Removing The Component Cover (Models A, C & D) - EUROCOM racer 4w User Manual

Removing the Component Cover (Models A, C & D)
1. Turn the computer off, remove the AC/DC adapter (and battery) and turn the computer over.
2. Remove screws -
1
1
3. Slide the component bay cover until the cover and case indicators
4. Lift the cover off the computer.
6
from the bottom of the computer
4
2
3
5
Upgrading The Computer
.
4
are aligned.
5
6
Upgrading the System Memory (RAM) 6 - 25
Figure 6 - 21
Component Cover
Screws
(Models A, C & D)
Figure 6 - 22
Component Cover
Move & Removal
(Models A, C & D)
6
