TGW4/8 Gateway Series for Aeonix
System Status Parameters
Table 2-32
Name
Login User Info
SIP Registration
Info
Latest Call Info
Call Context Info
Rtp Context Info
Tadiran Telecom (TTL) L.P.
Description
Displays the IP address and permissions of the logged in user. The numbers following
the IP address show the online permission level of the user: 1- administrator; 2 -
operator; 3 – viewer. The viewer can only read the configuration.
When more than one administrator logs in at the same time, the first logged in
operator's permission level is 1; others are 3; also, when more than one operator logs
in at the same time, the first one's permission is 2, others are 3.
Show registration status:
Not enabled: the registration server's address is not entered yet;
Latest response: the latest response message for the registration. 200 means registered
successfully;
No response: no response from registration server. The cause may be 1) incorrect
address for the registration server; 2) IP network fault; or, 3) the registration server is
not reachable.
Displays the latest call.
Displays the call status.
Displays the voice channel related to the calls.
