11.
Install the grille — Position the outer perimeter of the grille into the groove of the
speaker baffle. Six magnets pull the grille securely into place, as shown below.
Speaker Grille
Figure 48.
Installing the Speaker Grille
NOTE: Grille hooks are provided for removal of the grille after installation.
CS 26T Plus and CS 120P User Guide • Installation
31
