TGW4/8 Gateway Series for Aeonix
The format of number transformation is:
Source
Take FXS 021 REMOVE 3 as an example. It indicates that, for a call from the FXS port (on a subscriber
line), the first three digits area code 021 is removed from the called number.
Where FXS is source, 021 is number, and REMOVE 3 indicates the method of number transformation.
The format of routing rules is:
Source
Take IP 800[0-1] ROUTE FXO 1-2 as an example. It means that calls from IP with called number prefix
8000 or 8001 are routed to FXO port in a sequential order. Namely, FXO Port 2 is selected when FXO
Port 1 is busy and so on.
For details of Source and Number, see Table 2-18.
For details of Number Transformation and Routing Destination, see Table 2-19 and Table 2-20
respectively.
Routing Table Format
Table 2-18
Name
Source
Number
Number Transformations
Table 2-19
Processing
Mode
KEEP
Tadiran Telecom (TTL) L.P.
Number Transformation Method
Number ROUTE
Description
There are three types of source: IP, FXS (Phone/fax) and FXO (Line).
The IP indicates any IP addresses. IP [xxx.xxx.xxx.xxx] indicates a specific address. IP
[xxx.xxx.xxx.xxx:port] indicates a specific IP address and a specific port number.
The FXS or FXO indicates any FXS or FXO port. FXS1, FXO2, FXS [1-2], or similar
indicates a specific port.
A called party number with the form of number. It could be a calling party number with
the form of CPN + number The number may be denoted with digit 0-9,"*",".","#"," x ",
etc., and uses the same regular expression as that of dialing rules. Here are examples of
the form of number:
Designate a specific number: eg.114, or 61202700
Designate a number matching a prefix: such as 61xxxxxx.
Specify a number scope. For example, 268[0-1, 3-9] specifies any 4-digit number
starting with 268 and followed by a digit between 0-1or 3-9.
Number matching follows the principle of minimum matching. For example: x matches
any number with at least one digit; xx matches any number with at least two-digits; 12x
matches any number with at least 3-digits starting with 12.
Description and Example
Keep number. A positive number behind KEEP means to keep several digits in front of
the number; a negative number means to keep several digits at the end of the number.
Example: FXS 02161202700
Keep the last 8 digits of the called number 02161202700 for calls from FXS.
The transformed called number is 61202700.
Routing Destination
KEEP -8
