Removing the Cover from the Primary HDD Bay (Models A, C & D)
1. Turn the computer off, remove the AC/DC adapter (and battery) and turn the computer over.
2. Locate the hard disk bay cover and remove screws
3. Remove the hard disk bay cover
1
4
1
by levering the cover at point
3
2
Upgrading The Computer
& .
2
.
4
4
3
Upgrading the Hard Disk Drive(s) 6 - 11
Figure 6 - 6
HDD Bay Cover
Screws & Cover
Removal
(Models A, C & D)
6
