User Configuration Manual

2.7.12 Feature Codes (FXS only)

The feature codes consist of system feature codes and service feature codes. The system feature codes are
used for acquiring gateway information, and the latter is used for users to activate and deactivate
supplementary services.
After login, click the Advanced > Feature codes tab to open this interface.
The following are examples of dialing rules for feature codes:
Using *xx (dial * and 2 digits number) to activate a service.
Using #xx (dial # and 2 digits number) to cancel a service. This is illustrated with the following defaults
for various parameters, which may be modified according to requirements.
It is highly recommended not to modify the default configuration in System feature codes.
Feature Codes Configuration Interface
Figure 2-35
Feature Codes Configuration Parameter
Table 2-29
Name
System feature
codes
Obtain IP address
Query extension
number
Service feature
codes
66
Description
The function key for determining the IP address of the gateway. The default is ##.
When this function key is dialed, you can hear the TGW IP address, the web port
number for accessing the TGW, the IP address of the gateway, the subnet mask, and
the system software version number.
The function key for determining the phone number of this subscriber line. The
default is #00. By dialing this key, your will hear the phone number of the subscriber
line voiced by the gateway.
You can click to enable the service function keys, or clear the check box to
disable the service function keys.
