Removing the Hard Disk from the Caddy HDD Bay (Models A, C & D)
Note that the secondary hard disk module is used to replace the optical device mod-
ule (CD/DVD) in Models A, C & D computers.
1. Turn the computer off, remove the AC/DC adapter (and battery) and turn the computer over.
2. Remove the optical device (see page
3. Remove screws -
1
4. Slide the HDD in the direction of arrow
5. Remove the HDD 6
6. Reverse the process to install a new hard disk.
6 - 7 or page
from the rear of the secondary HDD module assembly.
4
.
5
from the module caddy 7
1
4
5
6
6 - 8).
.
2
3
7
Upgrading the Hard Disk Drive(s) 6 - 17
Upgrading The Computer
Figure 6 - 12
Removing the
Secondary HDD
from the Module
Caddy
(Models A, C & D)
6
