Sharp AR-M207 Service Manual page 11

(3) 1-stage paper feed unit
Paper feed 250 Sheets
capacity
Paper size Not available(The paper size can be set with the
detection function menu.)
Paper empty Available
detection
Paper size A3, B4, A4, A4R, B5, B5R, 11" x 17", 8.5" x 14",
8.5" x 13", 8.5" x 11", 8.5" x 11"R, 16K, 16KR, 8K
Paper weight 56 - 90g/m²(15 - 24lbs)
Factory setting AB system: A4
size Inch system: 8.5" x 11"
Size selection A3, B4, A4, A4R, B5, B5R,11" x 17", 8.5" x 14",
8.5" x 13", 8.5" x 11", 8.5" x 11"R
Cassette Can be made by the user
installation/
removal
Power Supplied from the machine(Power consumption:
5.6W)
External 590 mm(W) x 471 mm(D) x 88mm(H)
dimensions
Weight 5.0Kg
Reliability(MCBJ/ Conforms to the main unit
MCBF)
Item included Installation manual, Paper size label
Case color Frosty white
(4) 2-stage paper feed unit
Paper feed 250 Sheets x 2
capacity
Paper size Not available(The paper size can be set with the
detection function menu.)
Paper empty Available
detection
Paper size A3, B4, A4, A4R, B5, B5R, 11" x 17", 8.5" x 14",
8.5" x 13", 8.5" x 11", 8.5" x 11"R, 16K, 16KR, 8K
Paper weight 56 - 90g/m²(15 - 24lbs)
Factory setting AB system: A4
size Inch system: 8.5" x 11"
Size selection A3, B4, A4, A4R, B5, B5R
11" x 17", 8.5" x 14", 8.5" x 13", 8.5" x 11",
8.5" x 11"R
Cassette Can be made by the user
installation/
removal
Power Supplied from the machine(Power consumption:
8.4W)
External 590 mm(W) x 471 mm(D) x 174 mm(H)
dimensions
Weight 10.0Kg
Reliability(MCBJ/ Conforms to the main unit
MCBF)
Item included Installation manual, Paper size label
Case color Frosty white
(5) Dual function board
Expansion Electronic sort function, 2In1/4In1, Rotation copy,
function Edge erase/Center erase, Margin shift, Card shot
USB2.0(High-speed support),SPLC print(JBIG-
GDI), ROPM function
Electronic sort JBIG
compress function
Memory for 16MB
electronic sort
Electronic sort A4 standard document(Test chart B)100 sheets
scan quantity
Memory DIMM Memory slot x 1
expansion Max. 256MB x 1slot + 16MB(Max 272MB in total)
(Externally described as max. 256MB x 1)
Item included Installation manual,
(6) Original cover(OC)
Function
Item included
(7) 256MB expansion memory
Memory
Item included
(8) Job separator
Installation
conditions
Bin number
Distribution
system
Paper size
Paper weight
Paper exit section
capacity
Paper exit job
Paper exit full
detection
Power
Item included
Case color
Installation
(9) Network box
Function
Power
External
dimensions
Item included
(10) Facsimile expansion kit
Function
Item included
(11) Barcode font kit
Same as the AR-PF1.
(12) Flash memory kit
Same as the AR-PF2.
(13) PS3 expansion kit
Same as the AR-PK1N.
(14) Facsimile expansion memory
Same as the AR-MM9.
AR-M207 M165 M162 SPECIFICATIONS 2-6
Up/down open/close mechanism
Installation manual
256MB
Installation manual
Install when the printer or the FAX is expanded.
Performs paper exit for every job
1 bin
Controlled by the main unit.
Conforms to the main unit paper feed paper.
Conforms to the main unit paper feed paper.
Upper stage: 100 Sheets
Lower stage: 150 Sheets
Upper stage: FAX output or printer output
Lower stage: Copy output or printer output
Upper stage: Available
Lower stage: YES (Full detection by the counter)
None
Installation manual
Frosty white
Must be installed easily
Supports the network printer(PCL/PS)and the
network scanner.
Supplied from the machine
(Power consumption: 5.5W)
248 mm(W) x 127 mm(D) x 59 mm(H)
USB2.0code x 1
Software CD(Driver/Network setting/application)
Installation manual
FAX expansion option
One-touch dial key, destination label, installation
manual
