2.10.5 Capture Recordings on the Port

After login, click the Tools > TDM capture tab to open this interface. This tool can be used to capture
the voice stream from the Phone or Line interface. When the call lasts longer than 200 sec, only the first
200 sec of voice stream will be captured. The voice file is stored on the gateway in PCMU format.
Interface for capturing Port Recordings
Figure 2-55

2.10.6 Ethereal Capture

After login, click the Tools > Ethereal capture tab to open this interface. You are allowed to capture up
to three IP voice data files, each with up to 2M bytes. The data files are stored on the gateway in
dump.cap format under catalog /var/log.
Ethereal Capture Interface
Figure 2-56
