Quick Start Guide
1
Figure 1 - 5
LCD Panel Open
Model F
1. Built-In PC Camera
2. PC Camera LED
3. Built-In Microphone
4. LCD
5. Speakers
6. LED Indicators
7. Power Button
8. Illuminated Keyboard
9. TouchPad and
Buttons
10. Fingerprint Reader
(Optional)

1 - 10 LCD Panel Open - Model F

LCD Panel Open - Model F
2
5
6
3
1
4
5
8
9
10
Note that the Illumi-
nated Touchpad has a
defined valid opera-
tional area of sensitiv-
ity indicated within the
sensor area of the il-
lustration below. See
7
