TGW4/8 Gateway Series for Aeonix

1.3 Equipment Structure

1.3.1 TGW4S

The TGW4S adopts a compact plastic structural design and can be placed on a desk.
It provides four FXS ports.
The TGW4S supports the following:
Configuration Combination of TGW4S
Table 1-2
Model
TGW4S
TGW4S Front Panel
Figure 1-1
Description of TGW4S Front Panel
Table 1-3
Indicator
PWR
WAN
PC
FXS1-4
TGW4S Back Panel
Figure 1-2
Description of TGW4S Back Panel
Table 1-4
Connector
FXS1-4
PC
WAN
PWR
Tadiran Telecom (TTL) L.P.
Description
Power Indicator
Indicator of WAN interface
Indicator of PC interface
Indicator of FXS port
FXS4 FXS3 FXS2 FXS1
Description
FXS port
10/100Mbps Ethernet Interface, RJ45
10/100Mbps Ethernet Interface, RJ45
Power interface, 12 VDC input
Number of FXS Ports
4
PC WAN PWR
User Configuration Manual
Number of FXO Ports
0
