Removing The Component Cover (Model F) - EUROCOM racer 4w User Manual

Upgrading The Computer
Figure 6 - 27
Component Cover
Screws
(Model F)
6
Figure 6 - 28
Component Cover
Move & Removal
(Model F)
6 - 28 Upgrading the System Memory (RAM)

Removing the Component Cover (Model F)

1. Turn the computer off, remove the AC/DC adapter (and battery) and turn the computer over.
2. Remove screws -
1
2
1
3
3. Slide the component bay cover until the cover and case indicators
4. Lift the cover off the computer.
8
7
from the bottom and rear of the computer
6
5
4
.
6
are aligned.
7
8
