FUTABA T32MZ Instruction Manual page 91

The End Point function adjusts the left and right servo
throws, generates differential throws, and will correct
improper linkage settings.
The travel rate (normal full stick movement at high rates)
channels 1 to 16. Also, the limit point (how far the servo
30 〜
140%
30 〜
140%
Note: The indicators on the screen display actual servo throw
of the each channel. The center position of the indicator is
based on the Sub-Trim settings. Therefore the Sub-Trim
adjustment changes the Limit point display of the indicator.
The Servo Speed setting is used to set the servo delay for
each channel, from channel l to channel 16. The system uses
the programmed speed (delay) to slow down servo position
in each channel.
set.
to set.
＜ Linkage Menu ＞
91
