Upgrading The Computer
Figure 6 - 15
Secondary
Hard Disk Insulation
Plate Removal
(Model B)
6
Figure 6 - 16
Secondary
Hard Disk Assembly
Installation
(Model B)
6 - 20 Upgrading the Hard Disk Drive(s)
7. Remove screws -
7
8. Reverse the process to install a new disk (make sure you install the insulation plate).
9. Slide the HDD assembly into the bay at an angle as illustrated.
10. Make sure the insulation plate slides under the HDD bay guide at point
11. Slide the assembly in the direction of the arrow
the screws (see Figure 6 - 17 on page 6 -
and the insulation plate
10
9
8
11
7
21).
.
11
10
11
and secure the assembly with
12
12
11
.
