Upgrading the Optical Device (Models E & F)
1. Turn the computer off, remove the AC/DC adapter (and battery) and turn the computer over.
2. Locate the secondary hard disk bay cover and remove screws
3. Remove the hard disk bay cover.
4. Remove the screw at point
optical device out of the bay.
5. Reverse the process to install any new optical (CD/DVD) device.
1
2
, and use a screwdriver to carefully push out the
3
Note that though only Model F
is pictured, the cover removal
procedure is identical for all
both models.
Upgrading The Computer
.
&
1 2
3
Optical (CD/DVD)
(Models E & F)
Upgrading the Optical Device 6 - 9
6
Figure 6 - 5
Removing the
Device
