[7] SIMULATIONS

1. Entering the simulation mode

Perform the following procedure to enter the simulation mode.
"#" key
"*" key
"C" key
Main code
Start key
Sub code

2. Canceling the simulation mode

When the clear all key is pressed, the simulation mode is cancelled.
When the interruption key is pressed, the process is interrupted and the
screen returns to the sub code entering display.
* After canceling the simulation mode, be sure to turn OFF/ON the
power and check the operation.
Note: If the machine is terminated by a jam error or paper empty during
copying in the adjustment by the simulation, recopying is required.
Note: The values in the simulation columns are not default values but
sample values.
"*" key
Start key
AR-M207 M165 M162 SIMULATIONS 7-1

3. List of simulations

Main
Sub
code
code
01
01
Mirror scanning operation
02
Mirror home position sensor (MHPS) status display
02
01
Single paper feeder (SPF) aging *2
02
SPF sensor status display *2
03
SPF motor operation check *2
08
SPF paper feed solenoid operation check *2
09
RSPF reverse solenoid operation check *2 *3
10
RSPF paper exit gate solenoid operation check *2 *3
11
SPF PS release solenoid operation check *2
03
02
Shifter/job separator sensor status display
03
Shifter operation check
04
Job separator operation check *4
11
Shifter home position check
05
01
Operation panel display check
02
Fusing lamp and cooling fan operation check
03
Copy lamp lighting check
06
01
Paper feed/transport solenoid operation check
02
Resist roller solenoid (RRS) operation check
10
Main cassette semicircular roller cleaning
07
01
Warm-up display and aging with jam
06
Intermittent aging
08
Shifting with warm-up display
08
01
Developing bias output
02
Main charger output (Grid = HIGH)
03
Main charger output (Grid = LOW)
06
Transfer charger output
09
01
Duplex motor forward rotation check *6
02
Duplex motor reverse rotation check *6
04
Duplex motor RPM adjustment *6
05
Duplex motor switchback time adjustment
10
-
Toner motor operation
14
-
Trouble cancel (except for U2)
16
-
U2 trouble cancel
20
01
Maintenance counter clear
21
01
Maintenance cycle setting
22
01
Counters display
03
Jam memory display
04
Jam total counter display
07
Key operator code display
09
Paper feed counter display
13
CRUM destination display *5
14
P-ROM version display
15
Trouble memory display
22
SPF jam counter display *2
24
01
Jam total counter clear
02
Trouble memory clear
04
SPF counter clear *2
05
Duplex print counter clear *6
06
Paper feed counter clear
07
Drum counter clear
08
Copy counter clear
09
Printer counter clear
13
Scanner counter clear
14
SPF jam total counter clear *2
15
Scanner mode counter clear
