Removing The Battery from Model E & F Computers
1.
Turn the computer off, remove the AC/DC adapter and turn the computer over.
2.
Slide the latch
in the direction of the arrow.
1
3.
Slide the latch
in the direction of the arrow, and hold it in place.
2
4.
Lever the battery up at point
5.
Lift the battery out of the compartment
.
3
.
4
3
1
2
Battery
Note that though only Model
F is pictured, the battery re-
moval procedure is identical
4
for both (E & F) computer
models.
Upgrading The Computer
Figure 6 - 2
Removing the
Battery
(Models E & F)
Removing the Battery 6 - 5
