LCD Panel Open - Models A, C & D
2
7 6 5
11
3
1
4
5
9
10
Note that the Touchpad and
Buttons has a valid operation-
8
al area indicated within the
red dotted lines above.
LCD Panel Open - Models A, C & D 1 - 7
Quick Start Guide
Figure 1 - 2
LCD Panel Open
Models A, C & D
1. Built-In PC Camera
2. PC Camera LED
3. Built-In Microphone
4. LCD
5. Speakers
6. Power Button
7. LED Lock Indicators
8. LED Status Indicators
9. Keyboard (Model A
supports an
Illuminated Keyboard)
10. TouchPad and
Buttons
11. Fingerprint Reader
(Optional)
Note that the keyboard for
Models A, C & D are differ-
ent, and only Model A is
pictured (see Table 1 - 1,
on page 1 - 5).
