Upgrading The Computer
6
Figure 6 - 7
HDD/ODD Bay
Cover Screws &
Cover Removal
(Model B)
6 - 12 Upgrading the Hard Disk Drive(s)

Removing the Cover from the HDD/ODD Bay (Model B)

1. Turn the computer off, remove the AC/DC adapter (and battery) and turn the computer over.
2. Locate the HDD/ODD bay cover and remove screws
3. Slide the cover in the direction of arrow
4. Remove the HDD/ODD bay cover
2
1
, until the case markers
4
6
5
3
6
.
-
1 3
line up.
5
4
5
