Srx5K-Ioc4-Mrat Specifications - Juniper SRX5600 Hardware Manual

Serial Number Location

SRX5K-IOC4-MRAT Specifications

SRX5K-IOC4-MRAT is a fixed-configuration interface card with a Packet Forwarding Engine that provides
up to 480-Gbps (240-Gbps per PIC slot) line rate. This interface card provides scalability in bandwidth and
services to the SRX5400, SRX5600, and SRX5800 Services Gateways. See
NOTE: SRX5K-IOC4-MRAT cards do not support plug-in Modular Interface Cards (MICs).
Figure 68: SRX5K-IOC4-MRAT
SRX5K-IOC4-MRAT
The serial number label is located as shown in
Figure 67 on page 140.
Figure 67: SRX5K-IOC4-10G Serial Number Label
Serial number
ID label
Figure 68 on page
140
140.
