TGW4/8 Gateway Series for Aeonix
Processing
Mode
RELAY
Routing Destination
Table 2-20
Destination
ROUTE NONE
ROUTE FXS
ROUTE FXO
ROUTE IP
Tadiran Telecom (TTL) L.P.
Description and Example
Insert prefix of called party number when calling out. The inserted prefix number
follows behind RELAY.
Example:
IP 010 RELAY
For calls from IP with called party number starting with 010, digit stream 17909 will be
outpulsed before the original called party number is sent out.
Example:
IP 010 RELAY
For a call from the IP end with the called number starting with 010, before the call is
made, 17909 is automatically dialed first and three seconds later, the called number is
dialed.
One comma "," represents one second.
Description and Example
Calling barring (also known as "blacklist").
Example: IP CPN[1,3-5]
Bar all calls from IP, of which the calling numbers start with 1, 3, 4, and 5.
Route a call to FXS ports.
Example 1: IP 800[0-3]
Select a port in sequential order.
Example 2: IP 800[0-3]
Point this call to FXS port 1.
Example 3:
IP 800[0-3] ROUTE FXS 1-2/R
Select a port in round robin order
Example 4: IP 800[0-3]
Select all idle ports and provide ringing.
Route a call to FXO port.
Example 1: IP x ROUTE
Select a port in sequential order.
Example 2: IP 800[0-1]
Select a port in round robin order.
Route a call to the SIP proxy server.
Example: FXS 021 ROUTE IP 228.167.22.34:5060
228.167.22.34:5060 is the IP address and port of the platform.
17909
17909 ,,,
ROUTE NONE
ROUTE FXS 1-2
ROUTE FXS 1
ROUTE FXS 1-2/G
FXO 1-2
ROUTE FXO 1-2/R
