2.4.3 Subscriber Line Batch (Unavailable on the TGW4S)

Only a gateway with FXS ports can display this interface.
After login, click the Line > Batch tab to open the Batch configuration interface.
Step 1
Click
Step 2
Click
30
Description
Select if reverse polarity signal sending is activated on this line. By default, this is not
selected.
Note:The gateways will provide reverse polarity signal when the phone is connected after
this feature is activated.
Select if the line is set to maintenance status, in which case the FXS port no longer
supplies a current to the phone. By default, this is not selected.
Select if voice mail service is activated. By default this is not selected.
When selected, the MWI output Voltage value is 90V.
(Also see MWI Re-subscription on the Advanced > SIP page.)
Set whether DDI (Direct Dialing In) is activated, By default, this is not selected. Different
from FXS, DDI is only used for incoming calls, and the gateways will not send dial tone
after off-hook (calling in) on user side.
Note: Reverse polarity signal must be activated on the gateways when DDI is used.
Select if recording service is activated. By default, this is not selected.
, the following interface is shown. Choose batch configured features and click OK.
to activate this function to configure this parameter. For details of the parameter, see Line > Feature.
