Upgrading The Computer
6
Figure 6 - 30
Removing the
mSATA SSD

6 - 30 Upgrading the mSATA SSD

Upgrading the mSATA SSD
1. Turn the computer off, remove the AC/DC adapter (and battery) and turn the computer over.
2. Remove the component bay cover (see the appropriate component bay cover
removal page for your model).
3. Locate the mSATA SSD
4. Remove screw and the module will pop up.
2
5. You can then remove the module
6. Replace the component bay cover (see page
Models A, C & D
Model E
.
1
and replace it if necessary.
3
6 - 30).
1
Model B
2
Model F
3
