mac> • vlan < vid > smac <mac> • vlan < vid > dmac <mac> • smac < mac > dmac <mac> IES-1248-71/73 User’s Guide...
Page 420: Figure 295 Acl Profile Set Command Example
2. This rule limits the rate on the classified traffic to 1000 kbps and changes the priority level to 7. Figure 295 ACL Profile Set Command Example ras> switch acl profile set test vlan 10 priority 2 rate 1000 rpri 7 IES-1248-71/73 User’s Guide...
Page 421: Acl Profile Delete Command
57.1.4 ACL Profile Show Command Syntax: ras> switch acl profile show [<profile>] where The name of the ACL profile. [<profile>] This command lists the names of every ACL profile or displays the detailed settings of the specified ACL profile. IES-1248-71/73 User’s Guide...
Page 422: Acl Assignment Commands
The following example applies the ACL profile “test” to a PVC. Figure 298 ACL Assignment Set Command Example ras> switch acl set 1 0 33 test 57.2.2 ACL Assignment Delete Command Syntax: ras> switch acl delete <portlist> <vpi> <vci> <profile> IES-1248-71/73 User’s Guide...
Page 423: Acl Assignment Show Command
This command displays the current ACL profiles applied to the specified PVC(s). The following figure shows an example. Figure 299 ACL Assignment Show Command Example ras> switch acl show port vpi vci type profile ---- --- ----- ---- -------------------------------- 33 PVC test IES-1248-71/73 User’s Guide...
Page 424 Chapter 57 ACL Commands IES-1248-71/73 User’s Guide...
Page 425: Troubleshooting
Appendix A on page 440). For DC power versions, make sure the power wires are connected properly. (IES-1248-71 AC power version) Make sure the fuse is not burnt-out. Replace the fuse if it is burnt out. See Appendix B on page 447 for instructions.
Page 426: Sfp Lnk Leds Do Not Turn On
CORRECTIVE ACTION Make sure that the Ethernet port has the appropriate mode setting. Make sure that the IES-1248’s IP settings are properly configured. Check the VLAN configuration. Ping the IES-1248 from a computer behind the peer Ethernet device. IES-1248-71/73 User’s Guide...
Page 427: Dsl Data Transmission
Check the connection from the MDF(s) to the telephone company or the PBX. Check the telephone wire mapping on the MDF(s). Make sure the in-house wiring works and is connected properly. Repeat the steps above using a different ADSL port. IES-1248-71/73 User’s Guide...
Page 428: Testing Wiring
Test D determines if there is a problem with your device’s internal splitter. Test E determines if there is a wiring problem between your device and MDF 3. Test F determines if there is a building-wiring problem between the subscriber’s wall jack and MDF 3. IES-1248-71/73 User’s Guide...
Page 429: Figure 300 Testing In-House Wiring
Disconnect the telephone wire from USER. Connect a telephone to USER (see Appendix A on page 439 for the proper pin assignments). If there is no dial tone, your device’s internal splitter may be faulty, contact your vendor. IES-1248-71/73 User’s Guide...
Page 430: Local Server
If the rates match, the quality of the telephone wiring that connects the subscriber to the ADSL port may be limiting the speed to a certain rate. If they do not match when a good wire is used, contact the distributor. IES-1248-71/73 User’s Guide...
Page 431: Configured Settings
Make sure that your computer’s IP address matches a configured trusted host IP address (if configured). Incorrectly configuring the access control settings may lock you out from using in-band management. Try using the console port to reconfigure the system. IES-1248-71/73 User’s Guide...
Page 432: Telnet
4 Type y at the question “Do you want to restore default ROM file(y/n)?” 5 The IES-1248 restarts. Figure 301 Resetting the Switch Via Command ras> config restore System will reboot automatically after restoring default configuration. Do you want to proceed(y/n)? > restoring configuration... saving configuration to flash... IES-1248-71/73 User’s Guide...
Page 433: Uploading The Default Configuration File
Type the configuration file's location, or click Browse to search for it. Choose the 1K Xmodem protocol. Then click Send. 4 After a successful configuration file upload, type atgo to restart the IES-1248. The IES-1248 is now reinitialized with a default configuration file including the default password of “1234”. IES-1248-71/73 User’s Guide...
Page 434: Recovering The Firmware
9 This is an example Xmodem configuration upload using HyperTerminal. Click Transfer, then Send File to display the following screen. Figure 303 Example Xmodem Upload Type the firmware file's location, or click Browse to search for it. Choose the 1K Xmodem protocol. Then click Send. IES-1248-71/73 User’s Guide...
Page 435 Chapter 58 Troubleshooting 10 After a successful firmware upload, type atgo to restart the IES-1248. The console port speed automatically changes back to 9600 bps when the IES-1248 restarts. IES-1248-71/73 User’s Guide...
Page 436 Chapter 58 Troubleshooting IES-1248-71/73 User’s Guide...
Page 437: Appendices And Index
Appendices and Index Product Specifications (439) Legal Information (449) Index (457)
Page 439: Appendix A Product Specifications
1.5U 439.8 mm (W) x 251 mm (D) x 66 mm (H) Weight • IES-1248-71 DC power version and IES-1248-73: 5.2 kg • IES-1248-71 AC power version: 5.0 kg Wire Gauge Specifications The following table shows the specifications for wire gauge.
Page 440: Table 118 Power Input Specifications
Changing fuses for the IES-1248-71 DC power version and IES-1248-73 requires disassembly of the device. Only a qualified technician should perform this. The following specifications are for the IES-1248-71 DC power version and IES-1248-73. Table 121 Fuse Specifications (IES-1248-71 DC power version and IES-1248-73) FUSE LOCATION...
Page 441 • Maximum Number of FTP Sessions: 1 • Maximum Number of HTTP Sessions: no restriction Host Protection In order to prevent flooding attacks against the IES-1248 itself, there are bandwidth restrictions on some types of traffic to the IES-1248. IES-1248-71/73 User’s Guide...
Page 442: Table 122 Default Settings
3 db 3 db Name: DEFVAL_MAX (Factory Default) Profile Status: Active Latency Mode: Interleave Upstream ADSL Settings: Downstream ADSL Settings: Max Rate 512 Kbps 9088 Kbps Min Rate 32 Kbps 32 Kbps Latency Delay 4 ms 4 ms IES-1248-71/73 User’s Guide...
Page 443 It allows a port to join all multicast IP addresses (224.0.0.0~239.255.255.255). The IES-1248 ADSL ports’ PVCs use ATM Adaptation Layer (AAL) 5. Pin Assignments Hardware Telco-50 Connector Pin Assignments The following diagram shows the pin assignments of the USER Telco-50 connectors. IES-1248-71/73 User’s Guide...
Page 444: Figure 304 User Telco-50 Pin Assignments
This table lists the ports and matching pin numbers for the hardware Telco-50 connectors. Table 123 Hardware Telco-50 Connector Port and Pin Numbers PORT NUMBER PIN NUMBER 2, 27 3, 28 4, 29 5, 30 6, 31 7, 32 8, 33 9, 34 10, 35 IES-1248-71/73 User’s Guide...
Page 445: Figure 306 Console Cable Rj-11 Male Connector
19, 44 20, 45 21, 46 22, 47 23, 48 24, 49 25, 50 Console Cable Pin Assignments The following diagrams and chart show the pin assignments of the console cable. Figure 306 Console Cable RJ-11 Male Connector IES-1248-71/73 User’s Guide...
Page 446: Figure 307 Console Cable Db-9 Female Connector
Appendix A Product Specifications Figure 307 Console Cable DB-9 Female Connector Table 124 Console Cable Connector Pin Assignments RJ-11 MALE DB-9 FEMALE Pin 2: TXD Pin 2 Pin 3: RXD Pin 3 Pin 4: GND Pin 5 IES-1248-71/73 User’s Guide...
Page 447: Appendix B Removing And Installing A Fuse
P P E N D I X Removing and Installing a Fuse This appendix shows you how to remove and install fuses for the IES-1248-71 AC power version. If you need to install a new fuse, follow the procedure below.
Page 448 Appendix B Removing and Installing a Fuse IES-1248-71/73 User’s Guide...
Page 450 3 Select the certification you wish to view from this page. Viewing Certifications 1 Go to http://www.zyxel.com. 2 Select your product on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page. IES-1248-71/73 User’s Guide...
Page 451 Registration Register your product online to receive e-mail notices of firmware upgrades and information at www.zyxel.com for global products, or at www.us.zyxel.com for North American products. IES-1248-71/73 User’s Guide...
Page 452 Appendix C Legal Information IES-1248-71/73 User’s Guide...
Page 453: Appendix D Customer Support
• Regular Mail: ZyXEL Costa Rica, Plaza Roble Escazú, Etapa El Patio, Tercer Piso, San José, Costa Rica Czech Republic • E-mail: info@cz.zyxel.com • Telephone: +420-241-091-350 • Fax: +420-241-091-359 • Web Site: www.zyxel.cz • Regular Mail: ZyXEL Communications, Czech s.r.o., Modranská 621, 143 01 Praha 4 - Modrany, Ceská Republika IES-1248-71/73 User’s Guide...
Page 454 • Support E-mail: support@zyxel.fi • Sales E-mail: sales@zyxel.fi • Telephone: +358-9-4780-8411 • Fax: +358-9-4780 8448 • Web Site: www.zyxel.fi • Regular Mail: ZyXEL Communications Oy, Malminkaari 10, 00700 Helsinki, Finland France • E-mail: info@zyxel.fr • Telephone: +33-4-72-52-97-97 • Fax: +33-4-72-52-19-20 •...
Page 455 • Sales E-mail: sales@zyxel.com • Telephone: +1-800-255-4101, +1-714-632-0882 • Fax: +1-714-632-0858 • Web Site: www.us.zyxel.com • FTP Site: ftp.us.zyxel.com • Regular Mail: ZyXEL Communications Inc., 1130 N. Miller St., Anaheim, CA 92806- 2001, U.S.A. Norway • Support E-mail: support@zyxel.no • Sales E-mail: sales@zyxel.no •...
Page 456 Appendix D Customer Support • Web Site: www.zyxel.es • Regular Mail: ZyXEL Communications, Arte, 21 5ª planta, 28033 Madrid, Spain Sweden • Support E-mail: support@zyxel.se • Sales E-mail: sales@zyxel.se • Telephone: +46-31-744-7700 • Fax: +46-31-744-7701 • Web Site: www.zyxel.se • Regular Mail: ZyXEL Communications A/S, Sjöporten 4, 41764 Göteborg, Sweden Ukraine •...
Page 457: Index
144, 145 Command Line Interface 277, 432 ATM Traffic Classes Commands 277, 278 Attainable Net Data Rate 268, 269, 389 Abbreviations authentication adsl annexl disable administrator adsl annexl enable default privilege level for administrators multicast mvlan delete IES-1248-71/73 User’s Guide...
Page 458 GARP Timer Down Stream Interval Delay GARP Timer Setup Down Stream Output Power General IP Commands Downstream General Setup Downstream (ds) Generic Attribute Registration Protocol Duplex Get Community Dynamic Host Configuration Protocol Get Community Command GetNext Green-and-yellow IES-1248-71/73 User’s Guide...
Page 459 MAC Count IP DSLAM MAC Count Disable Command IP Settings MAC Count Enable Command IP Setup MAC Count Filter Isolation Disable Command MAC Count Set Command Isolation Enable Command MAC Count Show Command Isolation Show Command MAC Filter IES-1248-71/73 User’s Guide...
Page 460 Non real-time Variable Bit Rate Priority Level nrt-VBR) Priority Queue Assignment NTP (RFC-1305) product registration Number of Errored Seconds Profile 121, 125, 126, 127 Number of Severely Errored Seconds Profiles Protective Earthing Terminal PU VLAN Punch-down Tool PVC Channels IES-1248-71/73 User’s Guide...
Page 461 Route Delete Command Splitter Chassis Rear Panel Connections Route Set Command Route Show Command Stacking RSTP (Rapid STP) Static Multicast Filter 45, 177 Static Route rt-VBR Setup Rx Broadcast Packets Static VLAN Rx Bytes Control Tagging Rx Discard Packets IES-1248-71/73 User’s Guide...
Page 462 95, 131, 134, 135, 136, 211, 212, 213, 218, 219, Time Zone 229, 230, 233, 236 227, 415 Vendor Info Tones ventilation holes TPID See Tag Protocol Identifier 229, 230 trademarks VID See VLAN Identifier Traffic Parameters Virtual Channel Profile Traffic Shaping IES-1248-71/73 User’s Guide...
Page 463 Voltage 95, 130, 131, 134, 135, 136, 211, 212, 213, 218, 219, 229, 230, 233, 236 warranty note Web Configurator Logging out Wire Gauge XMODEM upload 433, 434 IES-1248-71/73 User’s Guide...
Page 464 Index IES-1248-71/73 User’s Guide...
